- Page 1 Nest Protect (Wired 120V ~ 60Hz) Detects smoke and carbon monoxide (CO) User’s Guide ATTENTION: Please read carefully and save this user’s guide in a safe place.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Meet your Nest Protect .................... -
Page 3: Meet Your Nest Protect
Nest Protect is designed to detect smoke and carbon monoxide in a residential environment. It has multiple sensors to help it understand what’s happening in your home and a photoelectric sensor to detect slow, smoldering fires. Nest Protect can be used as a single station or multiple station alarm. - Page 4 Horn enables Nest Protect to alert you with a loud emergency sound. Speaker allows Nest Protect 5.28" to speak with a human voice. (13.4cm) Light ring changes color to alert you. Push the Nest button to hush alarms and run a test.
-
Page 5: Location In Your Home
• In homes with more than 1,000 square feet on one level, additional alarms may be required. Nest Protect should be installed at least 10 ft (3 m) away from cooktops or cooking appliances. Nest Protect should NOT be installed in unfinished attics or garages. -
Page 6: Placement On The Ceiling Or Wall
Installing on the ceiling is recommended. Mark where the screws will go using the base as a guide. Make sure it’s at least 4 inches (10 cm) away from the wall. 4" CEILING (10cm) Minimum 4" (10cm) Minimum BEST NOT IN HERE THIS AREA 12" (30.5cm) Maximum OKAY NEST LOGO HERE IS UPRIGHT SIDE WALL Figure 1... -
Page 7: Placement On A Sloped Ceiling
PLACEMENT ON A SLOPED CEILING If you have a sloped, peaked or cathedral ceiling, Nest Protect should be 4 inches to 3 feet (10 cm – 1 m) from the highest point. NOT IN NOT IN THIS AREA THIS AREA "... -
Page 8: Setup And Installation
3. Have more Nest Protects? 2. Set up Nest Protect with the Nest app The Nest app will ask you if you have additional Nest Protects to set up. If so, it’ll take you The Nest app will guide you through each step: through a shorter setup. - Page 9 Protects, test they’re added to your Nest Account Switch off the correct circuit breaker or remove by pushing the Nest button on one Nest Protect the fuse from the fuse box. and follow the instructions to test. If they’re all added, every Nest Protect will speak up.
- Page 10 8. Remove the old connector 9. Attach the Nest 120V connector Unscrew the wire Hold the white wire ends together, cap them nuts to detach the with a wire nut and twist clockwise until secure. 120V connector Do the same with the black wires. There’s no from your old need for the red/orange/yellow wire.
- Page 11 Give it a slight twist clockwise. It’ll CLICK into place. Breaker box 14. Press to test Press the Nest button on one Nest Protect and follow the spoken instructions to test. They should all speak to you, confirming that they’re in range of each other.
-
Page 12: Operating Instructions
OPERATING INSTRUCTIONS When the Nest Protect smoke and carbon monoxide (CO) alarm has something to say, it will speak to you in words and colors instead of just beeping. It has two kinds of alerts: Heads-Up and Emergency Alarms. • Nest Protect can see smoke or carbon monoxide levels rising. So before it turns on an Emergency Alarm, Nest Protect gives you a friendly spoken Heads-Up to warn you in advance. - Page 13 “SMOKE ALARM HAS YELLOW or You’ve hushed an alert. Make sure you’re safe and BEEN HUSHED.” RED pulses. Nest Protect will now keep have put out the source of quiet, unless smoke or smoke or carbon monoxide. carbon monoxide reaches “CARBON MONOXIDE dangerous levels.
