Summary of Contents for roadeyescams recduo
-
Page 2: Table Of Contents
Table of Contents A. Features ..................1 B. Specification .................. 2 C. Structure of Product ..............4 D. Dimension ..................4 E. Installation Guide ................5 F. Functions of Remote Controller ............. 6 G. Start / Stop Recording ..............10 H. -
Page 3: Features
A. Features Suitable for all personal vehicle, taxi, bus, truck…… Small size, easy installation and dismount, it does not affect the driver's line of sight. Insert the card and power on to start recording without additional operating. Simultaneously recording interior and exterior condition. Having full time, date recording and display on the screen directly. -
Page 4: Specification
B. Specification Item Specification Chipset H.264 image compression chip Sensor Forward facing lens: VGA CMOS Sensor. Device Backward facing lens: VGA CMOS Sensor. Outside vehicle approx : 120 degree View Angle Inside vehicle approx : 170 degree Please use 5V±5%, 1A Cigarette lighter adapter. The machine Voltage needs 4.7v to start. - Page 5 (a) The GPS positioning speed will be influenced by solar film of the front windshield, weather or other environment factors. (b) Starting and closing time of infra red will be subject to light intensity, the installation location, front windshield and other factors ...
-
Page 6: Structure Of Product
C. Structure of Product Remote Control Receiver Force Recording Button IR LED Backward Facing Lens Indicator Light Sensor Recording Indicator DC5V(2) DC5V(1) GPS Mouse MICRO SD Video Out Forward Facing ※ Please do not plug the power in both micro-USB terminals. The machine might be damaged. -
Page 7: Installation Guide
Installation Guide Make the bracket facing Assemble the suction cups. Set up the machine in proper upward. position. Adjust the viewing angle. Plug the power cable to socket on photo No. 5 or No. 6, please do not plug in both sockets at the same time) Plug in the cigarette When the power is Force Record button: Light... -
Page 8: Functions Of Remote Controller
F. Functions of Remote Controller Button Function Description Force Manually establish a recorded file which Recording cannot be overwritten. Button Mode Full screen / Half screen spilt shift Button Menu Firmware version of the device displayed Button Mute Button Voice recording On/Off Select the file or enter the password Up key number... - Page 9 ◆ Introduction of OSD Interface: (Video output from connecting TV- OUT line to the device) GPS-Sensor is working well Forward facing lens GPS positioning (Recording) Voice recording on Backward facing lens (Recording) Inner view CH(CH2) Front view (CH1) GPS Information 1.
- Page 10 Front View (CH1) Inner View (CH2) Dual CH Display With GPS Information 4. When turns to Live screen, it could click via remote control to show Firmware version. 5. In the LIVE screen you can choose whether open the recording, click the mute button on the remote control icon will appear top right of the screen, that means stop recording;...
- Page 11 ◆ On Screen Playback Instructions: Force Recording G-SENSOR Enter the playback page to stop recording 1. Click the remote control in the playback page select the time you want to play the file. 2. Click the remote control select the next file page of playback list. 3.
-
Page 12: Start / Stop Recording
G. Start / Stop Recording When power on the device, the screen will show a welcome message for the device starts if connected to TV-Out. The firmware version of the device will displayed before LIVE view of recording starts. 1. Power on / Start Recording The device can be started completely after power on for one minute. -
Page 13: Software Player Instruction
H. Software Player Instruction How to read the files from Micro SD card? Open the plastic Remove the card Insert the Micro SD Connect the card lid. from the machine. card into the card reader to the PC reader (please and use the make sure the software in CD to... - Page 14 Play & Settings Icon Instruction: play previous file play previous frame play backward Pause Stop Play Play next frame Play next file Open file Disk back up Google map Setting Snapshot Format Micro SD Card Disk Backup Save the recorded files to your PC. Click on the button and it will pop up the screen as below.
- Page 15 Step1: Select the origin for the Micro SD card Setp2: Select the recorded file which you want to backup Step3: Choose the backup file format (1)Micro SD Card Backup (*.sd) (2)AVI File Backup (*.avi) Backup format： (1) Micro SD card backup format Micro SD Card File type (*.sd) (2)AVI File Backup(*.avi) Chn01 is the forward facing lens record.
- Page 16 with location of GPS (longitude and latitude), speed and G- SENSOR. If backup by the format of *.avi, the file recorded date, video and audio. We suggest to backup by using original format of Micro SD card. Step4: Backup Path: Select your backup destination (e.g.: C:\blackbox) Step5: Backup : Start backup the file to your specified destination ...
- Page 17 Set the recording frame rate for inside camera (5 / 10 / 15)fps The license plate number information can be input here, the film is easy to identify Information which vehicles to record video record (only English letter and number acceptable. This feature of the Micro SD card encryption, to prevent others from accessing any data.
- Page 18 Snapshot While playing the recorded file, you can use this function snapshot the picture and save it into your PC. Default saving path for snapshot picture will be in /Snapshot folder. File type: BMP Speed Meter & Volume Direction Speed Meter Latitude &...
-
Page 19: Formatting Memory Card
Formatting Memory Card When You Should Format Micro SD CARD? When you use the Micro SD card for the first time or just purchase a new card, you should format it in order to use it correctly. (The bundled Micro SD card has been formatted and tested by the manufacturer already.) Notice: 1. - Page 20 Windows XP Windows 7 3. When formatting is completed, please insert the card into the machine for recording. Open the plastic Insert the Micro Press the Micro Close the plastic lid . SD card in correct SD card in until it lid.
-
Page 21: Restoring Memory Card
J. Restoring Memory Card When you have backup the recorded files into PC and want to use the Micro SD card for other purposes, you have to restore it first so it can be used correctly. Notice: 1. Before formatting Micro SD card, please ensure to unlock it first. 2. - Page 22 Windows XP Windows 7...
