APPROX.DIMENSIONS:
Height - 1800mm
Width - 1550mm
Length - 1550mm
Operators Handbook
Serial No.
Manufactured in the U.K. by Northern Leisure Group Ltd./Kiddy Rides Tel: +44 (0) 113 239 38 03 Email: info@kiddyrides.uk.com
Northern Leisure Group Ltd.
www.kiddyrides.uk.com
www.kiddyrides.uk.com
Peppa Pig Carousel
Peppa Pig Carousel
Peppa Pig Carousel
Date of Manufacture
3 Seater
Advertisement
Table of Contents
Related Manuals for Kiddy Rides Peppa Pig Carousel
Summary of Contents for Kiddy Rides Peppa Pig Carousel
- Page 1 Peppa Pig Carousel 3 Seater APPROX.DIMENSIONS: Height - 1800mm Width - 1550mm Length - 1550mm Operators Handbook Serial No. Date of Manufacture Manufactured in the U.K. by Northern Leisure Group Ltd./Kiddy Rides Tel: +44 (0) 113 239 38 03 Email: info@kiddyrides.uk.com...
-
Page 2: Table Of Contents
CONTENTS Parts List - Upper Shell Introduction Parts List - Base Components Safety Matters Decals / Sticker Sets Initial Inspection Contact Procedures Initial Operation Orders Spares Siting Your Ride Repairs Hours of Business Daily Checks 22,23 Ride History / Log Taking Care Of Your Ride 24,25 Your Notes... -
Page 3: Introduction
Kiddy Rides supplies a wide range of children’s rides for sale, income share, or on a fix ed rental basis. As well as supplying the rides, it is responsible for unbeatable after-sales support and servic e for all Kiddy Rides customers as well as other operators. -
Page 4: Safety Matters
Safety Matters Northern Leisure/Kiddy Rides is a registered Inspection Body of ADIPS (the Amusement Device Inspection Procedure Scheme), conducting independent examinations and certification of children’s coin operated rides in accordance with guidance published by the Health and Safety Executive (HSE). By independent, we mean we are not linked to any particular manufacturer and will apply the guidance with equal diligence, regardless of the type of ride, or it’s manufacturer. -
Page 5: Initial Inspection
INITIAL INSPECTION Upon arrival of the machine, it is important to check the following items: a. Damage to external packing. b. Physical damage to the ride. c. Correct documentation is present. d. Ride Serial Number. e. Correct main’s voltage rating Coin mechanism currency and credits Any damage or discrepancies should be reported to your supplier immediately. -
Page 6: Siting Your Ride
SITING THE RIDE The following conditions must be observed when siting the machine: a. The machine must be placed on level ground which is firm and free from any holes etc. Where possible, a non-slip surface would be recommended. b. The ride is designed for protected locations. The ride should not be sited in any area where it would be subjected to water splash. -
Page 7: Daily Checks
DAILY CHECKS A check of each coin-operated Kiddy Ride should, whenever reasonably practical, be carried out each day before it is made available for public use. The following checks are recommended: a. Check that the mains plug is undamaged and securely attached to the mains cable, with no visible wires. -
Page 8: Taking Care Of Your Ride
Alternatively, a household furniture polish can also be used, or in cases of an extremely dirty ride, Kiddy Rides recommend using a good automotive cleaning compound. This material is available through Northern Leisure / Kiddy Rides. Do not use any solvent based materials when cleaning your ride. -
Page 9: Standard Operation & Adjustments
Standard Operation And Adjustments Control Box / Timer - The control system in this ride is a Low Voltage ‘Kermit Navigator’ box. This is located inside the centre column. It is accessed by removing the 4 bolts around the lid on the top of the column and lifting it upwards. -
Page 10: Price Of Play
Standard Operation And Adjustments PRICE OF PLAY - The price of play is the cost of each turn on the ride, e.g. 1 ride for 50p. The cost per ride and currency is set at manufacture, and the operator’s preference must be stated at the time of purchase. -
Page 11: Coin Mechanism
THE COIN MECH In order to ensure maximum efficiency from your coin mech it is essential to pay regular attention to the cleaning of the coin pathway. Before attempting to clean or remove the mech, the machine should be switched off. Any cleaning should be carried out by using a soft damp cloth. The surface should always be left clean and dry after such cleaning. -
Page 12: Fault Finding
FAULT FINDING To be carried out by a competent person. CHECK SYMPTOM Mains voltage supply. Mains supply to control box. Green 4-way plug on control box. No lights / self test message 2x yellow wires into 4-way plug. Break in yellow wires to button lamps. Check mains power is on. -
Page 13: Full Wiring Schematics
...... -
Page 14: Removal Of Body Shell
Ensure the power is turned off before carrying out any of the following procedures! Disconnecting The Loom The Wiring Loom is made up of 2 separate sections, a Top Loom, and a Base Loom. The two separate looms are joined together in the top of the ride using a 4-way M-Lock Connector. This connector can be found inside the centre column to the rear of the cash box assembly. -
Page 15: Base Mechanism
240V OUT Fuse Reference table overleaf... - Page 16 To Top Slipring & Brush Set Rotation MAINS OUT TO MOTOR MAINS IN Description Ref. No. Title Base Chassis Steel Frame Work 3 Phase Motor Carousel Gear Motor Gearbox Carousel Gear Box 3 Phase Inverter AC Drive / Inverter Base PSU Base Power Supply Slip Rings Small 4-Way Slip Rings...
