Dometic Caravan RM 7501 Manual page 8

Cut out opening for the
side vent L500
is 451 x 341 mm.
L205: 451 x 156 mm.
min. ventilation
height
Cut out opening for the
side vent L500
is 451 x 341 mm.
40
Batten
attached to
the floor
FIG. 3a
20
Ventilation heights
Minimum ventilation heights in mm.
Model
Upper side vent L205
Lower side vent L500
RM 7501 1400
VENTILATION OF THE UNIT
Sealing gasket
e.g. of V-type
This piece is
already on the
60
refrigerator
Condenser
385
min. 510
Sealing gasket
e.g. of V-type
Floor
Installation with
Upper side vent L500
Lower side vent L500
1400
Cut out opening for the
roof vent R500
is 507 x 87 mm.
min. ventilation
height
Cut out opening for the
side vent L500
is 451 x 341 mm.
FIG. 3b
FIG. 3c
Roof vent R500
Lower side vent L500
1250
Condenser
min. 510
20
Batten attached
to the side wall
Sealing gasket
e.g. of V-type
View from above
Door
17
