Tarantula RS.1 Installation Manual

Remote vehicle starter
Hide thumbs

Advertisement

Table of Contents

REV.5
RS.1
REMOTE VEHICLE STARTER
INSTALLATION GUIDE
www.security.soundstream.com
FCC ID NOTICE
This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the part responsible for compliance void the user's authority to operate
this device.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS.1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tarantula RS.1

Summary of Contents for Tarantula RS.1

  • Page 1 REV.5 RS.1 REMOTE VEHICLE STARTER INSTALLATION GUIDE www.security.soundstream.com FCC ID NOTICE This device complies with Part 15 of the FCC rules. Operation is subject to the following conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.

  • Page 2: Table Of Contents

    RS.1 PAGE 2 INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 TABLE OF CONTENTS WIRING DIAGRAM...............Page 3-4 Connector Pin Configuration Antenna Connection Door Lock Connector Bypass Connector Data Port Connector Tach Learning..................Page 5 Auto Tach/ Tachless Learning Hybrid Mode Low Idle Learn Wire Description................Page 6-7...
  • Page 3 RS.1 PAGE 3 WIRE DIAGRAM INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 OUTPUT TO ACTIVATE THE STARTER CIRCUIT PURPLE OUTPUT TO ACTIVATE ACCESSORY CIRCUIT ORANGE 12VOLT/ 30 AMP MAIN POWER INPUT 12VOLT/ 30 AMP MAIN POWER INPUT SELECTABLE OUTPUT* (DEFAULT 2ND IGNITION)
  • Page 4 RS.1 PAGE 4 INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 WIRE DIAGRAM OUTPUT TO ACTIVATE DOOR LOCK CIRCUIT (-) GREEN N/A* OUTPUT FOR VOLTAGE INVERTER* OUTPUT TO ACTIVATE DOOR UNLOCK CIRCUIT (-) BLUE ORANGE GROUND WHEN RUNNING (BYPASS TURN ON)

  • Page 5: Auto Tach/ Tachless Learning

    RS.1 PAGE 5 TACH LEARN INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 AUTO TACH/ TACHLESS LEARNING 2 CHIRPS/ 2 FLASHES = TACH MODE Start the vehicle with 3 CHIRPS/ 3 FLASHES = DATA TACH MODE the ignition key. 4 CHIRPS/ 4 FLASHES = TACHLESS MODE NOTES: When tach learning the system first sends out a request for tach from the data port.

  • Page 6: Wire Description

    RS.1 PAGE 6 INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 WIRE DESCRIPTION 6-PIN CONNECTOR STARTER This wire will test 0V with the key off, in the Accessory position and when the PURPLE PIN 1 OUTPUT Ignition is in the on. This wire is 12volts in the start/ crank position only.

  • Page 7: 9-Pin Connector

    RS.1 PAGE 7 WIRE DESCRIPTION INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 9-PIN CONNECTOR GREEN/ Supplies one .75 second pulse when locked and one .75 second pulse RE-ARM (-) PIN 1 after remote start shutdown. Factory alarm re-arm/ RAP shutdown.

  • Page 8: Transmitter Programming

    RS.1 PAGE 8 INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 TRANSMITTER PROGRAMMING PROGRAMMING ADDITIONAL TRANSMITTERS The system can lean up to 4 different remote’s. Each remote to be used MUST be programmed together during the same sequence. For security, when a new remote is programmed all previous remote’s are deleted.
  • Page 9 RS.1 PAGE 9 PROGRAMMING INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 ENTERING PROGRAM MODE 1 - Cycle the Ignition Key On/Off On/Off On (Leaving the key ON) 2 - Press and release the Program Switch 1 time. The park lights will turn on and the horn will honk to confirm entering program mode.

  • Page 10: Program Mode 1

    RS.1 PAGE 10 INSTALL MANUAL PROGRAM MENU 1 & 2 SYSTEM PROGRAMMING - Menu 1 Press and release the Valet Button to advance through Menu 1 settings. PROGRAM MODE 1 SETTING # SETTING OPTION 1 OPTION 2 OPTION 3 DESCRIPTION...
  • Page 11 RS.1 PAGE 11 PROGRAM MENU 3 & 4 INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 PROGRAM MODE 3 SETTING # SETTING OPTION 1 OPTION 2 OPTION 3 DESCRIPTION 1 CHIRP 2 CHIRPS 3 CHIRPS FLASHES SELECTABLE 2ND ACCESSORY RELAY STARTER...

  • Page 12: Diagnostics

    RS.1 PAGE 12 INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 DIAGNOSTICS DIAGNOSTICS CHART If the remote starter does not activate when the start button is pressed the park lights will flash a diagnostic to indicate what shutdown input has been triggered. For example: If the start button is pressed the park lights flash 3 times slowly.
  • Page 13 RS.1 PAGE 13 INSTALLATION NOTES INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 2 BUTTON REMOTE WHEN PROGRAMMED FOR 2 BUTTON OR LOCK/UNLOCK TOGGLE PRESSING UNLOCK AND START AT THE SAME TIME WILL SELECT MENU 4 WHILE IN PROGRAM MODE. THE SYSTEM MUST BE PROGRAMMED FOR 2 BUTTON REMOTE LOCK/UNLOCK TOGGLE TO OPERATE THE LOCK FEATURE ON THE VEHICLE.

  • Page 14: Door Lock Diagrams

    RS.1 PAGE 14 INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 RELAY DIAGRAMS DOOR LOCK DIAGRAMS Vehicle's Lock/Unlock Switch Door lock Output To Control Relay or Actuators Green Blue Ground Vehicle's Lock/ Unlock Switch Door lock Output 12volts Green Blue Ground...
  • Page 15 RS.1 PAGE 15 RELAY DIAGRAMS INSTALL MANUAL SYSTEM PROGRAMMING - Menu 1 DOOR LOCK DIAGRAMS Ground Vehicle's Lock/ Unlock Switch Door lock Output 12volts Green Blue Ground Lock Resistor 12volts Unlock Resistor USE SPDT 12v Relay 12volts Lock/ Unlock Switch...
