PhotoBooth Setup Guide
009-1420-00
*009-1420-00*

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PhotoBooth INF5520 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for InFocus PhotoBooth INF5520

Summary of Contents for InFocus PhotoBooth INF5520

  • Page 1 PhotoBooth Setup Guide 009-1420-00 *009-1420-00*...

  • Page 2: Important Notes

    InFocus, In Focus, INFOCUS (stylized) and Mondopad are either registered trademarks or trademarks of InFocus Corporation in the United States and other countries. All other trademarks are the property of their respective owners. Any other trademarks, service marks, personal names or product names are assumed to be the property of their respective owners and are used only for reference.

  • Page 3: Table Of Contents

    Contents   IMPORTANT NOTES  ............................ 1   Trademark information  ............................ 1   Contents ................................ 2   Accessory Identification ............................. 3   PhotoBooth Assembly  ............................ 5   PhotoBooth PC Module Installation ..........................  5   Preparing the Flash Unit  ............................  5   Attaching the Flash Unit  ............................  8   Attaching the Pivot Arm ............................  1 0   Preparing the Camera .............................  1 1   Preparing the Wireless Trigger  ..........................  1 3  ...

  • Page 4: Accessory Identification

    Accessory Identification ® EOS Camera Canon Flash Unit Kit Sync Cord Hot Shoe Speed Ring Wireless Remote Shutter Kit ® Canon Super Clamp L-Bracket Half Pole Adapter Kit 18-30” (46-74cm) Pivot Arm with Camera Bracket Mondopad™ Mobile Cart Softbox Accessory Identification Page 3...
  • Page 5 The accessories which you receive depend upon the part number you ordered: INF-5520-PB-C INF-PBKit-NOMP AC Adapter Kit Camera Kit Flash Unit Kit Half Pole Hot Shoe L-Bracket Pivot Arm Mondopad** Mondopad Mobile Cart Mondopad PC with Photobooth Software installed** Remote Shutter Kit Softbox Speed Ring Super Clamp...

  • Page 6: Photobooth Assembly

    PhotoBooth Assembly PhotoBooth PC Module Installation If you ordered INF-PBKit-NOMP, you will need to follow these instructions to replace your Mondopad PC. Otherwise skip to the next section. 1. Locate the Mondopad PC module on the back of the Mondopad panel. 2.
  • Page 7 2. Attach the speed ring to the flash unit by aligning the slots of the speed ring to the front of the flash unit and turning clockwise until it is fully attached. Move the blue “lock” slider button to the locked position. 3.
  • Page 8 4. Insert the cable ends into the speed ring. 5. Secure the Velcro at each corner of the softbox to complete its rectangle shape. PhotoBooth Assembly Page 7...

  • Page 9: Attaching The Flash Unit

    NOTE: If your mobile cart does not have holes drilled into it as per below, please contact InFocus Support at: www.infocus.com/support. 2. Attach the Mondopad panel to the mobile cart as per the manufacturer’s instructions and the INF-MOBCART addendum located on the InFocus Support site (Direct link: https://portal.infocus.com/support/Product%20Pages/downloads.aspx?mic=INF5520&on=do wnloads).
  • Page 10 3. Attach the flash unit to the half pole using the knurled clamp screw. Tighten securely. Knurled Clamp Screw Tilt Head 4. Slide the half pole onto the L-bracket and adjust as needed. 5. Adjust the half pole above the Mondopad panel, allowing room for the camera. 6.

  • Page 11: Attaching The Pivot Arm

    Attaching the Pivot Arm WARNING: Do not attach the camera to the arm until it is fully positioned and locked into place. 1. Insert the stud into the super clamp and attach the super clamp securely to the pivot arm. 2.

  • Page 12: Preparing The Camera

    Preparing the Camera Note: For this section, you will need the Canon AC adapter kit, the Canon camera, camera lens and an SD card (required). Mode Dial Power Switch Lens Focus Mode Switch SD Slot Battery Door 1. Insert a SD card (not included) into the camera’s SD slot on the right-hand side of the camera, being careful to align the SD card appropriately.
  • Page 13 7. Attach the camera to the pivot arm securely. 8. Carefully loosen the pivot arm adjustment knob to make final adjustments to the camera’s position, being very careful of the camera. WARNING: Turning the adjustment knob will release the arm pivot points. Damage to the camera could occur, if the camera is allowed to fall.

  • Page 14: Preparing The Wireless Trigger

    Preparing the Wireless Trigger 1. Slide the battery door off. 2. Insert a 12V battery into the wireless receiver, being careful of the battery orientation, and slide the battery door back on. 3. Slide the wireless receiver onto the bottom of the hot shoe. 4.

  • Page 15: Taking A Photobooth Photo

    Taking a PhotoBooth Photo Cell Button Power Switch 1. Turn Mondopad ON. 2. Turn the camera’s power switch to ON and the Mode Dial to M (“Manual”). 3. Turn the flash unit’s power switch to the ON position. 4. Verify that the Cell button LED is off. If the Cell button LED is lit, press the Cell button to turn it off.

  • Page 16: Framing Images

    Framing Images 1. From the Mondopad home page, navigate to View & Share. 2. Open an image file. Note: Images created with PhotoBooth appear in the PhotoBooth folder. 3. Tap Annotations. Framing Images Page 15...
  • Page 17 7. Tap Frames from the menu. 8. Tap the frame you want for the image and tap OK. Framing Images Page 16...
  • Page 18 9. To save the image, tap Save JPG. 10. Type a name in the File Name field and tap Save. 11. Saved images can be viewed in the View and Share folder. Framing Images Page 17...

  • Page 19: Adding New Frame Files To Mondopad

    Note: Saved images can also be found in the following folder: Documents>Mondopad Documents. Adding New Frame Files to Mondopad 1. From within the Mondopad software, navigate and login to Extras. 2. Tap Minimize to go to the Windows Desktop. 3. Navigate to the Zoos>Files>Frames folder. 4.
  • Page 20 Note: For best results, PNG images should be the same resolution as the Mondopad (1920 x 1080) and have transparent centers. Framing Images Page 19...

  • Page 21: Accessing Additional Documentation

    Accessing additional documentation To complete the setup of this product and the Mondopad Collaboration software, please download the Installer’s Guide located at www.infocus.com/INF5520docs. Accessing additional documentation Page 20...

  • Page 22: Troubleshooting

    Troubleshooting The following table is meant to assist you with troubleshooting your PhotoBooth. It is not a comprehensive list. For the best troubleshooting advice, we recommend reviewing the manufacturer’s documentation associated with each part.  The flash unit is not turning on Verify that the modeling lamp mode is not set to OFF.
  • Page 23 The camera LCD monitor is displaying an error Refer to the camera manufacturer’s message. reference guide. For additional troubleshooting support, please refer to the original manufacturer’s documentation or contact: InFocus Corporation Technical Support 6am-5pm PST 877-388-8385 www.infocus.com/support Troubleshooting Page 22...
