INSTRUCTION MANUAL
Ver 2.1
|
ANTIVANDAL 10x IP SPEED DOME CAMERA
MPEG4 with Motion Tracking
Firmware Ver. 1.2.1a

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ANTIVANDAL 10x IP SPEED DOME CAMERA and is the answer not in the manual?

Questions and answers

Related Manuals for Videcon ANTIVANDAL 10x IP SPEED DOME CAMERA

Summary of Contents for Videcon ANTIVANDAL 10x IP SPEED DOME CAMERA

  • Page 1 INSTRUCTION MANUAL Ver 2.1 ANTIVANDAL 10x IP SPEED DOME CAMERA MPEG4 with Motion Tracking Firmware Ver. 1.2.1a...
  • Page 2 This lightning flash with arrowhead symbol is intended to alert the user to the presence of un-insulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. This exclamation point symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

  • Page 3: Important Safeguard

    NOTICE Important Safeguard Read Instructions Read all of the safety and operating instructions before using the product. Retain Instructions Save these instructions for future reference. Attachments / Accessories Do not use attachments or accessories unless recommended by the appliance manufacturer as they may cause hazards, damage product and void warranty.

  • Page 4: Table Of Contents

    CONTENTS ○ Introduction Features About Network Function Product & Accessories Parts Name & Functions ○ Installation DIP Switch Setup Installation using Surface mount on the Ceiling Installation using Flush Mount Ring Bracket Installation using Ceiling Mount Bracket Installation using Wall Mount Bracket Cabling ○...
  • Page 5 CONTENTS ○ Network Setup DDNS Registration Quick Start of Network Connection Initial Setup via a Crossover Cable Guide to Network Setup Case A : Dynamic IP or PPPoE + Personal Router Case B : Static(Fixed) IP + Personal Router Case C : Static(Fixed) IP Case D : Dynamic IP + DSL/Cable Modem Case E : PPPoE + DSL Modem Port Forwarding...

  • Page 6: Introduction

    INTRODUCTION Features  Network Video Interface High frame are using hardware MPEG4 compression.  High frame rate with superior Video Quality  High speed : 30 fps at 720 x 480, 25 fps at 720 x 576  Web Browser based Viewer & i-Pro Multi Viewer supported. ...
  • Page 7 INTRODUCTION  Preset, Pattern,VST, Group, Privacy Mask, Schedule and More…  MAX. 127 Presets are assignable and characteristics of each preset can be set up independently, such as White Balance, Auto Exposure, Label and so on. Max. 8 set of VST action can be stored. This enables to move camera repetitively between two ...

  • Page 8: About Network Function

    INTRODUCTION About Network Function This product is only compatible with current versions of the Microsoft Windows OS.  This product operates with Microsoft’s Internet Explorer only.  You must have ActiveX controls enabled on your browser, found in the Options menu. ...

  • Page 9: Product & Accessories

    INTRODUCTION Product & Accessories  Product & Accessories  Main Body  Surface Mount Bracket  Screws & Terminal Block  Crossover Cable  Options  Ceiling Mount Bracket  Wall Mount Bracket  Flush Mount Ring Bracket 9/96 ANTI-VANDAL 10x SPEED DOME CAMERA...

  • Page 10: Parts Name & Functions

    INTRODUCTION Parts Name & Functions  Main Unit / Surface Mount Bracket  Back of Main Unit  Dome Cover Do not detach protection vinyl from dome cover before finishing all installation process to protect dome cover from scratches or dust. ...
  • Page 11 INTRODUCTION  LINK LED This green indicator should be flashing or glowing during normal operation. During a reboot or power cycling, it may take up to 50 seconds to initialize, negotiate your network speed, and begin operation at 10 or 100Mbps. If this light is not lit after 50 seconds of operation, check the network cable to ensure a proper connection.

  • Page 12: Installation

    INSTALLATION DIP Switch Setup Before you install the camera, you should set the DIP switches to configure the camera ID, communication protocol.  Camera ID Setup  ID number of camera is set using binary number. The example is shown bellow. ID Value ex) ID=5 ex) ID=10...
  • Page 13 INSTALLATION  Communication Protocol Setup Select the appropriate Protocol with DIP switch combination.  Switch State Protocol (Pin 1) (Pin 2) PELCO-D, 2400 bps PELCO-D, 9600 bps PELCO-P, 4800 bps PELCO-P, 9600 bps If you want to control using DVR or P/T controller, their protocol must ...

