StarBoard Link EZ2-Pen
User's Guide
Read this User's Guide and carefully retain it for future reference.
Before using this product, carefully read and fully understand the safety instructions.
Store this User's Guide nearby for ease of reference.
SBLE2P-ML120801

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Link EZ2-Pen and is the answer not in the manual?

Questions and answers

Related Manuals for StarBoard Link EZ2-Pen

Summary of Contents for StarBoard Link EZ2-Pen

  • Page 1 StarBoard Link EZ2-Pen User’s Guide Read this User's Guide and carefully retain it for future reference. Before using this product, carefully read and fully understand the safety instructions. Store this User's Guide nearby for ease of reference. SBLE2P-ML120801...
  • Page 3 StarBoard Link EZ2-Pen Notices Reproduction or reprinting, without permission, of this User's Guide or any part thereof is prohibited. The contents of this User's Guide are subject to change without prior notice. Every effort has been made to ensure that this User's Guide is complete and correct. However, should any questionable points, mistakes, etc., come to your attention, please inform the vendor.

  • Page 4: Product Assurance Provisions

    This second edition of the user’s guide (SBLE2P-ML120801) is for the following products: AH00336: StarBoard Link EZ2-Pen （Overseas model） Windows is a trademark of Microsoft Corporation (U.S.) and in other countries. Mac and Mac OS are trademarks of Apple Inc., registered in the U.S. and other countries.
  • Page 5 StarBoard Link EZ2-Pen Introduction Thank you very much for purchasing Hitachi Solutions’s StarBoard Link EZ2-Pen (henceforth referred to as "StarBoard"). This User's Guide has been created for people who already have a working knowledge of personal computers (henceforth referred to as "PC").
  • Page 6 StarBoard Link EZ2-Pen Safe Handling Markings and Symbols Various markings and symbols are used in this User's Guide and on this product, to ensure the safe and correct use of this product and to prevent personal injury and property damage. These symbols and their meanings are as explained below.
  • Page 7 StarBoard Link EZ2-Pen Safe Handling Safe Precautions Required Precautions (1) Precautions Regarding Operation WARNINGS Do not make modifications. Do not make any adjustments, repairs, or modifications not given in this User's Guide as doing so may lead to personal injury or damage to the product.
  • Page 8 StarBoard Link EZ2-Pen Safe Handling (2) Dealing with Trouble CAUTIONS What to do in case of emission of smoke, strange odor, or strange noise If an abnormal condition such as emission of smoke, strange odor, or strange noise happens to occur for some reason, immediately disconnect the product's USB cable from the PC.
  • Page 9 StarBoard Link EZ2-Pen Safe Handling NOTICE Disconnect the USB cable during extended periods of non-use. For safety reasons, disconnect the USB cable if the product is not going to be used for an extended period of time. Failure to comply may result in malfunction.
  • Page 10 StarBoard Link EZ2-Pen Safe Handling (5) Precautions Regarding Setup Environment WARNINGS Do not place in a location with flammable or corrosive gas. Placing this product in a location where there is flammable or corrosive gas may result in fire or damage to this product.
  • Page 11 StarBoard Link EZ2-Pen Safe Handling NOTICE Do not use this product in locations subject to high temperature or high humidity. This product's usage environment conditions: Temperature: 5°C – 35°C Humidity: 20%RH – 80%RH (no condensation) Do not set up in locations subject to vibration and/or shock of impact.
  • Page 12 StarBoard Link EZ2-Pen Safe Handling Careful thought was given to the cautions on this device and in this User's Guide. However, unanticipated circumstances might occur. When operating this product, users themselves must exercise caution as well as follow instructions. WARNINGS...
  • Page 13 StarBoard Link EZ2-Pen Safe Handling NOTICE Notice Contents Page(s) - Select a level and stable position. - Do not set it up near equipment that might generate electromagnetic waves or radio frequencies, such as radio transmitters, televisions, copying machines or P.2-1...

