USER GUIDE
AC Master/Slave Flash Kit
NS-DACMSFK
Before using your new product, please read these instructions to prevent any damage.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NS-DACMSFK and is the answer not in the manual?

Questions and answers

Related Manuals for Insignia NS-DACMSFK

Summary of Contents for Insignia NS-DACMSFK

  • Page 1 FINAL FOR PRINT NS-DACMSFK_14-1397_V3_MAN_ENG.book Page i Thursday, December 4, 2014 10:15 AM USER GUIDE AC Master/Slave Flash Kit NS-DACMSFK Before using your new product, please read these instructions to prevent any damage.

  • Page 2: Table Of Contents

    One-year limited warranty - Insignia ........

  • Page 3: Introduction

    NS-DACMSFK_14-1397_V3_MAN_ENG.book Page 3 Thursday, December 4, 2014 10:15 AM AC Master/Slave Flash Kit Introduction Congratulations on your purchase of a high-quality Insignia product. Your NS-DACMSFK represents the state of the art in master/slave flash technology and is manufactured for reliable and trouble-free performance. Features •...

  • Page 4: Flash Head

    NS-DACMSFK_14-1397_V3_MAN_ENG.book Page 4 Thursday, December 4, 2014 10:15 AM NS-DACMSFK AC Master/Slave Flash Kit Flash head Front Back Item Description 1 Flash window Covers the flash tube. Connect a PC sync cable to this jack and to your camera’s PC flash 2 PC sync cable jack sync jack, then set your camera to flash or sync mode.

  • Page 5: Light Holder

    NS-DACMSFK_14-1397_V3_MAN_ENG.book Page 5 Thursday, December 4, 2014 10:15 AM AC Master/Slave Flash Kit Light holder Item Description Screw the AC power plug on the bottom of the flash head into this 1 Power socket socket. 2 Umbrella mounting hole Insert an umbrella through this hole. Loosen this knob, tilt the light holder up or down to adjust the angle, 3 Angle adjustment knob then tighten the knob.
  • Page 6 NS-DACMSFK_14-1397_V3_MAN_ENG.book Page 6 Thursday, December 4, 2014 10:15 AM NS-DACMSFK AC Master/Slave Flash Kit 3 Place a light holder onto the top of a light stand, then tighten the light holder knob. 4 Screw the AC power plug on the bottom of a flash head into the power socket on the light holder.
  • Page 7 NS-DACMSFK_14-1397_V3_MAN_ENG.book Page 7 Thursday, December 4, 2014 10:15 AM AC Master/Slave Flash Kit 5 Loosen the umbrella mounting knob on the light holder, insert an umbrella though the umbrella mounting hole, then tighten the knob. Slide the tab on the umbrella handle over the tab to open the umbrella. Umbrella mounting knob...

  • Page 8: Using Your Flash Kit

    NS-DACMSFK_14-1397_V3_MAN_ENG.book Page 8 Thursday, December 4, 2014 10:15 AM NS-DACMSFK AC Master/Slave Flash Kit Using your flash kit To use your flash kit: 1 Assemble your flash kit. See “Assembling your flash kit” on page 5. 2 If you are not using a PC sync cable, position the flash heads so that the light sensor on your flash head has a clear line-of-sight to the camera’s flash.

  • Page 9: Troubleshooting

    10 to 20 minutes. Replacement parts For a list of replacement or spare parts go to insigniaproducts.com. In the Search for Keyword/SKU box, enter your model NS-DACMSFK, then press ENTER. Specifications Specifications are subject to change without notice.

  • Page 10: Legal Notices

    NS-DACMSFK_14-1397_V3_MAN_ENG.book Page 10 Thursday, December 4, 2014 10:15 AM NS-DACMSFK AC Master/Slave Flash Kit Legal notices FCC Part 15 This device complies with Part 15 of the FCC Rules. Operation of this product is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 11: One-Year Limited Warranty - Insignia

    Product at no charge with new or rebuilt comparable products or parts. Products and parts replaced under this warranty become the property of Insignia and are not returned to you. If service of Products or parts are required after the Warranty Period expires, you must pay all labor and parts charges.
  • Page 12 7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2014 BBY Solutions, Inc. All rights reserved. INSIGNIA is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners.