  • Page 14: Installation Using Surface Mount On The Ceiling

    INSTALLATION Installation using Surface mount on the Ceiling ① To pass cables to upside of ceiling, please, make ② Screw surface mount bracket to ceiling with 4 about φ60mm hole on the ceiling panel. screws. ③ Wire cables to terminal block and connect the ④...

  • Page 15: Installation Using Flush Mount Ring Bracket

    INSTALLATION Installation using Flush Mount Ring Bracket ① To pass cables to upside of ceiling, please, make ② Screw surface mount bracket to ceiling with 4 about φ170mm hole on the ceiling panel. screws. ③ Wire cables to terminal block and connect the ④...

  • Page 16: Installation Using Ceiling Mount Bracket

    INSTALLATION Installation using Ceiling Mount Bracket ① Screw ceiling mount bracket to ceiling with 3 ② Wire cables to terminals and connect the screws. terminals to main unit. Do not use surface mount bracket! ③ Screw main unit to ceiling mount bracket with 4 ④...

  • Page 17: Installation Using Wall Mount Bracket

    INSTALLATION Installation using Wall Mount Bracket ① Screw wall mount bracket to ceiling with 3 ② Wire cables to terminals and connect the screws. terminals to main unit. Do not use surface mount bracket! ③ Screw main unit to wall mount bracket with 4 ④...

  • Page 18: Cabling

    INSTALLATION Cabling  Power Connection Please, check the voltage and current capacity of rated power carefully. Rated power is indicated in the  back of main unit. Rated Power Input Voltage Range Current Consumption DC 12V DC 11V ~ 18V 0.8 A ...
  • Page 19 INSTALLATION  Ethernet Connection Connect with RJ-45 cable.   Alarm Input Connection Sensor Input  Before connecting sensors, check driving voltage and output signal type of the sensor. Since output signal types of the sensors are divided into Open Collector and Voltage Output type in general, the cabling must be done properly after considering these typed.

  • Page 20: Operation

    OPERATION Check points before operation Before power is applied, please check the cables carefully.  The camera ID of the controller must be identical to that of the target camera. The camera ID can be checked  by reading DIP switch of the camera. If your controller supports multi-protocols, the protocol must be changed to match to that of the camera.

  • Page 21: Starting Osd Menu

    OPERATION Starting OSD Menu  Function Using the OSD menu, Preset, Pattern, VST, Group and Alarm Input function can be configured for each application.  Enter Menu <Go Preset> [95] Reserved Preset  Description Some Preset numbers are reserved to special functions. ...

  • Page 22: Preset

    OPERATION Preset  Function Max. 127 positions can be stored as Preset position. The Preset number can be assigned from 1 to 128, but 95 is reserved for starting OSD menu. Camera characteristics (i.e. White Balance, Auto Exposure) can be set up independently for each preset.

  • Page 23: Pattern

    OPERATION Pattern  Function Pattern Function is that a camera memorizes the path (mostly curve path) by joystick of controller for assigned time and revives the path exactly as it memorized. 4 Patterns are available and Maximum 1200 communication commands can be stored in a pattern.

  • Page 24: Group

    OPERATION Group  Function The group function allows running sequence of Presets, Pattern and/or VSTs. Max 8 group can be stored. Each group can have max 20 action entities which can be preset, pattern or VST. Preset speed can be set up and the repeat number of Pattern & VST can be set up in Group setup.

  • Page 25: Schedule

    OPERATION Schedule  Function The Schedule function allows running an appropriate function like Preset, VST, Group, Pattern, Home move at designated day and time. For example, if you setup a rule Tuesday at 9:00AM and Preset 1 (say Main Gate), the camera will move to main gate every Tuesday at 9:00AM.

  • Page 26: Other Functions

    OPERATION Other Functions  Power Up Action This function enables to resume the last action executed before power down. Most of actions such as Preset, Pattern, VST and Group are available for this function but Jog actions are not available to resume. In case that tilt angle arrives at the top of tilt orbit (90°), zoom module camera keep ...

  • Page 27: Osd Display Of Main Screen

    OPERATION OSD Display of Main Screen  P/T/Z Information Current Pan/Tilt angle in degree, zoom magnification and a compass direction.  Camera ID Current Camera ID(Address).  Action Title Followings are possible Action Titles and their meaning. "SET PRESET " When Preset ...

