- Page 1 RM185-ID1 LCD Monitor TFT LCD MONITOR User's Manual...
-
Page 2: Fcc Statement
FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 3: Table Of Contents
● Table of Contents 1. Important safety instruction ------------------------------------------------- 2 2. Product feature ------------------------------------------------------------------- 3 3. Product installation ------------------------------------------------------------- 4 - 5 4. Function Keys -------------------------------------------------------------------- 6 5. MENU function ------------------------------------------------------------------- 7 - 8 6. Timing guide ---------------------------------------------------------------------- 9 7. Input signal detail --------------------------------------------------------------- 10 8. -
Page 4: Important Safety Instruction
● Important safety instruction The interior part of the monitor is Take care of the LCD monitor Do not scratch the screen of the composed of electric elements. If so that it is not damaged by the LCD monitor with sharp materials the monitor is broken, do not try external impact. -
Page 5: Product Feature
4. The RM185-ID1 is compatible with IBM PC and Apple Macintosh. (A different adaptor is necessary for apple macintosh) 5. The RM185-ID1 has a power saving function less than 36W in power ON mode, less than 2W in stand by, and 1W in power off. -
Page 6: Product Installation
Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. Notice Please use the cables that are provided. REVO does not take responsibility for any problems that arise from using any other cables... - Page 7 6. At the user's convenience, you can adjust the display angle of under 25 degree to backward. the RM185-ID1 7. Please turn off the RM185-ID1 when not in use. 25’ ☞ Adjusting LCD panel angle - Do not hold or press down on the monitor's screen while adjusting angle since LCD panel maybe damaged or break if severe.
-
Page 8: Function Keys
● Function Keys ▶ Operation of the function keys Button Function Hot Key Automatically adjusts AUTO the picture. MENU Opens the Main Menu. ▲ Up / Right VOLUME up ▼ Down / Left VOLUME down POWER ON / OFF ▶ On Screen Display (OSD) Menu Navigation 1. -
Page 9: Menu Function
● MENU Function ▶ Color ☞ Contrast Brightness Color Adjust Color Temp Contrast: Adjusts contrast level at the picture. Brightness: Adjusts brightness level at the picture. Level of color force: Adjusts to color saturation of the picture.(Red,Green,Blue) Red: Adjusts share of red. Green: Adjusts share of green. - Page 10 ▶ OSD Menu ☞ OSD H.Pos OSD V.Pos OSD Timer Language OSD Horizontal Adjustment: Adjusts OSD menu screen's horizontal OSD Horizontal Adjustment: Adjusts OSD menu screen's horizontal OSD Horizontal Adjustment: Adjusts OSD menu screen's horizontal location. location.(0-100) location.(0-100) OSD Vertical Adjustment: Adjusts OSD menu screen's vertical location. OSD Vertical Adjustment: Adjusts OSD menu screen's vertical location.(0-100) OSD Vertical Adjustment: Adjusts OSD menu screen's vertical location.(0-100) OSD Marking Time: Adjusts OSD menu screen's marking time within the...
-
Page 11: Timing Guide
● Timing Guide ▶ Timing guide This product is a multi-frequency monitor. It functions in horizontal frequencies from 30kHz to 80kHz and vertical frequencies from 56Hz to 75Hz. Due to tis design based on microprocessor, It offers the functions of automatic synchronization and automatic size. Resolution Frequancy ITEM... -
Page 12: Input Signal Detail
● Input signal detail ▶ Cable Connections Input / Output Cable Type DC Power DC Power Cord Audio IN Audio Cable VGA IN 15-pin VGA Signal Cable ▶ Plug & Play The adoption of the new VESA Plug and Play solution eliminates complicated and time consuming setup. -
Page 13: Product Specification
506(W) x 370(H) x 140(D) Unit / Box 4.5 kg Weight Speaker 2W x 1 Function Audio in / out Mono Mini Jack 1.5M RM185-ID1 The design & specifications of are subject to be changed without any pervious notice to improve its quality. -
Page 14: Troubleshooting
● Troubleshooting ▶ No power - Flip the power switch ON. The Power LED turns on. - Make sure AC /DC power cord is securely connected to the power jack and to a power outlet. ▶ Power on but no screen image - Make sure the VGA cable attached with this monitor is tightly secured to the VGA output port on the back of the device. - Page 15 ▶ Entire screen image rolls (scrolls) vertically. - Make sure the input signals are within the LCD monitor's specified frequency range. (Maximum : 1366 * 768 @59Hz) - Connect the VGA cable securely. - Try the monitor with another power source. ▶...