-
Page 17: Wiring Loom Ref
Top Loom Reference - refer to diagram. Colour Ref.: Button / Destination: Plug / Pin No: P4 / 6 Black Start (switch common) Start P4 / 19 Pink Colour Ref.: Use / Destination: Plug / Pin No: Start Lamp + P4 / 18 P4 / 5 Start Lamp -... -
Page 18: Base Loom
Base Loom Reference - refer to diagram. MAINS SUPPLY Colour Ref.: Use / Destination: Plug / Pin No: +240V Mains In, PSU Inlet, IEC(M) Brown -240V Mains In, PSU Inlet, IEC(M) Blue Yellow / Green Inlet, Ground Earth MOTOR SUPPLY Brown PSU, A.C.Drive IEC(F), A.C.Drive (L) -
Page 19: Light Sequencer
Light Sequencer Reference - refer to diagram. Colour Ref.: Use / Destination: Plug / Terminal No: +12V A.C. P11 / 1, P10 / 1 -12V A.C. Black P11 / 2, P10 / 2 P12 / 1 Yellow Lamp Common Lamp 1, 7, 8, & 14 P12 / 2 Blue White... -
Page 20: Parts List - Upper Shell
Parts List - Upper Body DESCRIPTION OF PARTS QUANTITY ITEM REF. Coin Mech Mech RM5 Evolution Coin Mech Mini Face Plate Mini Face Plate Coin Mech Metal Face Plate Small Metal Face Plate Cash Door Cash Door Cash Box Universal Defender Cash Box Meter / Counter Base Meter Speaker... -
Page 21: Parts List - Base Components
Parts List - Upper Body Cont... Perspex Panel Plain Perspex Panel Aluminium Entrance Step Aluminium Edge Plate (297mm) Perspex Fixing Screws T15 Security Screws Body To Base Fixing Bolts Body-Base Bolts Parts List - Base Components *See also page 15 for detailed base reference DESCRIPTION OF PARTS QUANTITY ITEM REF. -
Page 22: Decals / Sticker Sets
Decals / Sticker Description Peppa Pig Logo Tower Canopy Start Button Legend Tower S t a r t Border Car Tower Canopy Border Boat Tower Canopy Border Rocket Tower Canopy Graphic 1 Graphic 2 Graphic 3 Graphic 4 Graphic 6 Graphic 5 £1 a ride £1 a ride... -
Page 23: Contact Procedures
NO MINIMUM ORDER VALUE We want you to order what you want, when you want it. So you can order whatever quantities you like from Kiddy Rides, and you won’t be penalized with a minimum order value. ON-SITE REPAIRS If you are unable to return parts for repair, or fit spares yourself, we can arrange for one of our regional engineers to make a site visit. -
Page 24: Ride History / Log
REPAIR, SERVICE, AND HEALTH & SAFETY RECORD To be filled in by Engineer at time of work being carried out DATE PROCEDURE ENGINEER COMPANY COMMENTS Service / H&S / Repair... - Page 25 REPAIR, SERVICE, AND HEALTH & SAFETY RECORD To be filled in by Engineer at time of work being carried out DATE PROCEDURE ENGINEER COMPANY COMMENTS Service / H&S / Repair...
-
Page 26: Your Notes
YOUR NOTES... - Page 27 YOUR NOTES...