  • Page 28: How To Use Osd Menu

    HOW TO USE OSD MENU General Rules of Key Operation for Menu The menu items surrounded with ( ) always has its sub menu.  For all menu level, to go into sub menu, press NEAR key.  To go to up-one-level menu, press FAR key. ...

  • Page 29: Display Setup

    HOW TO USE OSD MENU Display Setup This menu defines Enable/Disable of OSD display on Main Screen. If an item is set to be AUTO, the item is displayed only when the value of it is changed.  Camera ID [ON/OFF] ...

  • Page 30: Privacy Zone Mask Setup

    HOW TO USE OSD MENU Privacy Zone Mask Setup Select area in image to mask.  Mask No [1~4] Select Mask number. If the selected mask has already data, camera moves as it was set. Otherwise, “UNDEFINED” will be displayed under “Mask NO”.

  • Page 31: Motion Setup

    HOW TO USE OSD MENU Motion Setup Setup the general functions of Pan/Tilt motions.  Preset Lock [ON/OFF] If Motion Lock is set to ON, it is impossible to set up and delete Preset, VST, Pattern and Group. It is possible only to run those functions.
  • Page 32 HOW TO USE OSD MENU  Parking Action Setup If Park Enable is set to ON, camera runs assigned function automatically if there is no PTZ command during assigned "Wait Time".  Park Enable [ON/OFF]  Wait Time [1 minute ~ 4 hour] The time is displayed with "hh:mm:ss"...

  • Page 33: Function Setup

    HOW TO USE OSD MENU Function Setup Configure 5 Special Functions with this menu FUNCTION SETUP  Preset Setup 127 Presets from the number 1 to 128 can be -------------------------------------- <PRESET SETUP> assigned excluding preset 95 reserved for <VST SETUP> <PATTERN SETUP>...

  • Page 34: Preset Setup

    HOW TO USE OSD MENU Preset Setup  Preset Number [1~128] If a selected preset is already defined, camera moves to pre-defined position and preset characteristics such as Label and Relay Outputs show on monitor. If a selected preset is not defined,“UNDEFINED”...
  • Page 35 HOW TO USE OSD MENU  Edit Preset Scene Using Joystick, move camera to desired position. ○ By pressing NEAR key, save current PTZ data. ○ Press FAR key to cancel. ○  Edit Preset Label Edits label to show on monitor when camera arrives at presets. In ①...

  • Page 36: Vst Setup

    HOW TO USE OSD MENU VST Setup  VST Number [1~8] VST SETUP ------------------------------------- Selects VST number to edit. If a selected VST has VST NO. not defined, "NOT USED" is displayed in 1st 1ST POS. PRESET 5 2ND POS. PRESET 6 Position and 2nd Position VST SPEED...

  • Page 37: Pattern Setup

    HOW TO USE OSD MENU Pattern Setup  Pattern Number [1~4 ] Selects Pattern number to edit. If a selected pattern number is not defined, "UNDEFINED" will displayed under selected pattern number.  Clear Pattern [CANCEL/OK] Deletes data in current pattern ...

  • Page 38: Group Setup

    HOW TO USE OSD MENU Group Setup  Group Number [1~8] Selects Group number to edit. If a selected Group number is not defined, "UNDEFINED" will be displayed under selected Group number.  Clear Group [CANCEL/OK] Deletes data in current Group ...
  • Page 39 HOW TO USE OSD MENU ④ Set up items such as Action, ###, Dwell and OPT. ⑤ After finishing setting up an Action, press Near key to one-upper- level menu (Step ②). Move cursor Up/Down to select Action number and repeat Step ② ~ Step ④ to edit selected Group. ⑥...

  • Page 40: Schedule Setup

    HOW TO USE OSD MENU Schedule Setup  Master Enable [ON/OFF] Decide whether Schedule function is active or not.  Clear Group [CANCEL/OK] Delete all data in current Menu  Edit Group Start editing Group.  Edit Schedule ④ After move the Cursor to the number by using Up/Down keys, press “Near”(Enter) Key to edit.

