Page 1: Digital Video Recorder
Digital Video Recorder Hardware Technical Reference Revision 1.1 October 2008 Fast Forward Video 18200-B West McDurmott Irvine, CA, 92614 Fax: (949) 852-1226 Phone: (949) 852-8404... -
Page 3: Table Of Contents
RS-232 – U J5 - A ..............7 OMMUNICATION LTERNATE SATA D J21........................8 J23...........................8 OWER RST, F ................8 UMPER LOCK IRMWARE UPDATE APPENDIX....................9 ......................9 ECHANICAL IMENSIONS ..........................9 LEVATION .......................10 EVISION HISTORY Q HD DVR Hardware Technical Reference - Rev. 1.1... -
Page 5: Overview
Q HD With HD-SDI and SD-SDI I/O capabilities the also features RS-422 control using Sony, Odetics and FFV serial protocol and an extensive menu of control and configuration options. is versatile enough to satisfy a variety of demanding DVR applications. Configuration Prior to use, set the configuration to verify operation as expected. -
Page 7: Architecture
Since image quality is of utmost importance, JPEG2000 compression is used to provide the highest picture quality. To support a sustained data rate at this level, the designers of the Q HD DVR included a SATA hard disk controller on the circuit board. -
Page 8: Hardware Block Diagram
IDE Hard Codec SATA LTC In / Out SATA Disk In / Out Bridge Controller Local Real Time Clock Micro- 32 MB processor Private Port SDRAM 16 MB Flash RS232 EPROM Port Q HD DVR Hardware Technical Reference - Rev. 1.1... -
Page 9: Specifications
57,600 baud, 8 data bits, No parity, 1 stop bit. DISK CONTROLLER Protocol: SATA I/II Maximum Data Rate: 60 Mbit/sec Single Drive Maximum Hard Drives: Supported Hard Drives: Hitachi, Western Digital, Seagate Q HD DVR Hardware Technical Reference - Rev. 1.1... - Page 10 4.5” W x 7.0” L x .75” D – D depends on config. Power Consumption: 10.8 watts not including storage device(s). Input Voltages: + 3.3 and +5V DC Specifications subject to change without notice Q HD DVR Hardware Technical Reference - Rev. 1.1...
-
Page 11: Jumper And Connector Locations
IDE, .100 S IRMWARE PDATE ORCE IRMWARE PACING Connector Pin-Outs AUDIO MONITOR OUTPUT Output Left Headphone Right Headphone Ground RS-232 – FFV FRONT PANEL PORT Function Receive Data (RX) Transmit Data (TX) Ground Q HD DVR Hardware Technical Reference - Rev. 1.1... -
Page 12: Aes3 And Ltc J4
GROUND GROUND Transmit Data (-) Transmit Data (+) Receive Data (+) Receive Data (-) GROUND GROUND RS-232 – USER COMMUNICATION J5 - ALTERNATE Function Transmit Data (TX) Receive Data (RX) Ground Q HD DVR Hardware Technical Reference - Rev. 1.1... -
Page 13: Sata Data J21
Function Hardware Reset or Initialize DVR Firmware Update Force DVR into firmware update when shorted during power on. Default Update Protocol - 57600 baud, 8 data, No parity, 1 stop bits Q HD DVR Hardware Technical Reference - Rev. 1.1... -
Page 15: Appendix
The following dimensions assume all connectors are used. Non-use of connectors will vary total installed height. Wiring loop may effect space requirements. Max Connector Height .500" Board Thickness .063" .100" Max Component Height Q HD DVR Hardware Technical Reference - Rev. 1.1... -
Page 17: Revision History
A P P E N D I X REVISION HISTORY REVISION HISTORY Rev. 1.0 – Aug. 28, 2008 - New Release Rev. 1.1 – Oct. 23, 2008 – Add details for LTC Sync Clock Input. Q HD DVR Hardware Technical Reference - Rev. 1.1...
