Page 1: User Manual
Q U I C K L O O K User Manual Please read the “Important Instructions for Use” overleaf... - Page 2 • Use only the charger provided. Use another charger could result irreparable damage to Quicklook Focus and will void the warranty. • Quicklook Focus should be stored in the “off” position when not in use. • Do Quicklook Focus bathroom, near water or other damp conditions.
-
Page 3: Contents Of The Package
We recommend that you read this manual carefully to obtain the best service from your new product. Contents of the Package Quicklook Focus is supplied with the following items: o Main unit with integrated display, camera & battery... - Page 4 The light will go when battery substantially charged. It takes about three hours to charge the battery from a discharged state. Quicklook Focus can be used while the battery is being charged.
- Page 5 Mode button butto Zoom down Camera button Operation Pic of the mouse on the The Quicklook Focus is powered on by handwriting rotating camera either stand. operating positions. It is powered off by Pic of the mouse on the Maybe show the handwriting stand.
- Page 6 Focussing The Quicklook Focus has a push-to-focus feature that must be used to obtain a sharp image. Simply point the camera at what you wish to view and briefly press the Focus/Freeze button and the unit will choose the best focus for you.
- Page 7 Focus differs from a magnifying glass in that image does correspond to the area directly beneath. Quicklook Focus can be operated and viewed from any orientation. Changing image mode Pressing the Mode button (refer to the diagram on page 5) on the side of the unit will cycle through the five image modes.
- Page 8 Note that all original colour is removed from the image in the enhanced modes. The colour options used in the semi-colour modes can be selected. Refer to the “Reading Mode Menu” later in this manual. Freezing the image To freeze the image, simply press and hold the Focus/Freeze button on the side of the unit for about a second (refer to the diagram on page 5).
- Page 9 Writing When you wish to write with the Quicklook Focus, rotate the camera out fully to its second click position. While looking at the display, find the place on the page where you wish to write and place your pen in the picture.
-
Page 10: Turning Off The Camera Lights
Quicklook off and back on again. Manual Focussing It is possible to manually change the focus on the Quicklook Focus: simply power-on the unit while holding the Focus button and release when the image is displayed. In use, repeated pressing of the Focus... -
Page 11: Battery Level
Using the Menu The Quicklook Focus has a menu system to allow you to customize it to suit your requirements. To bring up the menu,... - Page 12 and the Reading Mode Menu contains these options: Use Zoom-up and Zoom-down to navigate through the menu choices and press Mode to accept the choice. Press Focus/Freeze to cancel a choice and exit the menu. The Advanced menu contains options that are used only occasionally.
- Page 13 The Colour Mode Menu: Backlight - Use the Zoom-up and Zoom-down buttons to adjust the brightness of the display. Press Mode to accept the new setting. Brightness – Use the Zoom-up and Zoom-down buttons to adjust the image brightness. Press Mode to accept the new setting.
- Page 14 Exit – Exit the menu. The Reading Mode Menu: Backlight - Use the Zoom-up Zoom-down buttons adjust the brightness of the display. Press Mode to accept the new setting. Colour selection – Here you change semi-colours used reading modes. The icon on the right will appear while selecting...
- Page 15 modes you use are available. If you only require the black and white reading modes select the first icon; choosing the last icon will allow only the semi-colours; the centre icon will allow both black and white and semi-colour options to be available. The Advanced Settings Menu: Battery display –...
- Page 16 The Info screen will display the revision of the software within the unit. Factory Defaults – will return the unit to its original factory settings. Reset If Quicklook stops responding to button presses it may need to be reset. Using a pen or similar instrument, press the reset button recessed into the underside of the unit near the camera.
-
Page 17: Maintenance
Maintenance Dirt and finger marks on the screen should be cleaned with the lens cleaning cloth provided. If Quicklook becomes dirty it can be cleaned with a damp cloth and mild detergent. Never use any type of solvent or abrasive cleaning agents. Do not immerse Quicklook in water! -
Page 18: Warranty
The battery is warranted for a period of one year. Cracks, scratches or similar damage to the display are specifically excluded from warranty. In no event shall Ash Technologies, or its agents, be liable for special, indirect, incidental or consequential damages; the original user's... -
Page 19: Specifications
As we strive to constantly improve our products, this information is subject to change without notice. DECLARATION OF CONFORMITY We, Ash Technologies Ltd., declare under our sole responsibility that this product,... - Page 20 © Ash Technologies Limited 2008 Ash Technologies Ltd. +353-45-88 22 12 B5, M7 Business Park, +353-45-88 22 14 Naas, Ireland. info@ashtech.ie Made in Ireland www.ashtech.ie Quicklook Focus User Manual EN Rev B...