  • Page 41: Camera Setup

    HOW TO USE OSD MENU Camera Setup Setup the general functions of zoom camera module.  Focus Mode [AUTO/MANUAL/SEMIAUTO] Sets camera focus mode.  SEMIAUTO Mode This mode exchanges focus mode automatically between Manual Focus mode and Auto Focus mode. Manual Focus mode activates...
  • Page 42 HOW TO USE OSD MENU  Auto Exposure Setup  Backlight [ON/OFF] Sets Backlight Compensation  Day/Night [AUTO1/AUTO2/DAY/NIGHT] AUTO1 exchanges Day/Night mode faster than AUTO2.  Brightness [0~100] Adjusts brightness of images. Iris, Shutter Speed Gain adjusted automatically correspondence with this value. ...

  • Page 43: System Setup

    HOW TO USE OSD MENU System Setup  FAN RUN TEMP Above this temperature, the blower fan will start automatically. Range: 30 ~ 125℃ (86 ~ 257℉)  HEATER RUN TEMP Bellow this temperature, the Heater will be tuned on automatically. Range: -55 ~ 20℃...

  • Page 44: System Initialize

    HOW TO USE OSD MENU System Initialize  Clear All Data Deletes all configuration data such as display, camera, motion setup and so on.  Clear Display Set Initializes Display Configuration  Clear Camera Set Initializes Camera Configuration  Clear Motion Set Initializes Motion Configuration ...

  • Page 45: Anti-Vandal 10X Speed Dome Camera

    NETWORK SETUP DDNS Registration If you have DYNAMIC IP service from your Internet Service Provider (ISP), you can’t tell what current IP address of IP Speed Dome Camera is. To solve this problem, you have to register to our DDNS service. At first, we recommend, you have to check if you are using dynamic addressing.

  • Page 46: Quick Start Of Network Connection

    NETWORK SETUP Quick Start of Network Connection Please follow the steps below to complete the initial setup of the Network Function.  Please do not power on the IP Speed Dome until instructed.  Temporarily disable any proxy servers configured in Internet Explorer. ...
  • Page 47 NETWORK SETUP ⑪ Configure the IP Speed Dome’s TCP/IP settings as you would any other PC on your network, providing a proper IP address, subnet mask, default gateway, and DNS server.  If this is standalone unit with a direct connection to a cable/DSL/Broadband modem then input the addresses you have received from your ISP.

  • Page 48: Initial Setup Via A Crossover Cable

    NETWORK SETUP Initial Setup via a Crossover Cable This section provides a guide on how to connect the IP Speed Dome to your PC/laptop for initial setup. Please follow the instructions in the order they appear, without skipping steps. Do not supply power to the IP Speed Dome, until instructed.
  • Page 49 NETWORK SETUP ⑥ Now you will be able to access the viewer software within the IP Speed Dome.  Open Internet Explorer and type the IP address of 192.168.1.80 (default IP of the IP Speed Dome from the factory) into the Address Bar of the web browser (as seen below). Press Enter.
  • Page 50 NETWORK SETUP ⑧ The default ID and Password are both the word “admin” (without the “”) ⑨ If at any time you are prompted to download ActiveX controls, you must click ‘Yes’, all content is safe.  You will have to click “Yes” twice to two individual prompts. This allows your video to be displayed in Internet Explorer.

  • Page 51: Guide To Network Setup

    NETWORK SETUP Guide to Network Setup Please configure the IP Speed Dome at the location of its installation. You must determine your network scenario in order to configure the IP Speed Dome with the proper TCP/IP settings. This tutorial will guide you through the process.

  • Page 52: Case A : Dynamic Ip Or Pppoe + Personal Router

    NETWORK SETUP ⑤ Depicted below are several basic network scenarios. Determine which scenario describes your network. If your network does not match one of the scenarios below and are unsure how to setup your IP Speed Dome, please contact your network administrator, then call our Support Center.
  • Page 53 NETWORK SETUP  192.168.0.1 [Example]  Default Gateway  This IP address must be the IP address of your router (private or LAN side)  Use the same Default Gateway you noted under “Current TCP/IP Settings”  Use the 1st DNS Server from “Assigned IP Address from My ISP” ...

  • Page 54: Case B : Static(Fixed) Ip + Personal Router

    NETWORK SETUP Case B : Static(Fixed) IP + Personal Router [Efficient] Configure your IP Speed Dome's TCP/IP properties as follows :  STATIC  Network Type  A private IP address such as 192.168.0.200 [Example]  Internet Address  You need to assign the IP Speed Dome an IP address, just as you would assign a PC.
  • Page 55 NETWORK SETUP  8888  Web Server Port  Do NOT use the default port 80, you must change this number.  You may select any number between 1025 ~ 30000.  7777  Control Server Port  You may select any number between 1025 ~ 30000. ...

