DV Signage MON-100W Manual

10.2” monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Manual
MON-100W
10.2" Monitor
MON-100W : P/N 586845110-3
Page 1 of 22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MON-100W and is the answer not in the manual?

Questions and answers

Related Manuals for DV Signage MON-100W

Summary of Contents for DV Signage MON-100W

  • Page 1 Manual MON-100W 10.2” Monitor MON-100W : P/N 586845110-3 Page 1 of 22...

  • Page 2: Table Of Contents

    Table of Contents   1. Introduction 2. System 3. Instruction 3.1 Preparation 3.2 Powering On 3.3 Signal Input 4. Controls 4.1 Button control 4.2 OSD menu function 4.3 Remote control 4.4 Serial control 5. Dimensions 6. Specification 7. Appendix I – Graphic & Video Mode Support Table 8.

  • Page 3: Introduction

    1. Introduction The 10.2” DV Signage widescreen monitor (model: MON-100W) is a single LCD display unit. The unit provides standard video interfaces (DVI, VGA, S-Video & Composite). The monitor is fit for control room information display or any other general purpose information display.

  • Page 4: System

    2. System 10.2” Monitor (MON-100W) A robust metal housing with powder coating: (2)  COM   Port (3)  On/Off   switch (4)  Status  LED (9)  DVI-­‐D  Input (7)  S-­‐Video  Input...
  • Page 5 Item Description Function Controlling the OSD menu OSD button function COM port For serial command control On/Off switch Power on/off switch of the unit Status LED Status LED Power in (DC 12V) DC 12V Power input Composite Video Input Composite Video Input S-Video Input S-Video Input Analog RGB Input...

  • Page 6: Instruction

    3. Instructions 3.1 Preparation The DV Signage monitor is designed to be as plug and play as possible requiring the minimum of setup for use. The following describes the operation of this monitor unit. Please make sure the whole package in the box includes the items below : 10.2”...

  • Page 7: Controls

    4. Controls Once the system has been connected and switched on there are a number of functions available to adjust the display image as summarized in the following sections. The settings chosen will be saved for each mode independently. 4.1 Button control Controls Functions Menu –...

  • Page 8: Osd Menu Function

    4.2 OSD menu functions Selection page Select input source4 Select input source to Analog RGB Select input source to DVI Select input source to S-Video 1 Select input source to Composite 1 Select input source to S-Video 2 (No function now) Select input source to Composite 2 (No function now) ON –...
  • Page 9 Adjust red color level Press – or + (- +) Total :128 steps Adjust green color level Press – or + (- +) Total : 128 steps Adjust blue color level Press – or + (- +) Total : 128 steps Press SEL UP/DN button to select item Set the color temperature to 4200K Set the color temperature to 5000K...

  • Page 10: Remote Control

    # - Function in ARGB mode only Exit the OSD menu to save the setting chosen 4.3 Remote control (Optional) BUTTON FUNCTION Soft power ON/OFF button. POWER BUTTON ATTENTION BUTTON Use combined with digit keys (“Attention” + “1”) to enable/disable the IR function. SEL UP ( ) / SEL DN ( Press this button to select the items in the OSD menu.

  • Page 11: Serial Control

    4.4 Serial control Connect the serial control cable to the monitor at COM port RS-232 Serial control (Baud rate 2400, 8 bits, 1 stop bit and no parity) Physical connection : Monitor side Connector interface : Serial port Mating connector : DB9 Female PIN# Description RS-232 Rx Data...

  • Page 12: Dimensions

    5. Dimensions...

  • Page 13: Specification

    6. Specification Page 13 of 22...

  • Page 14: Appendix I - Graphic & Video Mode Support Table

    7. Appendix I - Graphic & Video Mode Support Table ARGB & DVI INPUT PORT : Horizontal   Vertical   Mode   Resolution   Clk  [MHz]   Sync  Mode   freq  [KHz]   freq  [Hz]   E1_70 640x350 70Hz 25.175 31.469 70.087 Digital Separate Sync...
  • Page 15 COMPOSITE, S-VIDEO INPUT PORT : Horizontal  freq   Vertical  freq   System   Resolution   [KHz]   [Hz]   NTSC 720x480 15.7 NTSC 4.43 720x480 15.7 720x576 15.6 PAL M 720x576 15.6 SECAM 720x576 15.6 Page 15 of 22...

  • Page 16: Appendix Ii Auto Color Gain

    8. Appendix II Auto Color Gain The Auto Color Gain function is supported in the ARGB mode only and is designed to calibrate the controller to the incoming video signal. In order to calibrate correctly, the display must be displaying an image containing both black and white data (see illustration below) when the function is used.

  • Page 17: Serial Control Protocols

    9. Appendix III Serial control protocols Function   Command   Description   Acknowledge  (if  enabled)   Menu 0xf7 Menu button pressed Button equivalent Select-down 0xfa Select down button pressed Button equivalent button Select-up button 0xfb Select up button pressed Button equivalent Right/+ button 0xfc Right/+button pressed...
  • Page 18 Frequency 0x8b, Frequency = Frequency adjustment nnnn | “+” | “-“ | value/increment/decrement (In ARGB mode only) “?” Query OSD H position 0x90, Set osd_hpos = OSD horizontal position nnn | “+” | “-“ | “r” value/increment/decrement | “R” | “?” Reset Range: “0””0””0”-“3””E””8”...
  • Page 19 Red level for 0xb4, Set the level of the red Red level for selected colour selected colour channel for the selected temperature. temperature nn | “+” | “-” | colour temp. = “r” | “R” | value/increment/decrement Range: “8””0”-“F””F” “?” Reset Default: “F””F”...
  • Page 20 Wide Screen Mode 0xd9, Wide Screen Mode “0” – 1280x768 (Default) Selection “0” | “1” | ”2” | Reset “1” – 1360x768 “3” Query “2” – 1366x768 “r” | “R” | “3” – 1368x768 “?” # - Function in ARGB mode only Hex to ASCII conversion table ASCII ASCII...

  • Page 21: Warranty, Caution & Limitation Of Liability, Trademark

    10. Warranty The products are warranted against defects in workmanship and material for a period of one (1) year from the date of purchase provided no modifications are made to it and it is operated under normal conditions and in compliance with the instruction manual.

  • Page 22: Contact Details

    ASIA: floor Millennium City 3 370 Kwun Tong Road Kwun Tong Hong Kong Tel: (852) 2861 3615 Fax: (852) 2520 2987 Sales: hk@dvsignage.com Specifications subject to change without notice Revision 02, dated 24 Nov 2010 © DV Signage Ltd 2010...
