Summary of Contents for Allo.com PSTN / VoIP PBX
- Page 2 Quick Installation Guide PSTN / VoIP PBX Version 2.1...
-
Page 3: Table Of Contents
Table of Contents Hardware Setup ......................1 Notification LEDs (On the Front Panel of the Gateway) .......... 2 PSTN/VOIP PBX Quick Installation Wizard ............3 Accessing the Main Web GUI of PSTN/VoIP PBX ..........4 Create Extensions (Analog and SIP): ..............4 Create Analog Trunks (Lines): ................ -
Page 4: Hardware Setup
PSTN/VoIP PBX Hardware Setup 1. Unpack your PSTN/VOIP PBX and make sure you received everything. Each box contains: PSTN/VOIP PBX -1 No AC adapter (120V-220V) + 2 wall plugs (EU & US) -1 No Ethernet cable and Serial Cable -1 No 2. -
Page 5: Notification Leds (On The Front Panel Of The Gateway)
PSTN/VoIP PBX Use Mozilla Firefox Only! 7. Follow the quick setup wizard steps 8. CONGRATULATIONS!!! You are now ready to start configuring your PSTN/VoIP PBX. Notification LEDs (On the Front Panel) Quick Installation Guide v2.1... -
Page 6: Pstn/Voip Pbx Quick Installation Wizard
PSTN/VoIP PBX PSTN/VOIP PBX Quick Installation Wizard By following the Wizard, you will create a very basic configuration file allowing you to make and receive calls thus confirming your PSTN/VOIP PBX is fully functional. Most of the features won’t be visible until you complete the wizard and access the full fledge user interface. -
Page 7: Accessing The Main Web Gui Of Pstn/Voip Pbx
PSTN/VoIP PBX Accessing the Main Web GUI of PSTN/VoIP PBX After completion of the quick setup wizard, unit will reboot and you can access the main Web GUI through WAN IP address of PSTN/VoIP PBX Create Extensions (Analog and SIP): This is where you create your extensions. -
Page 8: Create Voip Or Sip Trunks (Providers)
PSTN/VoIP PBX Create VOIP or SIP trunks (Providers): This will allow you to make calls using your SIP/VOIP account 1. Click on the Setup TRUNKS link in the GUI, and then select VOIP TRUNKS. 2. Set type as SIP and choose the correct Context Naming based on the credentials provided by your VOIP provider. -
Page 9: Internal Calls: Incoming & Outgoing (Ext. To Ext.)
PSTN/VoIP PBX 4. Don’t forget to SAVE and APPLY CHANGES after each operation. 5. YOU HAVE CREATED DIAL OUT RULES, WITH THESE RULES YOU HAVE CREATED DIAL PLANS THAT YOU WILL ASSIGN TO SPECIFIC EXTENSIONS (USERS). Internal Calls: Incoming & Outgoing (ext. - Page 10 PSTN/VoIP PBX 3. If pattern is “_8X.” & strip is “1”, dial “8<followed by external number/extensions>” from either analog or SIP users which uses the same dial plan 4. For SIP trunk follow the same steps mentioned above. Quick Installation Guide v2.1...
-
Page 11: Incoming
4. You are now able to make/receive basic calls through the PSTN/VoIP PBX. The full version manual will provide you detailed instructions about the numerous features of the PSTN/VOIP PBX. You can download it from the below link http://www.allo.com/documents/pstn-voip-pbx/pstn-voip-pbx-user-manual-2-8.pdf Quick Installation Guide v2.1...
