Summary of Contents for roadeyescams rec pro
-
Page 2: Table Of Contents
Index A. Feature Description .................. 1 B. Schematic Diagram Of The Installation Steps .......... 2 C. Specification ..................... 3 D. Product Appearance ................. 4 E. Recording And Stop Recording ..............5 F. Remote Controller Description ..............6 G. Main Menu Operating Description ............7 Main Menu Table Switch ............... -
Page 3: Feature Description
A. Feature Description ․ Build-in Full HD 5M CMOS Sensor. View angle approx. 105 degrees. ․ Easy installation. Suitable for all types of vehicles. ․ Equiped with 3 inch TFT LCD screen provides a platform for composing and playing back your footage, while the fixed focus lens keeps things simple. -
Page 4: Schematic Diagram Of The Installation Steps
B. Schematic Diagram Of The Installation Steps Two types of brackets installation for selection，Suction-cups type and Stick-holder type. A. Suction-cups type Make the bracket facing upward, assemble the suction cups, setup the machine in proper position, adjust the viewing angle. B. -
Page 5: Specification
C. Specification Items Description Chipset Ambarella H.264 image compression chip Sensor Device Full HD 5M CMOS Sensor View Angle View angle approx. 105 degrees. Start at 5V±5% ; 650mA, Voltage Remark: Please use 5V±5%, 1A Cigarette lighter adapter. The machine needs 4.8v to start. -
Page 6: Product Appearance
D. Product Appearance UNIT:mm Product Dimensions Monitor open Monitor close... -
Page 7: Recording And Stop Recording
E. Recording And Stop Recording Green indicator Red indicator Blue indicator Manual Force Recording Yellow indicator 1. Power on / Recording: Wait around 30 seconds after power-on to start up the machine. The recorder will be started while power supply acts after one minute. Green light indicator will keep on when the recorder is in power-on mode. -
Page 8: Remote Controller Description
F. Remote Controller Description Key mapping table for remote controller: Play back Camcorder/cam Manual Force Recording era mode switch Volume down Volume up Stop voice Mute Menu Confirm Up / Down / Left / Right Fast Rewind Fast Forward Play Stop Pause / Step... -
Page 9: Main Menu Operating Description
G. Main Menu Operating Description ● Main Menu Table Switch First stage- Main menu operating key description Moving menu options [Up/Down Key] Selecting items [Left/Right Key] Selected the item、confirm setting [Confirm key] Enter index、back to previous menu [MENU key] ● Setup Menu Description Language ★... - Page 10 Date / Time Menu Options [Up/Down Key] Selecting Options [Left/Right Key] Enter Selecting Items [Confirm Key] Back to Top Menu [MENU Key] Time Zone ★selecting the proper time zone for your position TV standard ★NTSC/ PAL for selecting Frequency ★50Hz/ 60Hz for selecting...
- Page 11 Mic. ON/OFF ★ OFF/ ON White Balance ★ Five ambient light option for selecting Auto / Daylight / Cloudy / Fluorescent / incandescent light Auto Auto (default) Daylight For sunny day. cloudy For cloudy, dusk weather, dawn. For warm white, cool white (3-wavelength) Fluorescent fluorescent lighting.
-
Page 12: Camcorder Menu Setting
Sensitivity ★Caution：You can adjust the sensitivity level (more number of green bars stands for higher sensitivity) Format ★cancel format / confirm format 11. Back to Default Setting ★ cancel default setting / confirm default setting ● Camcorder Menu Setting 1.Resolution setting ★three kind of resolutions for selecting：1080P(30) /720P(60)/ 720P(30) Second stage- menu setting key description... -
Page 13: Camera Menu Setting
2. Quality setting ★Caution：You can adjust the video quality level (more number of green bars stands for higher quality) 3. G-sensor sensitivity setting ★Caution：You can adjust the G-sensor sensitivity level (more number of green bars stands for higher sensitivity) ★When emergency record is triggered, it will keep around 3 minutes emergency recording and keep the files without being overwritten ●... -
Page 14: Play Video Files
3. Capture period setting ★Select NOR to set capture period function。 ★Capture period:30 seconds/1 minute/5 minutes / 30 minutes for taking one frame 4. G-sensor sensitivity setting ★Caution：You can adjust the G-sensor sensitivity level (more number of green bars stands for higher sensitivity) ... - Page 15 1. Delete one record 2. Delete all data 3. Protect Recording Data ★PS. The data is protected successfully while the locked image shown. (b)Photo playback/viewing mode Press” Playback” key on remote controller under capture mode, select the file you want to play. Photo rotation [confirm key] Select next/pervious photo...
- Page 16 1. Delete one record 2. Delete all data 3. Protect Recording Data ★PS. The data is protected successfully while the locked image shown. 4. Auto play...
-
Page 17: Software Operating Instruction
(3)How to read the file from SD card in the computer side? 1、Remove SD card from card slot of host side 2、Put the SD card to the card reader 3、Connect card reader to the USB port of PC side 4、Choose the file to play: Execute “IBoxPlayer.exe” ，which is located in the product CD folder, Screen shown as below. - Page 18 Pause key Go to next file key Stop key Play key Forward playback Rearward playback Mark starting point of back up file Mark ending point of back up file Backup the marking file Open document, select the file to play Backup the current playing file Snapshoot tool Google map...
- Page 19 Driving Speed Play BAR: Press left button of mouse and move around to pull BAR with fast-moving. Playback speed fast forward with 2 times or 4 times, and playback with 0.25 times, 0.0625 times Volume control 4.
- Page 20 6. Snapshoot Tool Play record from SD card first and then use Snapshoot tool to capture the screen. When select Snapshoot tool, it will appear the following window. (The picture of display screen will save in capture storage folder path.) 7.
- Page 21 8. Related settings Software version related information and SD card data storage settings (a) Storage path of Snapshot: the location to save images in the computer (b) Language: select language settings of playback software. (The settings will work after re-open the software) (c) The mode of User Interface：Set the display mode of host.
-
Page 22: Formatting Memory Card
I. Formatting Memory Card When should you need to format the SD card? When you purchase a new SD card, you have to format it in order to use for Vehicle video recorder. Procedures for new SD card formatted as follows: 1.
