Page 1: Installation Manual
INSTALLATION MANUAL Installation Manual English Split Type Unit Models ACQ 71 AV1 ACQ 100 AV1 ACQ 125 AV1 IM-5CKYER-0411(0)-SIESTA Part No.: R08019036183... -
Page 3: Outline And Dimensions
OUTLINE AND DIMENSIONS Indoor Unit ACQ 71 / 100 / 125 AV1 All dimensions are in mm Dimension Model ACQ 71 AV1 ACQ 100 AV1 / ACQ 125 AV1... -
Page 4: Safety Precautions
INSTALLATION MANUAL This manual provides the procedures of installation to ensure a safe and good standard of operation for the air conditioner unit. Special adjustment may be necessary to suit local requirements. Before using your air conditioner, please read this instruction manual carefully and keep it for future reference. This appliance is intended to be used by expert or trained users in shops, in light industry and on farms, or for commercial use by lay persons. -
Page 5: Installation Diagram
INSTALLATION DIAGRAM Indoor Unit Drain Piping Thermal Insulation Wrap the insulated pipe with the fi nishing tape from bottom to top Front Panel Air Filter (behind the grille) Air Intake Grille Air Discharge Louver To Outdoor Unit... -
Page 6: Installation Of The Indoor Unit
INSTALLATION OF THE INDOOR UNIT Preliminary Site Survey Be sure to read this manual before installing the air-conditioner indoor unit. • Voltage supply fl uctuation must not exceed ±10% of rated voltage. Electricity supply lines must be independent of welding transformers which can cause high supply fl... -
Page 7: Panel Installation
Drain Pump Work • Drain pipe must be in downward gradient for smooth drainage. • Avoid installing the drain pipe in up and down slope to prevent reversed water fl ow. • During the drain pipe connection, be careful not to exert extra force on the drain connector at indoor unit. - Page 8 Cover Lock Grille (The moving part protection for user direct touching) Cover lock grill must be installed as the fi gure below. Frame Intake Grille Cover Lock Grille (2pcs) Screw M4 x 6 (2pcs) If the unit need to be service, steps below shall be followed: 1.
- Page 9 Wires Installation Figure 1 Figure 1 and Figure 2 shows the location of cover wire in Indoor unit. Steps to install power supply wires and wires from outdoor unit. 1. Remove wire cover by removing 2 screws as shown in Figure 3. 2.
- Page 10 Piping Works And Flaring Technique • Do not use contaminated or damaged copper tubing. If any pipings, evaporator or condenser had been exposed or had been opened for 15 seconds or more, the system must be vacuumed. Generally, do not remove plastic, rubber plugs and brass nuts from the valves, fi...
-
Page 11: Special Precautions When Dealing With R410A Unit
• All wires must be fi rmly connected. • Make sure all the wire do not touch the refrigerant pipings, compressor or any moving parts. • The connecting wire between the indoor unit and the outdoor unit must be clamped by using provided cord anchorage. •... -
Page 12: Accessory Parts
ACCESSORY PARTS Short Duct Specifi cation • The indoor unit is provided with air discharge and air intake “knock-out” hole for duct connection. However the connection of the short duct for air discharge is possible on only one side. • The use of short duct for air discharge will improve airfl... - Page 13 MEMO / LE MÉMO / MITTEILUNG / MEMO / EL MEMORÁNDUM / ПАМЯТКА / NOT / ΣΗΜΕΙΩΜΑ / MEMO...
- Page 14 3PW54723-19J...
- Page 16 In the event that there is any confl ict in the interpretation of this manual and any translation of the same in any language, • the English version of this manual shall prevail. • The manufacturer reserves the right to revise any of the specifi cation and design contain herein at any time without prior notifi...
