DV Signage POP-15N (M3-330) User Manual

Popstyle 15.6” network display
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

User Guide

PopStyle 15.6" Network Display
POP-15N (M3-330) | Version 1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POP-15N (M3-330) and is the answer not in the manual?

Questions and answers

Related Manuals for DV Signage POP-15N (M3-330)

Summary of Contents for DV Signage POP-15N (M3-330)

  • Page 1: User Guide

    User Guide PopStyle 15.6” Network Display POP-15N (M3-330) | Version 1.1...
  • Page 2 Revision History Amendment Date Version May 31, 2013 V1.0 Page 2 of 14...

  • Page 3: Table Of Contents

    Table of Contents 1 Introduction ..................4 2 System .................... 5 3 Instructions ..................6 3.1 Preparation ....................6 3.2 SD card ......................6 3.3 Slide switch ....................7 3.4 Powering On ....................7 3.5 Autoplay / Manual Playback at power startup ......... 7 3.6 Playback modes ...................

  • Page 4: Introduction

    Introduction The DV Signage 15.6” PopStyle is a self-contained LCD display and network digital media player for continuous (looped) playback of video stored on a SD card. The unit comprises a widescreen 15.6” color TFT LCD, a RJ-45 LAN port and optional touch screen. A range of other accessories and factory installed customization options are also available, these are not to be covered in this manual.

  • Page 5: System

    System 15.6” PopStyle (POP-15N-OF) Page 5 of 14...

  • Page 6: Instructions

    SD card – see following note 3.2 SD card The DV Signage PopStyle uses standard SD cards to store the media (video, still images) for playback. The following are key points to note: The format of the digital media stored on the SD card needs to meet certain standards as per the specifications for this device as summarized in section 5.

  • Page 7: Slide Switch

    See the following section for Power On options. 3.5 Autoplay at power startup The DV Signage PopStyle supports AutoPlay modes at power startup AutoPlay: This is the default mode for the unit. This means that upon power-on video will start playing in accordance with a playlist (if DV Studio was used to transfer the media files to the SD card) or in alpha-numeric order (if the media files were simply copied to the SD card).

  • Page 8: Osd Configuration Mode

    Simple play mode, i.e. files copied to SD card without using DV Studio: In simple play mode, the user just copies all video files (.mpg) or JPEG files (.jpg) onto the SD card. The PopStyle will play these files in alphabetical sequence. For JPEG files, the play time is determined by the last digit of the filename.

  • Page 9: Network Setup

    3.8 Network setup Each PopStyle is shipped with DHCP settings (IP=0.0.0.0). In some network environment, fixed IP could be used and you may need to change the PopStyle with the fixed IP settings. All IP settings are set in a configuration file called “netcfg.ini”. To change the IP settings on PopStyle, copy the netcfg.ini file with your setting on to MEDIA folder on SD card and restart the PopStyle then you will see a boot up message with your IP information changed.
  • Page 10 [Default: 1440] Stop playing End of Day DAILY_END_TIME_ENABLE 0 = disable 1 = enable [Default] Change IP settings on player IP_OVERWRITE 0 = Keep the old IP settings on player [Default] 1 = Overwrite with new IP settings on player IP address 0.0.0.0 = DHCP mode [Default: 0.0.0.0]...

  • Page 11: Dimensions

    Dimensions Unit in mm PopStyle 15.6” OpenFrame (POP-15N-OF) Page 11 of 14...

  • Page 12: Specification

    Specification POP-15N-OF (M3-330) Specification: Playback video format MPEG-2 (.mpg)@3Mbit/s - Recommended JPEG (.jpg) up to 1280x720 Note: Depending on the features desired, customer/purchaser may be required to obtain a video codec license with the relevant organizations Video storage SD cards LCD display Color TFT Screen size...

  • Page 13: Dv Signage

    The manufacturer’s liability for damages to customer or others resulting from the use of any product supplied hereunder shall in no event exceed the purchase price of said product. TRADEMARKS The following are trademarks of DV Signage : DV Signage Video Flyer / PopStyle...

  • Page 14: 370 Kwun Tong Road

    ASIA: floor Millennium City 3 370 Kwun Tong Road Kwun Tong Hong Kong Tel: (852) 2861 3615 Fax: (852) 2520 2987 Sales: hk@dvsignage.com Specifications subject to change without notice Document No. 916330410 © DV Signage 2013 Page 14 of 14...
