BEFORE YOU BEGIN
Read these instructions completely and carefully.
IMPORTANT
•
- Save these instructions for
local inspector's use. Observe all governing codes and
ordinances.
Note to Installer
• - Be sure to leave these
instructions with the Consumer.
Note to Consumer
•
with your Owner's Manual for future reference.
Skill Level
• - Installation of this dishwasher requires
basic mechanical and electrical skills. Proper
installation is the responsibility of the installer.
Product failure due to improper installation is not
covered under the GE Appliance Warranty.
Completion Time
• - 1 to 3 Hours.
New installations require more time than replacement
installations.
CONTENTS
Installation Preparation
Parts Supplied......................................................................................3
Materials You Will Need ..................................................................3
Tools You Will Need ..........................................................................3
Advance Planning ..............................................................................4
Prepare Dishwasher Enclosure....................................................4
Prepare Drain Plumbing..................................................................5
Prepare Electrical Wiring ................................................................6
Prepare Hot Water Line ..................................................................7
Installation Instructions
Step 1, Locate Installation Items ................................................7
Step 2, Install Trim Pieces ..............................................................7
Step 3, Check Door Balance..........................................................8
Step 4, Remove Wood Base, Install Leveling Legs ............8
Step 5, Remove ToeKick ..................................................................8
Step 6, Remove ToeKick Brace ....................................................8
Step 7, Install Power Cord ..............................................................9

Safety Information

- Keep these instructions
IMPORTANT
•
be installed to allow for future removal from
the enclosure if service is required.
• If you received a damaged dishwasher, you should
immediately contact your dealer or builder.
READ CAREFULLY.
KEEP THESE INSTRUCTIONS.
FOR YOUR SAFETY
Read and observe all CAUTION and WARNINGS shown
throughout these instructions.
While performing installations described in this booklet,
gloves, safety glasses or goggles should be worn.
For Monogram local service in your area, 1.800.444.1845.
For Monogram parts and accessories, call 1.800.626.2002.
For Monogram parts and accessories in Canada,
call 1.800.561.3344.
Step 8, Install 90° Elbow..................................................................9
Step 9, Position Water Line and Housing Wiring ................9
Step 10, Install Drain Hose to Dishwasher Drain Port......9
Step 11, Insert Drain Hose Through Cabinet......................10
Step 12, Slide Dishwasher
Three-Fourths of the Way Into Cabinet................................10
Step 13, Slide Dishwasher Into Final Position ............10, 11
Step 14, Level Dishwasher ..........................................................11
Step 15, Secure Dishwasher
to Countertop or Cabinet ............................................................12
Step 16, Connect Water Supply ..............................................12
Step 17, Connect Drain Line ......................................................13
Step 18, Connect Power Supply ..............................................14
Step 19, Pretest Checklist ............................................................14
Step 20, Dishwasher Wet Test ..................................................15
Step 21, Set Water Hardness ....................................................15
Step 22, Install Sound Upgrade Kit if Equipped ................15
Step 23, Install ToeKick ..............................................Back Cover
Step 24, Literature ........................................................Back Cover
2
- The dishwasher MUST
