Summary of Contents for Revo 19'' wide lcd
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS 1. Read all of these instructions. 12. For added protection for this monitor during a lightning storm, 2. Save these instructions for later use. or when it is left unattended and unused for long periods of time, 3. Unplug this monitor from the unplug it from the wall outlet. -
Page 3: Canadian Notice
FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a NOTE : Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 4: Table Of Contents
CONTENTS CONTENTS Introduction ................1 Product Features ..............2 Setup ..................3 Stand Assembling Procedures ..........3 Stnad Disassembling Procedures ......... 3 Operation & Adjustment ............5 Specifications ................. 12 Factory Preset Timings ............13 Changing the Stand ............... 14 Troubleshooting .............. -
Page 5: Introduction
INTRODUCTION INTRODUCTION This manual explains how to correctly install, operate and get the best performance from your monitor. Please read this user’s guide carefully before installing your monitor, then keep it near your monitor for quick reference. First, please check that the contents of the box corresponds with the following checklist : TFT LCD monitor •... -
Page 6: Product Features
PRODUCT FEATURES The monitor is designed for use in a small work area or for those who need more work space on the desk. The convenient and user-friendly on-screen display allows for easy and accurate adjustments of screen size, position and screen color. -
Page 7: Setup
SETUP SETUP The monitor is packed with stand and main body separated. Please join the stand with the main body before use. Stand Assembling Procedures 1. Put some smooth pad or cloth on the level surface and place the monitor on it with the face downward. 2. - Page 8 CONNECTING THE 15 PIN SIGNAL CABLE AND POWER CORD Turn off the DVR and monitor. Connect the 15 pin signal cable to the output port of the DVR and monitor. Connect the audio cable to the output port of the sound DVR. Plug the power cord into the AC receptacle located on the back of the monitor.
-
Page 9: Operation & Adjustment
OPERA TION & ADJUSTMENT OPERA TION & ADJUSTMENT CONTROL PANEL POWER Indicator POWER Shows both normal operation Switches the monitor on and power management status and off. with power indicator light. Moves cursor to the right or Moves cursor to the left or high window in low window in the OSD the OSD window and decreases value of window and increases the... - Page 10 KEY PROCESS COLOR BRIGHTNESS PICTURE CONTRAST FUNCTION COLOR TEMP. OSD MENU LANGUAGE SOUND BRIGHTNESS Sound icon will be displayed only for Built in speaker model. CONTRAST COLOR TEMP. English - 6...
-
Page 11: Hot Key
HOT KEY When there is no OSD, if you press this AUTO button, you can use the best display performance fit for a current mode. In case of the model where the speaker is had built-in, you can adjust the volume directly before use the OSD menu. -
Page 12: Adjustment Procedure
ADJUSTMENT PROCEDURE Perform the Auto tracking Is the H.SIZE proper? Adjust the control. CLOCK Perform the AUTO POSITION Is the noise displayed on the screen? Adjust the CLOCK FINE until the screen is cleared. Is the noise displayed on the screen yet? English - 8... - Page 13 OSD FUNCTIONS WITH USING PC COLOR Adjust the brightness of image. BRIGHTNESS Adjust the contrast of image, the difference between CONTRAST light and dark areas on the screen. Choose different preset color temperatures or set your COLOR TEMP. own customized color parameters. Adjust the display image quality.
- Page 14 OSD MENU Adjust the OSD position horizontally (left or right) OSD H & and vertically (up or down). V POSITION Adjust the display OSD Menu. OSD TIME Adjust the OSD. Transparency TRANSLUCENT Select the aspect ratio. (WIDE/AUTO/4:3) ASPECT RATIO Regardless of input signal, wide screen output WIDE is automatically made.
- Page 15 SELF DIAGNOSIS If there is no image, the Self Diagnosis screen will be displayed. Self Diagnosis function checks if the status of the monitor screen is No Signal, Out of range or None support. No Signal screen is displayed when the D- Sub signal connector is connected but the status of the monitor is on DPMS mode.
-
Page 16: Specifications
SPECIFICA TIONS SPECIFICA TIONS Panel Size 19-inch(48 cm) diagonal Pixel Pitch 0.2835(H)mm x 0.2835(V) mm Viewing Angle 80°(Right/Left) 80°(down) Contrast Ratio 1000:1 contrast ratio (typ) Brightness 300cd/m brightness (typ) Response Time 5msec Color Filter RGB vertical stripe Synchronization Horizontal 30 - 80 Hz Vertical 56 - 77 Hz Video Bandwidth... -
Page 17: Factory Preset Timings
ACTOR Y PRESET TIMINGS ACTOR Y PRESET TIMINGS VESA MODES Resolution (dots lines) H.Freq(KHz) V.Freq(Hz) Remark MODES Resolution (dots lines) H.Freq(KHz) V.Freq(Hz) Remark MACINTOSH MODES Resolution (dots lines) H.Freq(KHz) V.Freq(Hz) Remark THE OTHERS Resolution (dots lines) H.Freq(KHz) V.Freq(Hz) Remark English - 13... -
Page 18: Changing The Stand
CHANGING THE ST CHANGING THE ST Removing Original Stand Turn off the monitor and pull out the power cable. Place a cushion or a soft cloth on the floor and put the product on it with the front of the monitor facing the floor. 1. - Page 19 ATTACHING THE MONITOR WITH THE ARM-STAND(OPTION) Support stand Surface for stand installation Tighten up screws at the locations indicated by arrows. This monitor’s installation surface is compatible with various kinds of VESA standard stands. Hole spacing : 100x100 mm Screw Length : 8~12 mm English - 15...
-
Page 20: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Symptom Check Picture is jitterd. Adjust Clock to set the screen position and adjust Clock fine until a noise isn’t displayed. No picture. Check if power switch and DVR power on. Check if the signal cable is correctly connected to the DVR. - Page 21 MEMO MEMO...
- Page 22 9978641707...
