Carrier is committed to continuously improving its products according to national and international standards
to ensure the highest quality and reliability standards, and to meet market regulations and requirements.
All specifications subject to change without prior notice according to Carrier policy of continuous development.
03501149
Cassette
Sky
53QC 36 - 48

HEAT PUMP

INSTALLATION MANUAL

Quality
Enviromental
Management System
Management System
ISO 9001 : 2008
ISO 14001 : 2004
Certi cate No.: QS-5519HH
Certi cate No : 12 104 30334 TMS
220-240V ~ 50Hz 1Ph
380-420V ~ 50Hz 3Ph
Safety
Management System
BS OHSAS 18001 : 2007
Certi cate No : 12 116 30334 TMS
Rev. (0) - 2013
