- Page 1 Pro-AV Monitor User Guide 32” PA-3200-0200-0xxx 40” PA-4000-0200-0xxx 46” PA-4600-0200-0xxx www.dvsignage.com...
- Page 2 Pro-AV Monitor User Guide | © DV Signage 2011...
-
Page 3: Table Of Contents
Contents Important Safeguards ROHS Notice Package Contents Set Up Procedure Monitor Operating Environment Monitor Connections Menu Functions IR Remote Specifications AC Power Mode Support Table ARGB Modes HDMI Port DisplayPort Monitor Dimensions Warranty Cautions Limitation of Liability Trademarks Contact Details www.dvsignage.com... -
Page 4: Important Safeguards
The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet Pro-AV Monitor User Guide | © DV Signage 2011... - Page 5 5. Power Sources - This display product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your location, consult your video dealer or local power company.
- Page 6 A. When the power supply cord or plug is damaged. B. If liquid has been spilled or objects have fallen into the display product. Pro-AV Monitor User Guide | © DV Signage 2011...
- Page 7 C. If the display product has been exposed to rain or water. D. If the display product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions. Improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the video product to its normal operation.
- Page 8 (B) Danger of explosion if battery is incorrectly replaced WARNING To prevent injury, this display product must be securely attach to the floor/wall in accordance with the manufacture installation instructions. Pro-AV Monitor User Guide | © DV Signage 2011...
-
Page 9: Rohs Notice
Declaration of RoHS Compliance This product has been designed and manufactured in compliance with Directive 2002/ /95/EC of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Certain components of products as stated above are exempted under the Annex of the RoHS Directives as noted below:... -
Page 10: Package Contents
2. Connect external equipment To protect the connected equipment, turn off the main power before making connections. Refer to your equipment user manual. Pro-AV Monitor User Guide | © DV Signage 2011... -
Page 11: Monitor Operating Environment
3. Connect the supplied power cord The power outlet socket should be installed as near to the equipment as possible, and should be easily accessible. NOTE: • Please refer to “Safety Precautions, Maintenance & Recommended Use” section of this manual for proper selection of the AC power cord. -
Page 12: Monitor Connections
PC with a VGA output Serial RS-232 serial interface. Used to load monitor operating code by qualified personnel. Contact your dealer for information Audio Out Speaker jacks. HDMI amplified output. Pro-AV Monitor User Guide | © DV Signage 2011... - Page 13 Menu Control Functions The monitor configuration can be controlled by either the IR remote control shipped with the monitor, or by the user buttons located on the rear of the cover. Turns On and Off the power to the monitor electronics. 1.
-
Page 14: Menu Functions
- or + Total : 100 steps Press - or + Total : 100 steps Gamma (0.4/0.6/1.0/1.6/2.2) Items marked Ṗ have sub menus. Exit the OSD menu to save the setting chosen Pro-AV Monitor User Guide | © DV Signage 2011... - Page 15 Display (Function in ARGB mode only) Auto Adjust Auto adjust the position, phrase, frequency Fine tune the data sampling position Phase (adjust image quality) Press [ – or + ] Total : 100 Increase/decrease sharpness level. Clock Press [- or + ] Total : 8 steps Display Position Adjust image position Sound...