  • Page 56: Case C : Static(Fixed) Ip

    NETWORK SETUP Case C : Static(Fixed) IP [Dedicated line directly to the IP Speed Dome] Configure your IP Speed Dome's TCP/IP properties as follows :  STATIC  Network Type  A static IP address received from your ISP, such as 24.107.88.125 [Example] ...
  • Page 57 NETWORK SETUP  7778  Video Server Port  You may select any number between 1025 ~ 30000.  7779  Audio Transmit Server Port  You may select any number between 1025 ~ 30000.  7780  Audio Receive Server Port ...

  • Page 58: Case D : Dynamic Ip + Dsl/Cable Modem

    NETWORK SETUP Case D : Dynamic IP + DSL/Cable Modem [Connected directly to the IP Speed Dome] Configure your IP Speed Dome's TCP/IP properties as follows :  DYNAMIC  Network Type  Use the DDNS server  DDNS Server ...

  • Page 59: Case E : Pppoe + Dsl Modem

    NETWORK SETUP Case E : PPPoE + DSL Modem [Connected directly to the IP Speed Dome] Configure your IP Speed Dome's TCP/IP properties as follows :  PPPoE  Network Type  Use the User ID or Username you received from your ISP for this direct ...

  • Page 60: Port Forwarding

    NETWORK SETUP Port Forwarding After entering the correct TCP/IP settings you will be ready for “Port Forwarding” (Cases A, B).  Please record the TCP/IP settings of your IP Speed Dome for future reference. You may need this information to access your IP Speed Dome and to configure “Port Forwarding”. IP Speed Dome TCP/IP Settings IP Address Subnet Mask...

  • Page 61: Starting Ip Speed Dome

    NETWORK SETUP Starting IP Speed Dome After correctly forwarding the Web Server Port , Video Server Port, Control Server Port and two Audio Ports through your router (if applicable), you may then install the IP Speed Dome in a proper location. ①...

  • Page 62: Web Viewer

    WEB VIEWER Web Viewer Screen In this section, the main GUI of the IP Speed Dome will be explained.  General Tab ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○...
  • Page 63 WEB VIEWER Zoom, Focus, and Iris controls for the camera connected to IP Speed Dome. If you drag the each handle, ○ Zoom, Focus, and Iris are adjusted individually according to your mouse motion. Tap to switch General or Special function controls. The picture above shows controls when general ○...
  • Page 64 WEB VIEWER  Special Tab ○ ○ ○ ○ ○ ○ ○ ○ ○ Tab to switch General controls. ○ Click it to create new map automatically. Before creating new map, please, make sure Camera model in ○ the “Motion Tracking” menu and PTZ Protocol in “Control” menu in the Admin Tool is correctly selected. Click it to store map, presets and group data to the IP Speed Dome.
  • Page 65 WEB VIEWER Masked Area No detection Unmasked Area Effective detection This defines the sensitivity of motion detection. Move small circular handle toward the+ direction to ○ increase the sensitivity. Click it to turn Motion Tracking function on or off. ○ 65/96 ANTI-VANDAL 10x SPEED DOME CAMERA...

  • Page 66: How Does Motion Tracking Work

    WEB VIEWER How does Motion Tracking work? The “Motion Tracking (MT)” means intelligent Wait at Home Till Target detected moving object following using PTZ camera to get the best incoming information to figure out behavior of moving target in the region of Camera interest.
  • Page 67 WEB VIEWER Priority Rule: Basically, if there are two moving objects crossing, MT will follow bigger sized object. Rejection of Oscillating Objects: If there is an object oscillating limited distance like swaying tree, flag, MT will consider the distance and count number of oscillation. If the number exceeds the setting value in Motion tracking menu, it will return to home.

  • Page 68: Create, Save, Load Map

    WEB VIEWER Create, Save, Load Map Firstly, make sure Camera Model in “Motion Tracking” menu and PTZ Protocol in “Control” menu Administration Tools before creating Map. Also, most map related function except “Load” can be operated only by the user who has Administrator authority. ...

