Summary of Contents for Voxx PRO9644E

Page 1: Table Of Contents
Model PRO9644E Owner’s Manual Table Of Contents: Features and Options Page 2 About Your "Code Hopping" Transmitters Page 3 Arming Your System Page 3 - 4 Protection While The System Is Armed Page 4 - 5 Disarming Your System Page 5 - 6...
Page 2: Features And Options
IMPORTANT! In order to provide the highest possible level of security to your vehicle, this system is equipped with selectable manual override circuitry. It is possible that you will need to manually override your security system if the transmitter becomes lost, or inoperative due to battery failure.
Page 3: About Your "Code Hopping" Transmitters
YOUR " CODE HOPPING" TRANSMITTERS The transmitters included with your new security system use the most advanced and secure form of radio frequency transmission available on any current automotive security system. Some of today’s sophisticated auto thieves use a device known as a code grabber, which will receive and store the signal from your keychain transmitter, and retransmit at a later time to disarm your system.
Page 4: Protection While The System Is Armed
SILENT ARMING - ACTIVE 1. Turn off the engine, exit the vehicle, and close all doors, hood lid, and trunk lid. 2. Press and hold the Lock button on the keychain transmitter for 2 seconds.  Dash mounted LED begins to flash slowly. ...
Page 5: Disarming Your System
left a door opened, the alarm will sound for six 30 second cycles, remain armed and ignore that triggered zone.  Whenever the system is armed, the dash mounted LED indicator will slowly flash. This serves as a visual deterrent to the potential thief. The LED is a very low current bulb and will not cause the vehicle’s battery to drain, even when left unattended for extended periods.
Page 6: While The System Is Sounding
 Headlight Illumination - Optional  Illuminated Entry Upon Disarm SILENT DISARMING 1. As you approach the vehicle, press and hold the Unlock button on the keychain transmitter for 2 seconds.  Dash mounted LED turns off. If passive arming was selected during the installation, then the LED will start flashing rapidly, indicating that the system is rearming automatically.
Page 7: Push Button Led/Valet/Override/Programming Switch
 If the LED is flashing one time...pause...one time...pause...etc., then an intrusion attempt was made to the shock sensor, or an accessory triggering device that may have been added to the system.  If the LED is flashing two times...pause...two times...pause...etc., then an intrusion attempt was made to a hood or trunk pin switch that was added to the system, or to a light activated entry point if the alarm was installed using the voltage sensing feature.
Page 8: Programming Your Custom Override Code
3. Within 5 seconds, press and release the PBLED override switch. The alarm system will stop sounding and enter the (bypassed) mode. You can now start and operate the vehicle normally. Typically this override mode is used only if the transmitter has become inoperative. Programming Your Custom Override Code: Unlike override switches easily found, and defeated, this security system allows the consumer to program a personal override code, offering a higher level of security.
Page 9 Custom Code Programming Example: To Change the code from the factory pre-assigned code of 11 to “52” you would do the following: 1. Disarm the system by use of the transmitter, or by use of the emergency override sequence. 2. Turn the ignition switch to the on position. 3.
Page 10: Using The Custom Code Override
MANUALLY OVERRIDING YOUR SYSTEM USING THE CUSTOM CODE OVERRIDE Assuming the override code programmed has not been changed, and the default override code of 11 is in the system's memory. 1. Enter the vehicle and turn the ignition switch to the on position. NOTE: The siren will sound.
Page 11: Additional Remote Function (Channel 3)
1. Press and hold the ARM or DISARM button on the keychain transmitter for 3 or more seconds. The alarm will immediately sound. 2. To stop the alarm, press and hold the ARM or DISARM button on the transmitter again for 3 seconds. If the button is not pressed, the alarm will automatically stop after 30 seconds.
Page 12: Ignition Controlled Lock/Unlock
To activate the optional accessory, press the programmed button on the keychain transmitter for up to 8 seconds for continuous output, or press and release for momentary activation. The optional accessory will immediately engage. Check with your installation center for more information on the optional accessory that may have been installed and how it is accessed.
Page 13: Programming New Or Replacement Transmitters
PROGRAMMING NEW OR REPLACEMENT TRANSMITTERS (BANK 1) The Transmitter Model Name 143BPr Is Also Found On The Back Of The Transmitter Case Battery Use CR2032 1. Turn the ignition key to the on position. 2. Press and release the valet/programming switch 3 times (Siren Chirps). 3.
Page 14 Two Vehicle Operation From One Remote Control This remote has the ability to operate 2 similar alarms from a single remote transmitter. To toggle on and off vehicle one or two,,, Press the Trunk/Key button + the Lock button for 5 seconds. The LED flashes 2 times.
Page 15: Transmitter Battery Replacement
Transmitter Battery Replacement: 1. Locate and remove the "00" point philips head screw on the back of the transmitter case. 2. Carefully separate the front case from the rear. 3. Slide the CR2032 battery out from under the battery clip and dispose of properly.
Page 16: System Functions At A Glance
 Valet Switch Override  Illuminated Entry Upon Disarm To purchase replacement transmitters or to get additional product information go to: www.pursuitcarsecurity.com © 2014 Voxx Electronic Corporation, 150 Marcus Blvd., Hauppauge, N.Y. 11788 128-9317 Page 16 128-9317 16 of 16...
