5b
Place & Program Sensor
IMPORTANT: IF YOU HAVE CLIPPED SENSOR INTO BRACKET, PLEASE SEE SENSOR RESET BOX.
For this install step you will need your Handset and Sensor:
Remove battery tab
A
Using Handset:
B Press MENU
Scroll to Security Setup, press SELECT
C
(Scroll Button found on left side of Handset)
Enter default Master Code 1234
D
Scroll to Sensors, press SELECT
E
On <Add New>, press SELECT
F
Scroll to desired Sensor Type, press SELECT
G
Wait 5 seconds
H
Clip Sensor into mounted Bracket (Display indicates you have 30 seconds)
I
Handset display will indicate the Sensor is found and then added, press OK*
J
Edit Sensor name by pressing DELETE and type new name
K
using keypad, then press OK (Or edit name on web later)
On Sensor only, press SELECT
L
Testing your Sensor:
Test your Sensor by opening the door. Correct installation will
M
generate a chime. Otherwise, see troubleshooting in User Manual
Repeat Step 5 for additional Sensors
N
SENSOR RESET INSTRUCTIONS
Slot
NOTE: DISCONNECT BY SEPARATING SENSOR FROM BRACKET USING SLOT. RESET SENSOR BY
INSERTING PAPER CLIP INTO RESET HOLE.
*NOTE: IF THE SYSTEM DID NOT FIND THE SENSOR, REFER TO SENSOR RESET INSTRUCTIONS, THEN REPEAT STEPS ABOVE.
A
Battery Tab
N o t A c t i v a t e d
C a l l s : 2 M s g : 2
PHNBK MENU
C
B
TALK
END
Scroll
Menu
MUTE SPKR
Button
2
1 3
ABC
DEF
5
4 6
JKL
GHI MNO
Reset Hole
6
Activate Your System
Using PC:
Go to www.LifeShield.com
A
Enter User Name and Password
B
Click on "Get Activation Code" and a 6-digit code will be provided
C
Using Handset:
Press MENU
D
On Activate, press SELECT
E
Enter Activation Code and press SEND
F
Upon activation acceptance press OK
G
Enter Master Code (Select a new 4-digit
H
code used to access and control the system)
Re-enter Master Code to confirm
I
Now testing communication to Central Monitoring*
J
Upon completion press OK*
K
*NOTE: IF YOU DO NOT SUBSCRIBE TO PROFESSIONAL MONITORING SERVICE
STEPS J AND K DO NOT APPLY.
R e a d y t o A r m
T h u 2 / 8 1 1 : 4 8a
C a l l s : 2 M s g : 2
PHNBK MENU
TALK
END
Scroll
MUTE SPKR Menu
Button
D
2
1 3
ABC
DEF
5
4 6
JKL
GHI MNO
Your system is now operational. If you are professionally monitored, for the next seven days
it will be in a non-monitored "Practice" mode to allow you to become fully acquainted with
all of its features. For help, call Customer Support at 1.877.XXX XXXX.
Welcome to LIFESHIELD
C
NOTE: IF YOU DO NOT SUBSCRIBE TO PHONE SERVICE, YOUR SYSTEM MAY EXHIBIT A TROUBLE BEEP.
GO TO LIFESHIELD.COM AND CLICK SECURITY/SYSTEM SETTINGS/EDIT AND SELECT 'NO'
ADJACENT TO THE HOME PHONE LINE FIELD TO CLEAR THE TROUBLE.
NOTE: LOW BATTERIES MAY CAUSE A TROUBLE BEEP UPON ACTIVATION. TO CANCEL TROUBLE BEEP
AND ALLOW TIME FOR CHARGING, PRESS CANCEL/OFF KEY, THEN PRESS OK ON DISPLAY.
