Conceptronic C4CHCCTVKIT Manual

4 channel cctv surveillance kit, mobile viewer
Hide thumbs Also See for C4CHCCTVKIT:

Advertisement

Quick Links

Download this manual See also: User Manual

Mobile Viewer

Manual
4 Channel CCTV Surveillance Kit
C4CHCCTVKIT
V1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the C4CHCCTVKIT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Conceptronic C4CHCCTVKIT

Summary of Contents for Conceptronic C4CHCCTVKIT

  • Page 1: Mobile Viewer

    Mobile Viewer Manual 4 Channel CCTV Surveillance Kit C4CHCCTVKIT V1.0...

  • Page 2: Instructions Of Android

    Instruction for mobile monitor Asee This module has mainly instructions on the installation and usage for Android, Blackberry, IPhone mobile phones. 1) The acquisition of client software: The client software can be obtained from the CD material supplied, then choose English and select the options supporting tools.
  • Page 3 1.1.2 Installation and operation instructions 1）Installation Support two installation modes and the user can choose one way for installation. 1. Install online Search ASee+ on Google market and install online. As the below image shows: 2. Install offline Copy the Asee.apk installation package to Android phone through cable. In the specified directory find out the corresponding .apk, click the application installation (If there is not installed apk installer in the mobile phone, the user needs to download an apk installation software so that it can identify the apk package), and the program icons will appear after the installation is finished.
  • Page 4 The functions of buttons show as follows: Table 1-1 Function keys Definition Function specification Play When the program connects with device, play video Capture the current screen(the default save path: the default pictures Capture directory of mobile) Set some information of the device, such as IP address, dynamic domain Settings name, port, username, password and device alias information.
  • Page 5 Zoom Zoom in/out control of PTZ. Focal length Focal length adjustment of PTZ. Aperture Aperture control of PTZ. 4）If it is first running or need to change the parameters, please click the <settings> button and enter the <Device List> page, as shown in the below image. In <device list>interface, click <Add>...
  • Page 6  <Password>：The password of the user (default password is empty).  <Max Channel>: The actual channel numbers of DVR. 5）After finishing, click <OK>and enter the Device List page. As shown in the below image Notes：  <Back>：Back to the screen of previous image. ...
  • Page 7 2. Full screen mode occurs when mobile phone is laid down horizontally, whereby it will automatically switch to full screen mode, as shown in the above image. 7）Channel switch function Select some channels in the Device List interface; the program will automatically switch to the Preview Interface and open the corresponding channel preview in Preview Interface.

  • Page 8: Instructions Of Blackberry

    2 Instructions of Blackberry 2.1 Essential condition 1) Supports version 4.6 or above of Blackberry system, and mobile phone screen resolution is 480*360 and 480*320. Supports 8900, 9000, 9700, 9630, 9900 of Blackberry. 2.2 installation 1） Install ASee. cod and ASee. jdp installation package into Blackberry handset through the desktop manager, as shown in the below image.
  • Page 9 Note： Some permissions cannot be set <permit> (the gray options mean cannot change this option), and click “save”. 4）Enter the initial interface Click the program icon <Asee>, after running procedure there will be a welcome page, then enter the initial interface, as shown in the below image.
  • Page 10 exit Exit the program Device list Enter the device list interface. 5) Click <login>, play the main interface, as shown in the below image. The corresponding functions of buttons in <Main interface> show as follows: Function keys Definition Function specification Play When the program connects with device, play video Full screen...
  • Page 11 Left control of PTZ The left direction control of PTZ Right control of PTZ The right direction control of PTZ Zoom in The zoom in control of PTZ. Zoom out The zoom out control of PTZ. Focal length + Amplify the focal length of PTZ. Focal length - Lessen the focal length of PTZ.
  • Page 12 The corresponding functions of buttons in < device edit> interface show as follows: Menu definition Function specification Set to real-time preview When the program connects with device, play video. New Device Create a new record. Edit Edit record. Delete Delete the selected record. Delete All Records Delete all records.
  • Page 13 2）Click the program icon Asee+ and the initial interface after running procedure is shown in the above image. The corresponding functions of buttons show as follows: Function keys Definition Function specification Stop When the program disconnects with device, stop playing the video. playing Capture the current image (the default save path: the default pictures Capture...
  • Page 14 Zoom Zoom in/out control of PTZ. Focal length Focal length adjustment of PTZ. Aperture Aperture control of PTZ. 3）Initial usage of need to change the parameter 1. Please click the settings button and enter the device manage interface, as shown in the below image. 2.
  • Page 15  <Port>：The mobile phone port set in DVR（default parameter is 8888）.  <User ID>：The username permitted to login the DVR（default username is ‘admin’）.  <Password>：The password of the user (default password is empty).  <Max Channel>：The actual channel number of DVR. 3.
  • Page 16 6. Click the button to view all channel numbers, as shown in the above image. 7. Double click any channel, then switch to the <channel preview> interface to preview channels, it can support four channels previewing at the same time, as shown in the below image. 8.
  • Page 17 （2）Slide rightly the <edit> button to delete the information. As shown in the above image. 4）Video display mode There are two modes: common mode and full screen mode Switch: when the mobile phone is laid down horizontally it will automatically display full screen. common mode full screen mode 5）Channel switch function...

  • Page 18: Instructions Of Symbian

    the channel is selected <Channel switch> button in the <preview interface>, the channels group will switch to 5 ~ 8, 8 ~ 12, 12~16 and circulation switch. As shown in the below image. 4 Instructions of Symbian 4.1 Essential condition 1) Support version OS S60 or above of Symbian system.
  • Page 19 click PTZ show as the following figure The functions of buttons show as follows: Function keys Definition Function specification Play/pause When the program connects with device, play video Capture the current screen(the default save path: the default pictures directory capture of mobile)
  • Page 20 Set some information of the device, such as IP address, dynamic domain name, settings port, username, password and device alias information. Full screen For this channel full screen. pervious/next Pervious to the former channel, next to the latter channel exit quit current software Choose one video channel of the device.
  • Page 21 Notes: 1)<server address>：The public IP address, dynamic domain name or LAN IP of DVR (The port should be mapped before using public IP and mobile phones need to open wifi before using LAN IP). 2)<port>：The mobile phone port set in DVR（default parameter is 8888）. 3)<user ID>：The username permitted to login the DVR（default username is ‘admin’）.
