- Page 1 USB 3.0 Universal Mini Docking Station Adapter User Manual DSH-M100U3 Ver. 1.00 All brand names and trademarks are properties of their respective owners. www.vantecusa.com Copyright © 2015 Vantec Thermal Technologies. All Rights Reserved...
-
Page 2: Table Of Contents
2.1.2 Installation for Mac OS X ........8 2.2 Hardware Installation ..........9 2.3 Verifying the Installation ........11 2.3.1 Verifying Windows installation ......11 2.3.2 Verifying OS X Installation ........11 2.4 Display Configuration ..........12 DSH-M100U3 Page 2... -
Page 3: Chapter 1: Introduction
Chapter 1: Introduction 1.1 Product Introduction The Vantec USB 3.0 Universal Mini Docking Station Adapter with HDMI/DVI and GbE is design to be quick and easy way to add additional monitor/projector, wired to Gigabit Network, and connect USB 3.0 device to your Ultrabook, Hybrid table or laptop computer. -
Page 4: Features
Display (HDMI or DVI with adapter), and Gigabit Ethernet Connection to your computer system Support for latest Mac OS X and Windows OS Bundle with HDMI to DVI converter Video: Display Support allow monitor for Extend / Mirror or Primary Display DSH-M100U3 Page 4... -
Page 5: System Requirements
Gigabit Ethernet wired connectivity (compatible with 10/100 Ethernet) Capable of Full-Duplex (2Gbps) Auto MDI-X for simplify connection Wake on LAN function 1.3 System Requirements Windows® XP, Vista, 7, 8, 8.1 (32/64 bit); Mac OS X 10.6 or greater DSH-M100U3 Page 5... -
Page 6: Package Contents
1 x HDMI to DVI converter 1.5 Hardware Layout 1. HDMI output port: Connect to a HDMI monitor 2. RJ45 port: Connect to the wired Gigabit Ethernet network via a network cable 3. USB 3.0 downstream port: Connect USB peripheral DSH-M100U3 Page 6... -
Page 7: Chapter 2: Getting Started
Docking Station Adapter to the computer. 2.1.1 Installation for Windows Insert the provided CD into your optical drive. Browse to the DSH-M100U3 Folder and select the Windows OS. Start the setup by clicking on the DisplayLink setup program. DSH-M100U3 Page 7... -
Page 8: Installation For Mac Os X
USB 3.0 Universal Mini Docking Station Adapter. 2.1.2 Installation for Mac OS X Insert the provided CD into your optical drive. Browse to the DSH-M100U3 Folder and select the Mac Folder that contains the setup program. Start the setup by clicking on the DisplayLink setup program. -
Page 9: Hardware Installation
(Optional): Plug the power adapter into the power jack of the Mini Dock. Connect the USB 3.0 Universal Mini Docking Station Adapter to your system. A pop-up message will appear in the notification area indicating the installation is complete. DSH-M100U3 Page 9... - Page 10 HDMI, you can use the provided HDMI to DVI adapter to connect to your monitor. Connecting USB 2.0/USB 3.0 device Connect your USB device to the USB 3.0 port on the USB 3.0 Universal Mini Docking Station Adapter. DSH-M100U3 Page 10...
-
Page 11: Verifying The Installation
Mini Dock from your computer and then repeat the installation steps again. 2.3.2 Verifying OS X Installation Choose About this Mac from the Apple menu. Click on More Info… In the Contents sidebar select USB from the Hardware section. DSH-M100U3 Page 11... -
Page 12: Display Configuration
This gives you access to the DisplayLink manager menu. To use the DisplayLink Manager Menu From the taskbar, click the DisplayLink icon A menu appears with several options. These are shown and described below. DSH-M100U3 Page 12... - Page 13 The window will move off the primary display from the right side and enter the extended display from the left side • Set as Main Monitor: Sets the extended screen as the main screen DSH-M100U3 Page 13...
- Page 14 **Note: The stated transmission rate of this device is 1Gbps. This is the theoretical data rate and actual rate may vary. It is dependent on the PC's OS, hardware, Network traffic, switches, routers traffic/data/capacity on the USB bus DSH-M100U3 Page 14...