-
Page 14: Heads-Up And Emergency Alarms
So go to that room and press the Nest button on the Nest Protect there to hush every Nest Protect in the home. This will ensure that you will identify the source of... -
Page 15: Wireless Interconnect
• The range and proper operation of any means when one Nest Protect raises any kind wireless device will vary depending on of alerts, every Nest Protect in the house will its surroundings. tell you in which room the smoke or CO is in. For •... -
Page 16: Testing Nest Protect
• Press the Nest button twice to start a test. • Nest Protect will say: “This is only a test. The When you turn out the lights for the night, alarm may sound.”... -
Page 17: General Maintenance
CLEANING YOUR NEST PROTECT BACKUP BATTERY Like any photoelectric smoke alarm, Nest In case of power outage, Nest Protect will use Protect can get dusty. Do not clean it with its backup battery. detergents or solvents (like Windex®) and do... - Page 18 EXPIRATION close the battery compartment. Nest Protect has a limited life like any smoke/ CO alarm. Nest Protect lifetime is 7 years. 1. First battery You will need to replace Nest Protect after 2.
-
Page 19: Safety
If they are wired, the smoke alarms cannot work during a long power outage and once the backup battery is dead. Nest Protect will warn you in advance when batteries are running low so that you can replace them. - Page 20 LIMITATIONS OF CARBON MONOXIDE (CO) ALARMS • This smoke alarm is not intended to • NEVER ignore your carbon monoxide alarm alert hearing impaired residents. Alarms if it alarms. Refer to “What to do in case of a specifically designed for the hearing impaired, carbon monoxide alarm”...
-
Page 21: Installation Code
As Nest (1) *In all sleeping rooms and guest rooms Protect is also a Carbon Monoxide alarm, it is (2) *Outside of each separate dwelling unit sleeping not recommended to install it in a furnace room area, within 6.4 m (21 ft) of any door to a sleeping... -
Page 22: Ac Installation Warnings
AC INSTALLATION WARNINGS ELECTRICAL SHOCK HAZARD • Turn off power to the area where you will install • The alarm cannot be operated from power this unit at the circuit breaker or fuse box derived from a square wave, modified square before beginning installation. - Page 23 WHERE NOT TO INSTALL YOUR CO ALARMS homes, for example – it is recommended • Keep carbon monoxide alarm at least 5 ft (1.5 m) a smoke alarm to be placed as far from away from any cooking appliance including these fuel-burning sources as possible.
-
Page 24: Carbon Monoxide (Co) Precautions
• Mild Exposure: Slight headache, nausea, Electrical appliances typically do not produce CO. vomiting, fatigue (often described as ‘Flu-like’ symptoms). The Nest Protect CO sensor meets the alarm • Medium Exposure: Severe throbbing headache, response time requirements of the American drowsiness, confusion, fast heart rate. - Page 25 If alarm signal sounds: 1) Operate reset/silence button THE FOLLOWING CONDITIONS CAN RESULT IN (Press NEST button); TRANSIENT CO SITUATIONS 2) Call your emergency services [fire dept. or 911]; 1. Excessive spillage or reverse venting of fuel...
-
Page 26: Fire Safety Precautions
FIRE SAFETY PRECAUTIONS CREATE AN ESCAPE PLAN TO PRACTICE WHAT TO DO IN CASE OF FIRE Be prepared when your smoke/CO alarm sounds its • Get out now. alarm. Develop a family escape plan, discuss it with • Don’t panic; stay calm. all household members, and practice it regularly. -
Page 27: Federal Communications Commission (Fcc) Compliance
Nest. This device complies with part 15 of FCC rules. Nest Labs. 900 Hansen Way. Palo Alto, CA 94304 Operation is subject to the following two conditions: 1. This device may not cause harmful interference. -
Page 28: Limited Warranty
3. WARRANTY CONDITIONS; HOW TO GET SERVICE IF YOU WANT TO CLAIM UNDER THIS LIMITED WARRANTY Before being able to claim under this Limited Warranty, the owner of the Product must (a) notify Nest Labs of the intention to claim by visiting nest.com/support during the Warranty... - Page 29 User’s Guide or other instructions SOLELY RESPONSIBLE FOR (AND NEST LABS DISCLAIMS) ANY provided by Nest Labs; (c) abuse or misuse of the Product; (d) AND ALL LOSS, LIABILITY, OR DAMAGES, INCLUDING TO YOUR breakdowns, fluctuations, or interruptions in electric power or WIRING, FIXTURES, ELECTRICTY, HOME, PRODUCT, PRODUCT the telecommunications network;...
