Description of Front Panel

[1] Power button -
activated by pressing either the remote control power button or toggling the front panel power switch. When the GIA-
275 is active, the LED indicator in the Standby button will illuminate BLUE. When the GIA-275 is in standby mode the
button will illuminate RED.
[2] 192kHz Indicator
'standard' resolution audio the indicator will not illuminate.
[3] IR Sensor -
The IR sensor receives signals from the remote control.
[4] mp3 Jack -
Mp3 players can be connected via the mp3 jack. This jack will accept a standard 3.5mm stereo
plug. The device connected to this jack will become the active device.
[5] Headphones Jack
the speakers will be disconnected when headphones are connected. The volume control can be used to adjust the
headphone volume when headphones are connected. This jack will accept a standard 3.5mm stereo headphone plug.
[6] Mute -
You can mute the GIA-275 by pressing the Mute button. Press it a second time or press Mute on the remote
control to un-mute.
[7] Volume Control
[8] Analog Input Select
rear panel. Press AUX2 to select the mp3 or other analog device connected to AUX2 on the rear panel.
[9] Digital Input Select
rear panel. Press D-2 to select the device connected to the D-2 Optical or Coax connector on the rear panel
[10] USB Input Select -
[11] Bluetooth Select
[12] Bluetooth Pairing
initiate pairing. LED will blink rapidly when GIA-275 is in pairing mode and ready to pair. LED will blink slowly when
paired with source device.
4
5 6
Toggles the GIA-275 in and out of Standby mode. When in standby mode, the GIA-275 is
-
When playing high resolution audio the LED indicator will illuminate BLUE. When playing
-
Headphones may be used through the use of the headphones output jack. Output to
-
Press AUX1 to select the analog device connected to the AUX1 Analog Inputs on the
-
Press D-1 to select the device connected to the D-1 Optical or Coax connector on the
Press to select the device connected to the USB Input on the rear panel.
-
Press to select Bluetooth as the input device.
– Press for 3 seconds to enable Bluetooth pairing. LED will blink slowly. Press again to
7
8 9 10
11 12
