- Page 1 Concept Pro VHSD-810EXT Speed Dome System User Manual...
-
Page 2: Precautions
Safety Information CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN. CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Warning Precaution This symbol indicates that dangerous voltage This exclamation point symbol is intended to alert the consisting a risk of electric shock is present within user to the presence of important operating and... -
Page 3: Table Of Contents
Precautions Contents Operating 4 Precautions Before using, make sure power supply and others are properly connected. While operating, if any abnormal condition or malfunction is observed, stop using the camera immediately and then contact your Special dealer. 1. Introduction Product & Accessories Parts Name &... -
Page 4: Parts Name & Functions
Product & Accessories Parts Name & Functions Please check if all the camera and Dome Cover accessories are included in the package. - Protects the camera module from outside environment. Dome Cover Main Body - Do not detach protection vinyl from the dome cover before finishing all installation processes Camera module, screws, terminal block slot and to protect dome cover from scratches or dust. -
Page 5: Dip Switch Setup
DIP Switch Setup DIP Switch Setup Before installing the camera, you should 2. Communication Protocol Setup AD(American Dynamics) set the DIP switch to configure the camera Bottom of Main Body ID, communication protocol. 5 6 7 8 Pin On/Off If the pin is located ‘ON’ side of the printed label, it means on. -
Page 6: Installation Using Surface Mount Bracket
Installation Using Surface Mount Bracket Installation Using Flush Mount Ring Bracket (Option) Drilling the Hole on the Ceiling Drilling the Hole on the Ceiling Drilling the Hole on the Ceiling To pass cables through the ceiling, drill a hole To pass cables through the ceiling, drill a Drilling the Hole (30mm diameter) on the ceiling panel. - Page 7 Installation Using Ceiling Mount Bracket (Option) Installation Using Wall Mount Bracket (Option) 1. Installing on the Concrete Ceiling 1. Installing on the Concrete Wall Drill the Ceiling and Fix the Anchor Bolts Drill the Wall and Fix the Anchor Bolts Fix the Wall Mount Bracket On the ceiling, drill a hole (6mm diameter/ 50mm On the wall, drill a hole (6mm diameter/50mm...
-
Page 8: Cabling The 5P Terminal Block
Cabling the 5P Terminal Block Cabling the 7P Terminal Block Relay Out 5P Terminal Block BNC Video Sensor/Alarm Input 5p terminal block connects the sensor/alarm input and the relay out device to the camer’s main body. (Refer ‘Installation Using Surface Mount Bracket’ of page 10 for the connection of the terminal block.) Power Monitor... -
Page 9: Main Functions
Check Points before Operation Main Functions Preset Group Check Points before Operation - Max. 127 positions can be stored as preset positions. - The group function allows running sequence of presets, 1. Before power is applied, please check the cables carefully. The preset number can be assigned from 1 to 128, but 95 pattern and/or VSTs. -
Page 10: Osd Information
OSD Information General Rules of Menu Operation This page explains how to operate the OSD CONCEPT PRO SPEED DOME menu using keyboard controller. PRESET LABEL PATTERN1 Preset Label Action Title - - - - - - - - - - - - - - - - - - - - - - - - - - - <SYSTEM INFORMATION>... -
Page 11: Osd Menu Contents
OSD Menu Contents OSD Menu Contents CONCEPT PRO SPEED DOME The 1st screen The 2nd screen The 3rd screen The 4th screen Value CONCEPT PRO SPEED DOME The 1st screen The 2nd screen Value <SYSTEM INFORMATION> FIRMWARE VER <CAMERA SETUP> FOCUS MODE AUTO / MANUAL / SEMIAUTO COLOUR SYSTEM... -
Page 12: Osd - Concept Pro Speed Dome & System Information
OSD - CONCEPT PRO SPEED DOME & SYSTEM INFORMATION OSD - DISPLAY SETUP CONCEPT PRO SPEED DOME DISPLAY SETUP CONCEPT PRO SPEED DOME DISPLAY SETUP To enter this screen, enter ‘Preset key + 95’. This menu defines to enable/disable of OSD display on main screen. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - <SYSTEM INFORMATION>... -
Page 13: Osd - Motion Setup
OSD - MOTION SETUP OSD - MOTION SETUP MOTION SETUP ALARM INPUT SETUP MOTION SETUP MOTION SETUP Setup the general functions of pan/tilt motions. If an external sensor is activated, camera will move to - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - PRESET LOCK PRESET LOCK... - Page 14 OSD - FUNCTION SETUP > PRESET SETUP OSD - FUNCTION SETUP > PRESET SETUP FUNCTION SETUP LABEL FUNCTION SETUP PRESET SETUP Configure 5 special functions with this menu. - Edits label to show on monitor when preset runs. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - <PRESET SETUP>...
