W10156600
OPTIONAL PARTS
For Models: KGCC566RBL02, KGCC566RWW02
(Black)
Illus.
Part
No.
No.
DESCRIPTION
Following Parts Not Illustrated
9763116 Cord, Power
3177991 Screw
Miscellaneous
8286320 Spud Kit
WIRING HARNESS PARTS
4456626 Harness,
Ignitor 15" (2)
8285402 Wire, Ground
4456627 Harness,
Ignitor 28" (2)
5
(White on White)
