Connect a Bluetooth Device to the GIA-275
1) Press the BT button [11] on the front panel to select Bluetooth input. The BT button LED
will illuminate blue.
2) Press the Pair button [12] on the front panel for 3 seconds, the Pair button LED will
illuminate blue and blink slowly.
3) Press the Pair button [12] a second time to make the GIA-275 discoverable and put it in
pairing mode. The Pair button will illuminate blue and blink rapidly when in pairing mode.
4) Enable Bluetooth on your source device (e.g., phone, tablet, laptop etc.) and put it
In search/pairing mode.
5) In 1-15 seconds you should see a Bluetooth product named ARM-HIC-SPDIF-720 on your
source device. Select it. Your source device will pair with the GIA-275 and should indicate
That it is connected.
6) Once connected, the GIA-275 BT button [11] will remain illuminated blue and the Pair
button [12] LED will continue to blink at a medium speed. If/when the Bluetooth source
device is disconnected or drops the connection because of poor reception, the blink rate
will slow down.
7) Play some music!
Note: Your Bluetooth source device will connect to the GIA-275 with the highest quality audio
connection available on the source device. To get the best quality sound you should use
maximum bitrate rips (preferably lossless) and a phone, tablet, laptop... that supports aptX.
For more information about aptX and devices that support it please visit www.aptx.com.
Connect The GIA-275 to your MAC
Prerequisite: OSX V10.6 or later, USB 2 or 3 port
If you wish to play high resolution audio (24 bit 192kHz) as well as CD quality 16 bit audio through
your MAC you can connect the GIA-275 to a MAC USB 2 or 3 port using the USB cable supplied with
the GIA-275. MAC OSX version 10.6 and later provide native support for USB Audio 2 and it is not
necessary to install a driver. Simply connect the GIA-275 to a MAC USB 2 or 3 port and follow the
instructions on the screen. There are a number of media players available that support high
resolution audio on the MAC.
Connect The GIA-275 to your Windows System
Prerequisite: Win XP, Vista, 7, 8 or 8.1, USB 2 or 3 port
Windows XP, Vista, 7, 8 and 8.1 provide native support for USB Audio 1 but do not provide support
for USB Audio 2. Therefore, if you wish to play high resolution audio (24 bit 192kHz) as well as CD
quality 16 bit audio through your Windows system, you will need to install the USB Audio 2 driver
from the CD supplied with the GIA-275. Once the USB Audio 2 driver is installed, Windows Media
Player can play standard quality audio through the GIA-275 (high resolution audio is NOT supported
by Windows Media Player). If you wish to play high resolution audio you will need to install a media
player such as Foobar2000 (free) or jRiver ($) (or others) in addition to the driver supplied with the
GIA-275.
Note that the GIA-275 must be connected to a USB 2 or USB 3 port on your PC. It will NOT work if
connected to a USB 1 port. USB 1 and 1.1 are too slow for high resolution audio.
