Summary of Contents for Penpower Technology WorldPenScan Series
- Page 1 WorldPenScan Series User Manual Release: November, 2014 Version: v4.0 Win...
- Page 2 Penpower Technology Ltd. Software User License Agreement You are licensed to legally use this software program (“the Software”) by Penpower Technology Ltd (“Penpower”) under this license agreement (“The Agreement”). If you do not agree with any of the provisions in this Agreement, please do not install, copy or use the Software.
- Page 3 Penpower is unable to promise nor warrant that there will be absolutely no risk of loss or damage of information, or any other kind of loss, during installation and/or execution of the Software. You must be fully aware of your risks in using the Software. Penpower will provide you with the Software and support services in respect of the Software to the maximum extent permitted by law.
- Page 4 10. Jurisdiction With regards to any disputes arising from this Agreement, Penpower and you agree that the court having jurisdiction over the business location of Penpower will be the court in the first instance.0 11. Miscellaneous In the event that any provision of this Agreement is found to be invalid at law, such in- validity will not affect the validity of any other provisions, or the legal enforceability of such other provisions.
-
Page 5: Fcc Statement
FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in- stalled and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 6: Table Of Contents
2.2.2 WorldPanScan BT ...................2 - 2 2.2.3 WorldPanScan X ..................2 - 3 2.3 Software Installation ..................2 - 4 2.4 Running Penpower WorldPenScan Series ............2 - 6 2.5 Connect to Pen Scanner ..................2 - 7 2.5.1 Via USB Cable ..................2 - 7 2.5.2 Via Bluetooth (Only for WorldPenScan BT) ..........2 - 8... - Page 7 There may be newer versions of the software that was released during or after this prod- uct’s manufacturing date. If the content in the User Manual differs from the on-screen interface, please follow the instructions on the on-screen interface instead of the User Manual.
-
Page 8: Chapter 1 Product Introduction
Chapter 1 Product Introduction WorldPenScan series, the best input device, scans and recognizes lots of languges and put the scanned material into your computer via the USB interface. Whenever you come across any particular words or sentences that you do not understand, WorldPen- Scan series will scan for you. -
Page 9: Chapter 2 Getting Started
Chapter 2 Getting Started Chapter 2 Getting Started 2.1 System Requirements · Windows 8 desktop mode/7 /Vista /XP SP3 · 650MB of available hard disk space · USB port · Bluetooth module-WIDCOMM or Microsoft Bluetooth stack(WorldPenScan BT) 2.2 Hardware Specification 2.2.1 WorldPanScan ·... -
Page 10: Worldpanscan Bt
WorldPenScan Series 2.2.2 WorldPanScan BT · Dimensions: 130mm x 37mm x 18.5mm · Weight: 35g · Interface: USB 2.0/Bluetooth v2.1+EDR · Built-in lithium polymer rechargeable battery · Voltage and amperage: 4.75~5.25V (<100mA) · Scanning speed: 15 cm/sec.· · Character size: 5~22 pt... -
Page 11: Worldpanscan X
Chapter 2 Getting Started 2.2.3 WorldPanScan X · Dimensions: 114.7mm x 33mm x 22.45mm · Weight: 55g · Interface: USB 2.0/Bluetooth v4.0 BLE · Built-in lithium polymer rechargeable battery · Voltage and amperage: 4.75~5.25V (<100mA) · Scanning speed: 10 cm/sec.· ·... -
Page 12: Software Installation
WorldPenScan Series 2.3 Software Installation 1. Insert the WorldPenScan/ WorldPenScan BT setup CD into the CD-ROM drive. The installation program will start automatically. Click [WorldPenScan]/ [WorldPenScan BT] to install WorldPenScan/ WorldPenScan BT. (WorldPenScan BT for example) 2. Please select an installation language and click [Next] to install. - Page 13 Chapter 2 Getting Started 5. Select a destination folder to install the software to. Click [Next] to continue. 6. Choose the program folder that you want to install WorldPenScan BT to. If left as default, the software will create a new folder for you. Click [Next] to continue.
-
Page 14: Running Penpower Worldpenscan Series
WorldPenScan Series 2.4 Running Penpower WorldPenScan Series Go to [Start/ All Programs/ Penpower WorldPenScan or Penpower WorldPen- Scan BT/ WorldPenScan or Penpower WorldPenScan BT] or double-click the shortcut on the desktop to start the WorldPenScan/ WorldPenScan BT tool- bar. When running the software for the first time, a Registration Reminder will appear. -
Page 15: Connect To Pen Scanner
Chapter 2 Getting Started 2.5 Connect to Pen Scanner You can plug pen scanner into your computer's USB port via the USB cable to use WorldPenScan or WorldPenScan BT. Besides, WorldPenScan BT can be connected with computer via Bluetooth for use. 2.5.1 Via USB Cable Please follow the instructions to connect pen scanner with computer. -
Page 16: Via Bluetooth (Only For Worldpenscan Bt)
WorldPenScan Series 2.5.2 Via Bluetooth (Only for WorldPenScan BT) Please follow the instructions to pair your computer and pen scanner with Bluetooth at first time use. 1. Press the function button on pen scanner until the status light blinks. When the status light blinks, you can begin to pair the computer with pen scanner. - Page 17 Chapter 2 Getting Started 5. Select [WorldPenScan] and click [Next]. 6. Select [Use the passkey found in the documentation] and enter the default passkey of pen scanner: 1234. Then Click [Next]. 7. Click [Finish] when pen scanner was successfully paired to your computer.
