ProVisual AC-930P Installation Manual page 8

Product
Connection
AC-930P Interface
Common end
Stop
Close
Open
Connect with Barrier
AC-930P Interface
Exit Button
AC-930P Interface
Alarm Light
+
-
Connect with Alarm Device
For this type of connection, the
barrier switch is closed in normal
status. When user presents
card or presses the exit button,
the barrier will be opened, The
opening time depends on the
door-open delay time. It is
recommended to install ultra-red
and ground sensor for protection.
接读卡器
Power Interface
Home & Business Security Solution
COM1
COM2
Connect with Automatic Door
Active Boorbell
Black
Red
Green
White
1 2 3
4 5 6
7 8 9
* 0 #
262RP
Connect with Reader
CCTV & Security Distributor
AC-930P Interface
The automatic door is open when
COM1-COM2 is short circuit.
AC-930P Interface
Connect with Door Bell
AC-930P Interface
