- Page 1 Type d’unité Split Installationshandbuch Deutsch Split Typ Einheit Installatiehandleiding Nederlands Werdelen Drukletter Eenheid Manual De Instalación Español Escisión tipos Unidades Models AHQ71AV1 Руководство по установке Русский Блок Раздельного Типа AHQ100AV1 Kurulum kılavuzu AHQ125AV1 Türkçe Ayrılma Tipi Üniteleri AHQ140AV1 Εγχειρίδιο Εγκατάσταση...
-
Page 3: Outline And Dimensions
OUTLINE AND DIMENSIONS Indoor Unit AHQ71AV1 All dimensions are in mm Dimension Model AHQ71AV1 1080 Indoor Unit AHQ100/125AV1 All dimensions are in mm Dimension Model AHQ100AV1 1490 1308 1538 AHQ125AV1 1738 1556 1786... - Page 4 Indoor Unit AHQ140AV1 All dimensions are in mm Dimension Model AHQ140AV1 1750 1903 1830 1880...
-
Page 5: Safety Precautions
INSTALLATION MANUAL This manual provides the procedures of installation to ensure a safe and good standard of operation for the air conditioner unit. Special adjustment may be necessary to suit local requirements. Before using your air conditioner, please read this instruction manual carefully and keep it for future reference. This appliance is intended to be used by expert or trained users in shops, in light industry and on farms, or for commercial use by lay persons. -
Page 6: Preliminary Site Survey
Air Intake Grille Bottom Panel Air Filters (Inside Air Intake Grille) TO OUTDOR UNIT INSTALLATION OF THE INDOOR UNIT (AHQ71AV1) Preliminary Site Survey Standard Mounting • Voltage supply Á uctuation must not exceed ±10% of the Ensure that the overhead supports are strong enough to hold rated voltage. - Page 7 Please ensure that the following steps are taken: • Unit installation should be tilted at least 10mm as recommended in Figure B. • The drain pipe slope shall be kept at least 1:100. • Provide clearance for easy servicing and optimal air Á ow as shown in Figure C. •...
- Page 8 UNDER CEILING INSTALLATION (AHQ71AV1) Install the Suspension Bolts Install the suspension bolts so that it can support the indoor unit. Adjust distance to ceiling before installation. Refer to the dimension given to install the unit. Install the Indoor Units Insert the suspension bolts into the À ttings of the hanger bracket.
- Page 9 Refer to the dimension as illustrated when installing the mounting bracket. When installing the rear piping, determine the pipe hose position. Drill the pipe hole at the slight downward slant to the outdoor side. Mounting Bracket Hook the unit on the mounting bracket Wall Piping and Drain Hose Installation (Under Ceiling Type)
- Page 10 How to Remove Air Inlet Grille Remove the air inlet grille by both hands as the direction Move the air inlet grille upward, and then turn it backwards. shown. (Do not use too much force). Loosen the screw for À xing the panel arm (3 screw, left, Remove the grille holder (both left and right side).
- Page 11 INSTALLATION OF FRESH AIR INTAKE (AHQ71AV1) Knock out the fresh air intake hole at the top panel. Assemble the axial fan, fresh air adapter, À lter and dust hose as shown in À gure below. TOP PANEL ASSY. FRESH AIR ADAPTER 2"...
- Page 12 INSTALLATION DIAGRAM (AHQ100/125AVI) Air Discharge Louver Signal Receiver Indicator Light Wrap the Insulated pipe with the À nishing tape from bottom to top Air Intake Grille Air Filters (Inside Air Intake Grille) TO OUTDOOR UNIT INSTALLATION OF THE INDOOR UNIT (AHQ100/125AV1) Preliminary Site Survey Standard Mounting •...
- Page 13 Figure E Please ensure that the following steps are taken: • Unit installation should be tilted at least 10mm as recommended in Figure E. • The drain pipe slope shall be kept at least 1:100. • Provide clearance for easy servicing and optimal air Á ow as shown in Figure F. •...
- Page 14 UNDER CEILING INSTALLATION (AHQ100/125AV1) Install Suspension Bolts Install Indoor Units Install the suspension bolts so that it can support the Insert the suspension bolts into the À ttings of the hanger indoor unit. bracket. Adjust distance to ceiling before installation. Set the nuts and washer on both side of the metal Refer to dimension given to install the unit.
-
Page 15: Installation - Ceiling Exposed Type
Installation - Ceiling Exposed Type Step 1 Remove air intake grille, side panel and hanger bracket from the unit. Please refer to Figure J. Figure J Hanger Bracket Side Panel Intake grille Step 2 Position the hanger rod as shown in Figure K and install the hanger bracket. Figure K Step 3 Hang up the unit and tighten the bolts after installation of piping and drain pipe. -
Page 16: Piping And Drain Hose Installation
Figure M Piping and Drain Hose Installation Figure N Drain Hose Steps to open intake grille Unlock the screw attached to block lock grille with screwdriver. Remove block lock grille and unlock grille lock. Please refer to Figure P for reference. Figure P Block Lock Grille Screw (M4) - Page 17 INSTALLATION DIAGRAM (AHQ140AV1) Wrap the Insulated pipe with the À nishing tape from bottom to top Air Discharge Louver Air Discharge Grille Signal Receiver Indicator Light Air Intake Grille Air Filters (Inside Air Intake Grille) TO OUTDOOR UNIT INSTALLATION OF THE INDOOR UNIT (AHQ140AV1) Preliminary Site Survey •...
- Page 18 Please ensure that the following steps are taken: • Unit installation should be tilted/slanted at least 10mm as recommended in Figure Q. • The drain pipe slope shall be kept at least 1:100. • Provide clearance for easy servicing and optimal air Á ow as shown in Figure R. •...
- Page 19 Piping Works And Flaring Technique • Do not use contaminated or damaged copper tubing. If any pipings, evaporator or condenser had been exposed or had been opened for 15 seconds or more, the system must be vacuumed. Generally, do not remove plastic, rubber plugs and brass nuts from the valves, À...
-
Page 20: Special Precautions When Dealing With R410A Unit
All wires must be À rmly connected. • • Make sure all the wire do not touch the refrigerant pipings, compressor or any moving parts. • The connecting wire between the indoor unit and the outdoor unit must be clamped by using provided cord anchorage. •... - Page 21 MEMO / LE MÉMO / MITTEILUNG / MEMO / EL MEMORÁNDUM / / MEMO ПАМЯТКА ΣΗΜΕΙΩΜΑ...
- Page 22 25 Z tamamen kendi sorumluluğunda olmak üzere bu bildirinin ilgili olduğu klima modellerinin aşağıdaki gibi olduğunu beyan eder: AHQ71AV1, AHQ100AV1, AHQ125AV1, AHQ140AV1, 01 are in conformity with the following standard(s) or other normative document(s), provided that these are used in accordance with our 08 estão em conformidade com a(s) seguinte(s) norma(s) ou outro(s) documento(s) normativo(s), desde que estes sejam utilizados de...
- Page 24 In the event that there is any confl ict in the interpretation of this manual and any translation of the same in any language, • the English version of this manual shall prevail. The manufacturer reserves the right to revise any of the specifi cation and design contain herein at any time without prior •...