  • Page 14: Table Of Contents

    1.3 Role of Each Part ........................1-3 1.3.1 StarBoard ......................1-3 2. Assembly and Setup ................2-1 2.1 Installing the StarBoard Software ................... 2-2 2.2 Installing the Devices ......................2-2 2.2.1 Projection from the Projector ................. 2-2 2.2.2 Installing the Digitizer ..................2-3 2.2.3 Connecting the USB Cable ..................

  • Page 15: Introduction

    First-time users of StarBoard should read through this chapter. 1.1.1 Product Outline In order to use the StarBoard Link EZ2-Pen, a digitizer are installed on an existing whiteboard or flat wall surface. After setting up the provided software on a PC that is connected to a projector, you can use the pen to operate the projected PC screen, or import characters or images drawn on the projection area in real time to the PC.

  • Page 16: Parts Check

    1.2.1 StarBoard [1] Parts Name Digitizer Pen (Reflective Pen) USB extension cable Cable holder Wood screws Machine screws Wall mount bracket StarBoard Software DVD-ROM StarBoard Software Startup Guide (10) StarBoard Link EZ2-Pen Startup Guide (11) Warranty Sheet (10) (11) English...

  • Page 17: Role Of Each Part

    Used in pen input. images drawn with the pen, and transmits this (5) USB extension cable data to the PC. Used to connect the StarBoard with the PC. (2) Status LED (6) Cable Holder The connection status is displayed by the color Used to fix the USB cable in place.

  • Page 18: Assembly And Setup

    Assembly and Setup StarBoard Link EZ2-Pen 2. Assembly and Setup Be sure to follow the precautions below when installing the StarBoard. Important Use on a flat surface. This product is designed so that stable input is achieved when used on a flat surface.

  • Page 19: Installing The Starboard Software

    2.2.1 Projection from the Projector Project the computer screen using the projector. To install the StarBoard, ensure the following clearance is maintained around the projection area. However, the StarBoard detectable sizes are as shown below. (Aspect ratio 4:3/16:10) 60-90 inches...

  • Page 20: Installing The Digitizer

    Assembly and Setup StarBoard Link EZ2-Pen 2.2.2 Installing the Digitizer ・Installing with Magnets Align the center of the digitizer with the center of the projection area, 5cm (2 inches) above the projection area, and install so it is parallel with the edge of the projection area.

  • Page 21: Connecting The Usb Cable

    Assembly and Setup StarBoard Link EZ2-Pen (2) Align the center of the digitizer with the center of the projection area, 5 cm (2 inches) above the projection area, and install so it is parallel with the edge of the projection area.
  • Page 22 Assembly and Setup StarBoard Link EZ2-Pen (2) Connect the bundled USB extension cable to the computer. USB extension cable English...

  • Page 23: Adjusting The Sensor

    2.2.4.1 Sensor Adjustment Procedure (Windows version) (1) Start "SBAdjust.exe" (When first connected via USB, it starts automatically). Select "MENU" – "Settings" – "StarBoard" – "StarBoard Settings" and press "Sensor adjustment" in the StarBoard toolbar. Alternatively, Run "SBAdjust.exe" located under "My Computer" → "C Drive" (*) → "Program Files"...
  • Page 24 Assembly and Setup StarBoard Link EZ2-Pen (3) Once the sensor adjustment is properly completed, a message that says "Digitizer adjustment has finished successfully." is displayed. After this, calibration is performed, so please wait. *If you do not want to calibrate, press the "Cancel" button.

  • Page 25: Sensor Adjustment Procedure (Mac Version)

    2.2.4.2 Sensor Adjustment Procedure (Mac version) (1) Start "SBAdjust" (When first connected via USB, it starts automatically). Start "Go" → "Applications" → "StarBoard" → "Lsadrv" folder → "SBAdjust". (2) Touch the center of the blinking mark with the pen tip.

