- Page 1 Homing Amusement And Game Machine Co.,Ltd http://www.hominggame.com User Manual KIDDY RIDES Cutey Hat Please read this <User Manual> carefully before operating machines!
-
Page 2: Technical Parameters
Homing Amusement And Game Machine Co.,Ltd http://www.hominggame.com User Manual of Kiddy Rides 1. Technical Parameters: Item Value Remark AC220V (or on your request) Working Voltage ≤2.4A Machine Working Current 180W Motor Power 0.58-0.75S Rocking Frequency 40KGS Carrying Capacity 2. Applicability: Place indoor, and apply to 3~7 years old children under 40Kgs. - Page 3 Homing Amusement And Game Machine Co.,Ltd http://www.hominggame.com 4. Configure the control box according to following instructions and picture- Open the panel of control box with key. Turn on the electric switch on the control box, and make sure the LED light is shining. Set the price from 1~3 coins by the “COUNT”...
-
Page 4: Maintenance
Homing Amusement And Game Machine Co.,Ltd http://www.hominggame.com 2. When machines can not work or stop automatically, please switch off the machine immediately and examine & repair the machine. 5. Maintenance: 1. When machine is dirty, you can lean it with cotton fabric. 2. - Page 5 Homing Amusement And Game Machine Co.,Ltd http://www.hominggame.com 3. No any sound from sound speaker. Check if the “VOLUME” knob is on right position, and adjust it to see what happens. Check if the sound speaker is damaged or broken. Make sure all plugs and wire lines related with sound speaker is good and connected firmly and not loose.
-
Page 6: Dip Switch
Homing Amusement And Game Machine Co.,Ltd http://www.hominggame.com 5. Straps skid. After a long period use, the traps inside the machine will get loose or become slack. Please change the invalid straps on time. DIP Switch Function 4 coins per game 3 coins per game 2 coins per game 1 coin per game... - Page 7 Homing Amusement And Game Machine Co.,Ltd http://www.hominggame.com Pin No. code Resource Function Remark P1.4 P1.5 Button for P1.6 outside P1.7 No button function when calculating circle P1.0 P1.1 Port of P1.2 parameter P1.3 setting +12V Control for input of audion OC P3.7 Control for input of audion OC Lamp control...
