Functional Diagram

The USB comport has the following setup:
» AV-Out
» 5V IN
» Data input
» Signal IN
Battery cover
Lens
Screen
Tripod thread
Due to limitations in the technology of the display production, single or few dark
or light dots might appear. This is not a defect and will not have any impact on the
recorded video or photo!
5
turn on video & images
Key Panel
Port Cover
Microphone
Status LEDs
Front LED
OCB-Contacts
Wifi/2,4 GHz Module