-
Page 15: Osd - Function Setup>Vst Setup
OSD - FUNCTION SETUP>VST SETUP OSD - FUNCTION SETUP>PATTERN SETUP VST SETUP PATTERN SETUP FUNCTION SETUP FUNCTION SETUP - Up to 8 VST are available, which makes the camera to move It records the free path of camera by joystic control. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - <PRESET SETUP>... -
Page 16: Osd - Function Setup>Group Setup
OSD - FUNCTION SETUP>GROUP SETUP OSD - FUNCTION SETUP>GROUP SETUP GROUP SETUP SCREEN EDIT GROUP - Assign Function FUNCTION SETUP EDIT GROUP The group function allows running sequence of presets, pattern Move cursor Left/Right to select items and move cursor Up/Down - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - <PRESET SETUP>... -
Page 17: Osd - Function Setup>Schedule Setup
OSD - FUNCTION SETUP>SCHEDULE SETUP OSD - FUNCTION SETUP>SCHEDULE SETUP SCHEDULE SETUP SCREEN SCHEDULE SETUP - Save Edited Setting FUNCTION SETUP SCHEDULE SETUP - The schedule function allows running the appropriate function To save data and exit, press near key. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - <PRESET SETUP>... - Page 18 OSD - CAMERA SETUP>WB SETUP OSD - CAMERA SETUP>AE SETUP CAMERA SETUP AE SETUP CAMERA SETUP CAMERA SETUP Setup the general functions of zoom camera module. Setup the video related function of zoom camera module. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - FOCUS MODE SEMIAUTO...
-
Page 19: Osd - System Setup
OSD - SYSTEM SETUP OSD - SYSTEM SETUP SYSTEM SETUP SET HOME POSITION SYSTEM SETUP SET HOME POSOTION - Home position means the origin of pan angle calculation. The - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - <DATE/TIME SETUP>... -
Page 20: Osd - System Initialise
OSD - SYSTEM INITIALISE Dimensions SYSTEM INITIALISE Unit: mm SYSTEM INITIALISE Initialises to the camera setting. - - - - - - - - - - - - - - - - - - - - - - - - - - - CLEAR ALL DATA CLR DISPLAY SET CLEAR ALL DATA... -
Page 21: Dimensions Of Option Brackets
Dimensions of Option Brackets Dimensions of Option Brackets 1. Flush Mount Ring Bracket Unit: mm 2. Sun Shield Mount Bracket Unit: mm 3. Wall Mount Bracket Unit: mm 2. Ceiling Mount Bracket Unit: mm 112.6 4- 7 374.6 112.6 57.5 71.6 355.5 199.3... -
Page 22: Specifications
Specifications Signal Format NTSC Image Device 1/4” Interline Transfer CCD Total Pixel 410K pixels [811 (H) x 508 (V)] 470K pixels [795 (H) x 596 (V)] E ective Pixel 380K pixels [768 (H) x 494 (V)] 440K pixels [752 (H) x 582 (V)] H.