- Page 18 2-10 WorldPenScan Series 8. Then, the pen scanner will connect to your PC automatically. When pen scanner is paired with your PC successfully, the status light on pen scanner blinks slowly (blink every 3 seconds), and the pen scanner will connect with WorldPenScan BT automati- cally.
-
Page 19: Chapter 3 Scanning And Settings
Chapter 3 Scanning and Settings 3.1 WorldPenScan Series Toolbar Minimize 1. Language Recognition: The WorldPenScan series can recognize Traditional Chi- nese, Simplified Chinese, English, French, German, Italian, Japanese, Korean, Spanish and more text. Click to select the language you would like to scan. - Page 20 WorldPenScan Series 6. Business Mode : You can select [Barcode], [MICR], or [OCR A/B] from Busi- ness Mode. These modes allow you to scan barcodes, invoices, checks, bills, postal codes, coupon numbers, and racing numbers. In order to have higher recognition accu- racy, you may use the Business mode to recognize different documents.
-
Page 21: Scan Text And Image
5. Stop applying pressure to the pen to stop scanning. The text that the pen has scanned will be displayed in your word processor immediately. Note: WorldPenScan series is able to scan and recognize one row of characters at a time. Please place the scan tip arrow at the center of the line. -
Page 22: Online Translation
WorldPenScan Series 3.3 Online Translation WorldPenScan series provides online translation function to translate scanned words and sentences by [Dictionary] and [Sentence Translation]. WorldPenScan series col- lects the translations results from websites and display them in its translation window. Note: Please connect to the internet while using the online translation function. -
Page 23: Sentence Translation
Chapter 3 Scanning and Settings 3.3.2 Sentence Translation 1. Select [Sentence translation] in the drop-down menu from the button 2. Select the language you want to translate from and the language you want to translate to 3. Select the translate engine you want to use 4. -
Page 24: Business Mode
WorldPenScan Series 3.4 Business Mode The Business Mode allows you to scan barcodes, invoices, checks, bills, postal codes, coupon numbers and racing numbers etc. The fonts that the Business Mode supports are OCR A, OCR B, MICR, and other fonts as the samples below:... -
Page 25: Original Image
Chapter 3 Scanning and Settings 3.5 Original Image Click [Tools] button and select the [Original Image] option from the drop-down menu to open the [Original Image] window. After scanning, the [Original Image] win- dow displays the scanned image. You can check the scanned image to compare with the original text. -
Page 26: Settings
English word. Scan Direction WorldPenScan series must be used to scan the characters in consistent direction, any changes to the direction will cause inaccurate recognition results. When choosing Traditional Chinese, Simplified Chinese, Japanese or Korean as the language recognition, you can accord to the document you want to scan to choose the scan direction manually. - Page 27 Scan from right-to-left or from left-to-right Scan from left-to-right or from right-to-left Note: Penpower WorldPenScan series is able to scan and recognize one row of char- acters at a time. Please place the pen scanner in such a manner so that the Scan Tip arrow is at the center of the line of text.
- Page 28 Left hand: Scan from left-to-right Right hand: Scan from left-to-right Note: Penpower WorldPenScan series is able to scan and recognize one row of char- acters at a time. Please place the pen scanner in such a manner so that the Scan...
-
Page 29: Recognition Settings
Recognition Languages WorldPenScan series provides lots of recognition languages for you to choose. In the toolbar, you can drag down the recognition menu to select the recognition language you want. - Page 30 3-12 WorldPenScan Series Chinese Recognition Option When choosing Chinese Traditional or Chinese Simplified as the language recognition, you can choose to output the recognized characters in Traditional Chinese or Simplified Chinese. Check the [Output full-width punctuations] option to set the punctionations as full-width.
-
Page 31: Business Mode
3-13 Chapter 3 Scanning and Settings 3.6.3 Business Mode When using the business mode, you can accord with the scan content to choose the scan mode as below for higher recognition accuracy and the font the mode supports will show in the window. y Barcode: Recognize barcodes. -
Page 32: Hardware Information (For Worldpenscan Bt)
3-14 WorldPenScan Series 3.6.4 Hardware Information (For WorldPenScan BT) In [Hardware info] page, you can view the Bluetooth status and pen status. y Host Bluetooth status: Show whether the Bluetooth of your computer is turned on or not. y Pen Bluetooth status: Show the connecting status of pen scanner. -
Page 33: Help
Selecting [About] in the drop-down menu from the button can see the informa- tion of WorldPenScan series, or you can go to Penpower Technology Ltd. official website for more informaiton. If there is any problem or suggestion, please click [Contact us]... - Page 34 Penpower WorldPenScan Series User Manual Release: November, 2014 Version: v4.0...
