Guest Internet GIS-R6 Quick Setup Manual

The Guest Internet Hotspot gateway products have Ethernet LAN ports that can
be used to connect wireless access points, Internet café kiosk computers, wired
hotel rooms and business center computers. The Internet (WAN) port must be
connected to the DSL or cable modem.
First connect the gateway as shown
in the diagram to configure it using
the setup wizard.
Connect your computer Ethernet
connector to the LAN connector
of the gateway. Your computer
Ethernet connector should be
configured for dynamic IP or as
a DHCP client. It cannot be used
with a fixed IP.
Connect the Internet
connector of the gateway
to the DSL or cable
modem LAN Ethernet
connector. The DSL or
cable router should have
the LAN network
connector configured as a
DHCP server. Check with
the equipment manual to
verify the LAN connector
configuration.
For operation the WiFi
Hotspot customers will
use the wireless
GIS-R6
network or kiosk
computers. Connect
connections
wireless access points
and kiosk computers
USE ONLY THE
to the gateway LAN
POWER SUPPLY
port via a switch.
SHIPPED WITH
THE UNIT TO
Additional wireless
PREVENT
access points are
DAMAGE
connected to the
Ethernet switch.
DO NOT DISCONNECT POWER
DURING RESET TO AVOID DAMAGE
Reset to Factory Defaults
: With the gateway powered up, use a paperclip to press the reset button
through the hole shown. Hold the reset button down for 10 seconds then release. All parameters will be reset.
Hotspot Gateway Product Setup - Quick Start Guide 1
Download the product manual at: http://www.guest-internet.com/gateway
DSL
Or
Cable
LAN port
Internet
port
Internet
Internet
Wireless
access
points
First Time Product Configuration
GIS-R6
Connect your laptop computer to one of the LAN ports of the gateway.
Connect the Internet port to your DSL router.
Open your computer browser. Instead of your login page you will see the
page shown below. This page is the SETUP WIZARD.
Product
Configuration
Configuration
computer
Optional rack
mount kit is
available
Reset
The setup process has four steps. Follow the instructions to type in the
information requested on each page. Then click on the button to go to the
next page. When the setup process is completed your personalized
wireless Internet service will be ready for your guests to start using. The
setup process is shown overleaf: flip this page over to start the setup
process.
Login to the Admin pages at any time. Connect your computer to the
12volt power supply
24 volts
For 110/220volts
gateway via an Ethernet cable to a LAN port. Then open your browser and
type in the URL:
The username is
with the wizard.
When the page opens select the option you need in the menu. See the
manual for more information about configuration.
Support@guest-internet.com
http://aplogin.com/admin
admin , and the password is the one that you entered
