HomeTroller Zee Quick-Start Guide
your internet router.
c) Connect the Z-Stick to one of the USB ports on your HomeTroller Zee
d) Connect the AC power adapter to your HomeTroller Zee to begin the boot process. Allow the unit to boot fully
(about 1 minute and 45 seconds).
Accessing the HomeTroller Zee Web Interface
Once the unit boots, you'll need to access the web interface to
set the system up. The method below should work with any
browser on any device (mobile or desktop).
a) Navigate to
http://find.homeseer.com
b) Click the "Search" button. Your HomeSeer system
should now appear at the bottom.
c) Click the IP address hyperlink to access your system's
web interface.
Set Your System Password
The system password screen will appear the first time you run your HomeTroller
to prevent unauthorized access to your unit.
Activate and Register Your HomeTroller Zee Online
Be sure to activate your HomeTroller Zee and register the unit to receive HomeSeer support. To do this, make you're
your unit is connected to the internet and follow these steps:
a) From the HomeTroller Zee web interface, use the pull down menus to navigate to the General Tab of the Setup
Area (TOOLS > Setup)
b) Click the "Register Online" button in the License section of the Setup screen and enter your license codes.
Note: License codes are included on a sticker on the bottom of your HomeTroller Zee.
Setting the Time Zone and Updating Your HomeTroller Zee
Be sure to set the time zone and check for updates and install any that are available. To do this, follow these steps:
Congratulations on your purchase! Your HomeTroller Zee is ready to put you in
control of your home. Please take a few minutes to read through this guide to
familiarize yourself with the steps required to set up your Z-Wave network and your
HomeTroller Zee.
STEP #1
– HomeTroller Zee Initial Setup
After you've created your Z-Wave network, you'll need to install your HomeTroller
Zee. Follow these steps:
HomeTroller Zee Hardware Installation
a) Unpack the HomeTroller Zee, Ethernet cable and AC power supply.
b) Connect the Ethernet cable to your HomeTroller Zee and to a network port on
Please do this now by following the prompts on your screen.
Page 1
Zee. You MUST set a system password
Advertisement
Related Manuals for HomeSeer HomeTroller Zee
Summary of Contents for HomeSeer HomeTroller Zee
- Page 1 Connect the Z-Stick to one of the USB ports on your HomeTroller Zee d) Connect the AC power adapter to your HomeTroller Zee to begin the boot process. Allow the unit to boot fully (about 1 minute and 45 seconds).
- Page 2 Example: US – America/New_York b) From the HomeTroller Zee web interface, use the pull down menus to navigate to the General Tab of the Setup Area (TOOLS > Setup). If an update is available, click the update button near to top of the page and wait for the update to download and install.
- Page 3 Click the ‘Start’ button below the Actions menu. Your HomeTroller Zee is now in inclusion mode and is ready to communicate with your battery operated device. e) Activate the network button (or button sequence) on your battery operated device and observe the inclusion process in the green log window.
- Page 4 Simply put, an automation event consists of an action (or actions) that are set into motion by one or more triggers. Example: Turning on lights at sunset. Trigger = sunset, Action = turning lights on. With HomeTroller Zee, you can quickly and easily create all the events you need.
- Page 5 STEP #8 – HSTouch Client Setup Here you will configure your settings and connect to your HomeSeer system to allow for control from your device. Follow the instructions below to set up the HSTouch Client. a) HSTouch will prompt you to select a server or settings.
- Page 6 Select the server you would like to have as your Home setup. d) Configure a Label for that HomeSeer system. Click Address to enter the IP Address or Domain of the HomeSeer System. e) Now that you have set up the connection address, go ahead and enter in your Username and Password for that server.
- Page 7 Registration a) Once the HSTouch has finished installing, go ahead and open it up. You will be prompted with a Log In to MyHS screen. b) Click Register. Your default browser will come forward and load the registration page. c) Enter in the preferred email address you would like to use to be tied to your MyHS for the Account Email Address.
- Page 8 Icon Legend for HS3 This is a list of the icons that are found in HS3 with a description of their function. Note: Some buttons are multi-functional. ICON DESCRIPTION Add / Delete Copy Event Standard Editing / Advanced Editing Toggle Edit Mode Enabled / Disabled Error communicating Expand / Collapse Section...
- Page 9 Into Z-Wave Network Device Failure Replace Device Z-Stick Failure Contact Homeseer Hometroller Zee Not Powered On Power Unit On Hometroller Zee Not Fully Booted Wait 2 Minutes For Unit To Boot HSDiscover Cannot Locate Device Hometroller Zee Not Connected To Connect Unit To Router And Reboot Door Locks Won’t Include Or Can’t...