  • Page 69: Preset

    WEB VIEWER Preset If you draw a box on the map as shown in the picture bellow, the PTZ camera will move and change the zoom ratio to obtain the optimal video matched with the box you just draw. As shown bellow, if you click the right button of a mouse, you will see the menu item [Save Preset]. If you choose this, you will see a dialog box to specify Preset Number and Dwell Time.

  • Page 70: Group

    WEB VIEWER Group If you drag a preset number in the yellow box on the map and drop it into the group list box as shown in the picture bellow, corresponding Preset number will be added and registered like “P000” as a member of Group. Maximum 20 presets can be member of one Group.

  • Page 71: Viewer Interface

    WEB VIEWER Viewer Interface  Click N Go By clicking a target in main view, PTZ camera will move to locate the center of view to the target.  Box N Go By drawing a box on the target in main view, PTZ camera will move the camera view to the center of the box and change zoom ratio to match the view size with that of the box surrounding the target.

  • Page 72: Admin Tool

    ADMIN TOOL This section is provided to familiarize the user with the administration tools. Intuitive options are not explained in detail. All the changes on Administration Tools take effect immediately. These settings will be global, affecting the view of all users currently logged on. However, OSD items selections are effective only after you refresh the viewer windows or restart the internet Explorer.
  • Page 73 ADMIN TOOL  Frame Rate Maximum frame rate of video to limit the traffic occupied.  Camera Flip Flip the video orientation. (i.e. Turn the video upside down.)  P/T Direction Define the direction of Pan/Tilt motion.  Video Compression Choose the video compression method form Motion JPEG and MPEG-4 formats. ...

  • Page 74: Control Tool

    ADMIN TOOL Control Tool  Com1 For PTZ devices only. Select the PTZ control protocol.  Com2 For Digital I/O module only. Select the module type.  PTZ Camera ID For PTZ Device Address Setup. 0 ~ 255 are available. ...

  • Page 75: Motion Detection Tool

    ADMIN TOOL Motion Detection Tool  Detection Action Set up the reaction of IP Speed Dome when motion detected. Alert Sound : Audio Out through the Audio out jack of IP Speed Dome. Out 1 ~ 4 : Select output relay numbers in the Sensor Alarm I/O module connected with IP Speed Dome.

  • Page 76: Motion Tracking Tool

    ADMIN TOOL Motion Tracking Tool  Camera Select model of Zoom Camera Module.  Tracking Sensitivity Select the sensitivity 0~7 for target’s movement during Motion Tracking. The bigger number, the more sensitive.  Tracking Range Define the coverage of “Motion Tracking operation”. If you want to apply motion tracking for all area, check the box before ALL.
  • Page 77 ADMIN TOOL  1x Zoom Wait The time out of waiting after 1x zoom state. If camera loses a target object, it will automatically zoom out to 1x to search the object lost. If there is no moving object for a while, the camera will return to Home Position where “Motion Tracking”...

  • Page 78: Tcp/Ip Tool

    ADMIN TOOL TCP/IP Tool  Network Type Select a Static or Dynamic address scheme that is used by the Internet Service Provider (not the addressing scheme used by a personal router).  Internet Address Input a value to assign an IP address to the IP Speed Dome. ...

  • Page 79: Ddns Tool

    ADMIN TOOL DDNS Tool  Use DDNS If you check this box, DDNS updating is enabled. (primary and secondary)  Primary DDNS Address Assign DDNS address. (default. www.net4c.net)  Secondary DDNS Select DDNS Provider. Currently, DtDNS is available. Provider  Host Name Type the host name registered in DDNS service (i.e.

  • Page 80: Smtp Tool

    ADMIN TOOL SMTP Tool This function is used to email the specified email recipient and notify that individual of the IP address / web port number used to access the IP Speed Dome. This email function is only activates on power-on reset time of IP Speed Dome.

  • Page 81: Date & Time Tool

    ADMIN TOOL Date & Time Tool  Current Date/Time It shows the current Date/Time setting of IP Speed Dome.  New Date/Time Select the method of Date/Time setting. Date/Time can be set by local computer or time server or manual. 81/96 ANTI-VANDAL 10x SPEED DOME CAMERA...

  • Page 82: Users Tool

    ADMIN TOOL Users Tool  System Manager Specify an ID and Password for the System Administrator of the IP Speed Dome. The System Administrator will have all rights and privileges to manage the system. After changing Administrator’s ID and Password, IP Speed Dome should ...