-
Page 16: Ir Remote
Use to display the OSD menu and go to the next OSD screen. DISPLAY BUTTON Use to view an on-screen informa- tion. When OSD menu displayed, press this button to turn it off. Pro-AV Monitor User Guide | © DV Signage 2011... -
Page 17: Specifications
Specifications Screen Size 46” Diagonal 40” Diagonal 32” Diagonal Active Area 46”=1025.4 x 578.6mm, 40.37 x 22.77” 40”= 891.7 x 504.2mm, 35.1 x 19.85” 32”= 703.6 x 398.4mm, 27.7 x 15.68” Resolution 46”,=1920 x 1080 40” =1920 x 1080 32” = 366 x 768 Colors Up to 16.7M colors Brightness... -
Page 18: Ac Power
5. During lightning storms, or when the unit is not used for a long time, disconnect the power supply, antenna, and cables to protect the unit from elec- trical surge Pro-AV Monitor User Guide | © DV Signage 2011... - Page 19 Appendix I – Mode Support Table Horizontal Vertical Mode Resolution Clk [MHz] Sync Mode freq [KHz] freq [Hz] T_70 720x400 70Hz 28.322 31.469 70.087 Digital Separate Sync T_70 720x400 70Hz 28.322 31.469 70.087 Sync On Green V_60 640x480 60Hz 25.175 31.469 59.940 Digital Separate Sync...
-
Page 20: Hdmi Port
1920x1200 60Hz 193.2 74.5 1080p60 1920x1080p 60Hz 67.5 1080i60 1920x1080i 60Hz 74.14 33.7 1080i50 1920x1080i 50Hz 74.184 28.1 720p60 1280x720P 60Hz 74.25 576p50 720x576P 50Hz 26.9568 31.2 480p60 720x480P 60Hz 26.9568 31.4 Pro-AV Monitor User Guide | © DV Signage 2011... -
Page 21: Displayport
DisplayPort Horizontal freq Mode Resolution Clk [MHz] Vertical freq [Hz] [KHz] T_70 720x400 70Hz 28.322 31.469 70.087 V_60 640x480 60Hz 25.175 31.469 59.940 SV_60 800x600 60Hz 40.000 37.879 60.317 X_60 1024x768 60Hz 65.000 48.363 60.004 SX_60 1280x1024 60Hz 63.81 60.020 UX_60 1600x1200 60Hz 75.000... -
Page 22: Monitor Dimensions
LANDSCAPE LANDSCAPE LANDSCAPE LANDSCAPE PORTRAIT Fig 1. 46” Monitor 336.4 [13.24] 126 [4.96] 1,094.2 [43.077] 1,025.4 [40.370] 46” 638.14 [25.124] 578.6 [22.780] 29.8 [1.172] 34.4 [1.353] 395 [15.55] Pro-AV Monitor User Guide | © DV Signage 2011... - Page 23 LANDSCAPE LANDSCAPE LANDSCAPE LANDSCAPE PORTRAIT Fig 2. 40” Monitor 922.9 [36.333] 891.7 [35.106] 40” 535.4 [21.077] 504.2 [19.850] 15.6 [.613] 129.8 [5.11] www.dvsignage.com...
- Page 24 Note: The mounting for the VESA 400mm footprint on the 32” model is not centrally located. Review the dimensions before installing. 120.3 [4.73] 57.2 [2.25] 771.7 [30.380] 461.7 398.4 [15.685] 32” [18.176] 31.6 [1.246] 703.6 [27.701] [1.340] [4.72] 336.4 [13.24] 395 [15.55] Pro-AV Monitor User Guide | © DV Signage 2011...
-
Page 25: Mounting The Monitor
Mounting the Monitor The monitors each provides two sets of mounting points: 400mm x 400mm VESA: On the rear panel of the monitor a 400 x 400 mm VESA standard mounting pattern is provided. Mounting screw size M6 600 x 200mm VESA: The monitor also supports mounting points on the rear panel suitable for use with a wide range of wall mounts. -
Page 26: Warranty
Pro-AV Monitor User Guide | © DV Signage 2011... -
Page 27: Cautions
Disclaimer: DV Signage shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 28: Contact Details
18440 Technology Dr. Building 130 Morgan Hill, CA 95037, USA T: +1-408-782-7773 | F: +1-408-782-7883 info@dvsignage.com Europe DV Signage Europe GmbH. Landshuter Allee 162a, D 80637 Munich Germany T: +49-(0)89 143 47 52-0 | F: +49-(0)89 143 47 52-30 info@dvsignage.eu DV Signage Ltd.
