- Page 1 MEC-SAT-M002 Mini PCI-e 2-port Serial ATA III board User’s Manual Third Edition, February 2014 © 2014 Cervoz Co., Ltd. All rights reserved. Reproduction without permission is prohibited...
- Page 2 Copyright Notice © 2014 Cervoz Co., Ltd. All rights reserved. Reproduction without permission is prohibited. Trademarks Cervoz is a registered trademark of Cervoz Co., Ltd. All other trademarks or registered marks in this manual belong to their respective manufacturers. Disclaimer Information in this document is subject to change without notice and does not represent a commitment on the part of Cervoz.
-
Page 3: Table Of Contents
Table of Contents Chapter 1 Introduction Overviews Features Installation Flowchart Package Checklist Chapter 2 Hardware Installation Chapter 3 Software Installation Appendix Pin Assignments Board Side Pin Assignments Device Side Pin Assignments Technical Reference MEC-SAT-M002 Specifications MEC-SAT-M002 Dimensions Product Warranty Statement... -
Page 4: Introduction
Introduction Overview MEC-SAT-M002 is a serial ATA III card for embedded PC. The card follows the Mini PCI-e standard which is complaint with PCI Express x 1 classification and small form factor (30.00 x 50.95 mm). This board fits in any host computer that has Mini PCI-e card slots. -
Page 5: Installation Flowchart
Installation Flowchart Installation Flowchart of MEC-SAT-M002 The following flowchart provides a brief summary of the procedure you should follow to install the Mini PCI-e card: Hardware Installation Connect the internal cable Hardware Installation Install the card in the Mini PCI-e slot... -
Page 6: Hardware Installation
Hardware Installation This chapter describes the PCI Express Series hardware installation procedure. Since the BIOS automatically assign the PCI Express board’s IRQ number and I/O addresses, you must plug in the board before installing the driver. Step 1 Connect the internal cable to the card Connect the internal cable to the card (20PIN connector) Both sides of the cable connectors are the same, it doesn’t matter which side Note... - Page 7 Step 2 Install the card to the Mini PCI-e slot Make sure you install the card in the right position (fool-proof design) Step 3 Fix the card on the motherboard (clip type or screw type) There are 2 options to fix the card. It depends on the design of the motherboard (clip or screw).
- Page 8 Screw type Step 4 Card installation completed Clip type...
- Page 9 Screw type Connect SATA devices and proceed to the next Step 5 section ”Software Installation” Connect SATA devices (SATA connector)
-
Page 10: Software Installation
Software Installation This chapter gives installation, configuration, and update/removal procedures for the driver for Win 2003, Win XP, Win Vista, Win 7, and Win 8. Step 1 Turn on PC and start Windows Note XP OS as example... - Page 11 Step 2 Windows automatically detects the new device If the card is installed properly, system would detect the new device and the hardware wizard would start automatically. Click “Cancel” to disregard Step 3 Insert CD Open the CD drive...
- Page 12 Find the “MEC-SAT-M002” folder Step 4 Open the “MEC-SAT-M002” file folder Find the “Driver” folder Step 5 Open the “Driver” folder...
- Page 13 Step 6 Find the appointed OS folder (Ex.: XP) Open the appointed OS folder (We use XP as an example in the above picture) Make sure you select the correct OS Step 7 Find your OS version (Ex.: XP 32bit) Select appoint OS folder (We use XP 32bit as an example in the above picture) Make sure you select the correct version of the OS (Ex.: 32-bit or 64-bit)
- Page 14 Find the “setup” file Step 8 Run the “set up” file Step 9 Driver installation set up InstallShield Wizard would start automatically after “setup” is clicked Click “Next”...
- Page 15 Step 10 License Agreement Select “I accept the terms in the license agreement” Click “Next” Step 11 Driver installation in progress Note System runs the installation automatically...
- Page 16 Step 12 Driver installation completed Driver installation completed, click “Finish” Step 13 Restart Windows After installation is completed, click “Yes” to restart PC...
- Page 17 Step 14 Confirm if driver is installed Start “Computer Management” program Go to the route: → → → My Computer Manage Device Manager SCSI and RAID controllers You would find driver name: Asmedia 106x SATA Controller Device is ready to be used Step 15 Confirm if SATA device is found Start “Computer Management”...
-
Page 18: Appendix
Appendix Pin Assignments Board Side Pin Assignments Wire to Board Connector (CN17) Description Description Receive_2 + Transmit_1 + Receive_2 - Transmit_1 - Transmit_2 - Receive_1 - Transmit_2 + Receive_1 + SATA LED_2 + SATA LED_1 + SATA LED_2 - SATA LED_1 -... -
Page 19: Device Side Pin Assignments
Device Side Pin Assignments SATA 7 Pin Connector SATA 7 Pin Connector-1 SATA 7 Pin Connector-2 Description Description Transmit_1 + Transmit_2 + Transmit_1 - Transmit_2 - Receive_1 - Receive_2 - Receive_1 + Receive_2 +... -
Page 20: Technical Reference
Technical Reference MEC-SAT-M002 Specifications General PCI-Express Revision PCI-Express Base Specification Rev 2.0 PCI-Express Electromechanical PCI-Express Mini Card Electromechanical Rev. 2.0 Revision Hardware Controllers Asmedia ASM1061 Single-Lane (x1) PCI-Express with throughput up to 5.0/2.5Gbps Interface (Connector) Serial ATA III 2 (SATA) -
Page 21: Product Warranty Statement
Limitation of Liability Cervoz’ liability arising out of the manufacture, sale, or supplying of the product and its use, whether based on warranty, contract, negligence, product liability, or otherwise, shall not exceed the original selling price of the product. The remedies provided herein are the customer’s sole and exclusive remedies.