  • Page 83: Firmware Update Tool

    ADMIN TOOL Firmware Update Tool  Version Shows the current firmware version.  How to upgrade Click [Browse…] button and select the latest version of the firmware. Its file name should be ***.bin. Click [Update Start] button. It will start upgrading its firmware. IP Speed Dome will re-boot automatically as soon as it finish the upgrade process.

  • Page 84: Default Set Tool

    ADMIN TOOL Default Set Tool Reset its system configuration to the factory defaults. Note) After initializing, all information should be deleted. Please re-consider before initializing. Rebooting Tool Re-boots IP Speed Dome. 84/96 ANTI-VANDAL 10x SPEED DOME CAMERA...

  • Page 85: Appendix

    APPENDIX A : Current TCP/IP Settings  For Windows 98 / ME Users  Note the settings under the IP Address, DNS Configuration, and Gateway tabs  If your IP settings are obtained automatically, you could use the MS-DOS prompt (or Command Prompt) to determine your IP address.

  • Page 86: B : Changing Your Computer's Ip Address And Subnet Mask

    APPENDIX B : Changing your computer’s IP address and subnet mask  For Windows 98 / ME Users  Select 'Use the following IP address' and change the IP address and Subnet Mask.  For Windows 2000 or Windows XP ...

  • Page 87: C : Port Forwarding

    APPENDIX C : Port Forwarding After assigning the IP Speed Dome a web server port and video server port you must use Port Forwarding (for cases A, B) Please consult your router’s user guide on how to correctly configure Port Forwarding. For your convenience, we have provided two example configurations.
  • Page 88 APPENDIX  Enabled / Disabled Select “Enabled”.  Name Input IVS name.  Private IP Input IVS address.  Protocol Type Select “TCP”.  Private Port / Public Port Input IVS Web Server Port.  Schedule Select “Always” If 'Setting Saved' shows, click [Continue] button. ⑤...
  • Page 89 APPENDIX  For Linksys BEFSR41 Cable/DSL routers: Open a web browser and type http://192.168.1.1 into your Address bar (the default IP address to access ① the router) You will have to supply your User Name and Password to log onto the router. Default from factory (User ②...
  • Page 90 APPENDIX  For Netgear RP614 routers Input http://192.168.0.1 in address bar of web browser. http://192.168.0.1 is the default IP address. ① If it asks ID and password, input admin as ID and password as password. ② Click “Port Forwarding” in "Advanced". ③...

  • Page 91: Faq

     I can’t connect!! In the case of a connection failure. Modem Reboot  Modem Reboot Finished  Router Reboot  Router Reboot Finished  IP Speed Dome Reboot  IP Speed Dome Reboot Finish  Verify DDNS and IP Speed Dome connection, if applicable.
  • Page 92 How do I find out my IP address information if my settings were  automatically detected?  Windows 98 / ME Users ① Open an MS-DOS Prompt ② At the prompt type:“winipcfg” (without the quotation marks) ③ Use the drop down list to select your 10/100 Ethernet Adapter (not a PPP adapter) ④...
  • Page 93  My LINK light is not flashing or solid? Verify the cable connection. 99% of the time the cable’s connection to the unit is causing this problem. Try using a different network cable or crossover cable (for PC connection only). Try reinserting the cable, if this still doesn’t solve the problem call our Support Center.
  • Page 94  Can I use the IP Speed Dome on my dial-up Internet connection? No, we recommend a high-speed broadband connection of at least 128Kb/sec.  I’m accessing my video server remotely over the Internet and the video stream is choppy, is this normal? Yes.

  • Page 95: Specifications

    SPECIFICATIONS Specifications  Appearance Model 10 Video Signal System NTSC 1/4'' Interline Transfer CCD Max. Pixels 811(H)508(V) 410K 795(H)596(V) 470K Effective Pixels 768(H)494(V) 380K 752(H)582(V) 440K Horizontal Res. 500 TV Line(Color), 570 TV Line(B/W) S/N Ratio 50 dB (AGC Off) 10 Optical Zoom, 10 Digital Zoom Zoom Focal length...

  • Page 96: Dimension

    SPECIFICATIONS Dimension  Main Unit & Surface Mount Bracket  Flush Mount Ring Bracket  Ceiling Mount Bracket  Wall Mount Bracket Unit (mm) 96/96 ANTI-VANDAL 10x SPEED DOME CAMERA...
