Summary of Contents for DigiFrame 10.4'' sovering series
- Page 1 The moment keeps going Jackie on holidays - Great ocean road, Melbourne 10.4" Sovereign Series Bringing memories to life! Product User Manual (Model No's: DF-F1048b, F1049r & F1050s)
- Page 2 Now they can be treasured in high quality digital form. Your DigiFrame is designed to bring your digital photos out of your computer and into your life! It is packed with great features (like movies & functions) to help you get the most out of your special moments.
-
Page 3: Table Of Contents
What’s inside Introduction Main Features Getting Started Jess & Chris Package Contents - Friends forever Installing your unit Operation Controls Using your Remote Control Inserting Memory Cards Main menu Viewing Pictures Watching video Listening to MP3 music File Management Playing a slideshow with music Copying and Deleting Files Using the SETUP option Technical Support / FAQ... -
Page 4: Introduction
Introduction Before operating the unit, please read this manual thoroughly, and retain it for future reference. This manual will help you use many of the exciting and useful features that will make your Digiframe viewing more enjoyable. This Digiframe lets you view digital pictures directly from your camera’s memory cards. -
Page 5: Package Contents
Package Contents 1. Digiframe 2. USB Cable 3. AC Adapter 4. Remote Control 5. User Manual Bringing memories to life! Product user manual for 10.4 & 15” Models... -
Page 6: Installing Your Unit
Plug in the AC power adapter into power outlet and the other end into the unit. • Place all of the media you wish to show on the DigiFrame onto your memory card of choice and place it into the provided slot, making sure that it is in the correct way. -
Page 7: Operation
Operation This Digital Frame is really easy to operate: 1. Remove memory card from camera: 2. Insert memory card into the frame and ensure it is inserted correctly: 3. The slideshow will start automatically... -
Page 8: Controls
Controls & Slots 1. AUTO 2. MENU 3. PREVIOUS Mini USB Port 4. NEXT POWER CF Card SD / MS / MMC / XD Card Power... -
Page 9: Using Your Remote Control
Using your remote control The following table briefly describes the remote control functions. BUTTON DESCRIPTION On/Off Switch your Digiframe on/off Card selection Select your memory card VOL - Decrease volume VOL + Increase Volume Slideshow Start slideshow Music Display music files... -
Page 10: Inserting Memory Cards
Inserting Memory Cards The Digital Picture Frame is compatible with the following memory cards: • Secure Digital Card (SD) • Multimedia Card (MMC) • Memory Stick • Compact Flash (CF) Card • XD (m) Picture Cards Insert your memory card. Do not force. If you are not able to easily insert the memory card completely, you may have inserted it the wrong way. -
Page 11: Main Menu
Main Menu Upon turning on the Digital Picture Frame, you will go straight to the MENU screen. To set the Auto Start feature Choose the SETUP screen. Use the left/right arrow to go to the “Set up”. Press PLAY button to enter the options screen. Use the Up / down arrows to choose your auto start option. -
Page 12: Viewing Pictures
Viewing Pictures When correspondent card is removed from card slot. VIEWING PICTURES Make sure you have at least one picture on your memory card or your USB flash drive. When this is done: • Select the desired flash media on main menu. (SD/XD/CF/MS/USB/ NAND-Internal Memory) •... - Page 13 Viewing Pictures • Otherwise press PLAY to enter the full screen photo (pause mode) and press PLAY to enter into slideshow mode. • Once a slideshow is playing or a picture is being shown, press the PLAY button. The following menu will appear:...
- Page 14 Viewing Pictures Previous Play previous picture in the picture list. Play or Pause Play or pause the current slideshow. Next Play next picture in the picture list. Rotate Use the rotate function to change the picture orientation between either portrait or landscape. Stop Stop slideshow and return to photo thumbnail.
-
Page 15: Watching Video
Watching Video The Digital Picture Frame supports the following video formats: • Motion JPEG (AVI): video format used by most digital cameras MPEG-I • MPEG-2 • MPEG 4 Make sure you have at least one video on your memory card or your USB flash drive. - Page 16 Watching Video Once a movie is playing, press the PLAY button on the remote control. The following menu will appear:...
- Page 17 Watching Video Fast Forward Previous Play forward the movie by 2/3/4 times speed. Play previous movie in the play list. Play or Pause Zoom Play or Pause the movie. Increase the size of the picture by 2/3/4/1 times. Fast Backward Play backward the movie by 2/3/4 times speed.
-
Page 18: Listening To Mp3 Music
Listening to MP3 Music A list of music files will be listed on the left side of the screen. The right side consists of the frequency chart and information status bar. The song information area is below the status bar. Use Up/Down arrows to select the music file and press PLAY to play. - Page 19 Pictures with Music Background Playing a slideshow with music Ensure you have at least one picture on your memory card or your USB flash drive. Additionally, you must have one MP3 file saved on the same selected memory card/USB/Internal Memory. When this is done: •...
-
Page 20: Playing A Slideshow With Music
Pictures with Music Background • Once an audio-slideshow is playing, press the PLAY button. The following menu will appear: Previous Play previous picture in the picture list. Play or Pause Play or pause the current slideshow. Next Play next picture in the picture list. Rotate Use the rotate function to change the picture orientation to either portrait or landscape. -
Page 21: File Management
File Management Press VOL+ or VOL- on remote control to increase or decrease the volume Copying and Deleting Files Copy and delete files on your memory card, USB drive or internal memory. Copy • Select the desired flash media on main menu. (SD/XD/CF/MS/USB/ NAND-Internal Memory) •... -
Page 22: Copying And Deleting Files
Copying & deleting files • Press PLAY to start copying the file. • Press the STOP button to bring you back to the Copy and Delete menu. Delete • Select the desired flash media on main menu. (SD/XD/CF/MS/USB/NAND-Internal Memory) • Select the “FILE”... -
Page 23: Using The Setup Option
Using the set-up option Upon turning on the Digiframe, you will go straight to the MENU screen. Press the “SETUP” button to display the Setup menu on the remote control. The following options can be changed by using the “SETUP” option from the main menu:... - Page 24 Calendar/Clock Display Upon turning on the Digiframe, you will go straight to the MENU screen. If you select Calendar/Clock and press PLAY, you will go to Calendar/Clock screen. If the Alarm is turned on, it will also show the alarm time. A picture slideshow will begin at the...
-
Page 25: Technical Support / Faq
2) Q: If I keep showing the same photo for a long time, will it damage the LCD screen? A: No. The Digiframe can display the same photo continuously for a long period time. But it is recommended not to show the same picture continuously for more than 1 month. - Page 26 7) Q: How come the Digiframe does not show some of my photos? A: The Digiframe is designed to show photos following the same camera industry standards format as digital cameras. This format is a JPEG format. Images, such as web images, scanned images, or photos in RAW format, are not stored according to camera industry standards and therefore cannot be displayed correctly on the Digiframe.
-
Page 27: Troubleshooting
If you don’t see the opening screen, check if the power is connected to the Digiframe and make sure it is securely attached. No Start-up screen Memory card is not inserted correctly. -
Page 28: Cleaning The Lcd Screen
Keep your Digiframe out of sunlight. Direct sunlight may cause damage. • Do not open the case of the Digiframe. There is a risk of electric shock, and there are no user serviceable parts inside. Opening the case will void your warranty. -
Page 29: Specifications
We hope you enjoy your Digiframe! - Page 30 Bringing memories to life! For additional hints & tips - visit us at www.digiframe.com.au For Repairs & Service please contact CUSTOMER SERVICE on 1300 559 881 or email support@digiframe.com.au...