  • Page 26: Positioning Alignment

    Once you click on the center of all nine circles, a dialogue box that says "Calibration completed" is displayed. Press "OK" to finish calibration. This completes sensor adjustment. 2.2.5 Positioning Alignment Select "MENU" on the StarBoard Software toolbar → "Settings" →"StarBoard" → "Calibrate" → "OK". and then perform position alignment. English...

  • Page 27: How To Use

    StarBoard Link EZ2-Pen How to use 3. How to Use 3.1 How to Use The Pen To use the pen to draw letters or images, press the tip of the pen to the projection area and move the pen. Remove the tip of the pen from the projection area to finish writing. Keep in mind the following points when using the pen.

  • Page 28: Start Method

    (5) Select "Start" → "All Programs" → "StarBoard Software", or double-click the StarBoard icon on the desktop. If the "No connection" icon in below appears on the Tasktray, it means that the StarBoard is not connected. Make sure that the StarBoard and the PC are properly connected.

  • Page 29: Start Method (Mac Version)

    (refer to page 1-3 of this User's Guide). (5) Select "Go" → "Applications" → "StarBoard Software" to start StarBoard Software. (6) Select "MENU" on the StarBoard Software toolbar → "Settings" → "StarBoard" → "Check Connection," and then check the connection.
  • Page 30 StarBoard Link EZ2-Pen How to use If the positions of the pen tip and cursor are out of alignment, select "MENU" on the StarBoard Software toolbar → "Settings" → "StarBoard" → "Calibrate," and then perform position alignment. Important Run the "Adjusting the Sensor (See page 2-6 to 2-9 of this User's Guide.)"...

  • Page 31: Appendix

    ・USB extension cable other than use self-powered USB hub. bundled one ・Bus-powered USB hub ・USB extender StarBoard Software files may be Uninstall the StarBoard Software broken or installation may not be and then re-install it. complete correctly. （For details on installing StarBoard Software, see the StarBoard Software Installation Guide.)
  • Page 32 ・USB extension cable other than bundled one ・Bus-powered USB hub ・USB extender Is a high-speed USB device Be sure to connect the StarBoard and Touch Sensor Error connected to the USB host any high-speed USB devices to (Insufficient USB controller used to connect the separate USB host controllers.
  • Page 33 StarBoard Link EZ2-Pen Appendix Input-Related Problems Problem What to check What to do The pen does not Are you holding the pen Please check page 3-1 of this user's operate, or its operation properly? guide, "How to Use The Pen", and try is unstable.

  • Page 34: System Specifications

    StarBoard Link EZ2-Pen Appendix 4.2 System Specifications Item Specification Model name StarBoard Link EZ2-Pen Detection method Infrared image sensor system* Digitizer resolution 0.05mm Sampling rate Approx. 100 points/second when using (USB1.1 Full Speed) Interface USB 1.1 (cable length：6m) Effective screen size 60 –...

  • Page 35: Proper Care And Cleaning

    Appendix 4.3 Proper Care and Cleaning Clean the StarBoard periodically so that you may use it for a long time to come. (1) Digitizer Cleaning ・When cleaning the digitizer, use a soft cloth dampened with a diluted neutral cleansing agent that does not contain a polishing compound.

  • Page 36: Product Warranty Policy

    StarBoard Link EZ2-Pen Appendix 4.5 Product Warranty Policy 1. During the free warranty service period, if a malfunction occurs during normal use, the malfunction will be corrected without charge, according to the provisions of the warranty. Furthermore, if the customer registration card accompanying the warranty is not returned to our company, the customer information will not be registered;...
  • Page 37 StarBoard Link EZ2-Pen Appendix 5. If this product malfunctions, review the contents of this user’s guide. If the problems remain irreparable, contact the dealer. The dealer will determine whether or not the product must be repaired, so please contact them. If the customer sends the product to our company without RMA (Return Merchandise Authorization) number, it might not be covered by warranty.
