Function
Debugging
2.Start to read card
Setup the Jumper
Rs485
Rs232
Provisual
2007-04-16
1
2
3
4
5
6
7
8
9
0
#
PC time should be in consistent with controller time;
*
otherwise the reader may not work properly.
Connect with Exterior Identification Device
1. Select the device
After the exterior device is connected with AC-930P, please
3. Get the card
select Tools---Card Register in the software program. Then,
number
select the exterior device and start to read the card. If you
can find the card number in the list, it means the exterior device
works correctly.
Test the Communication
AC-930P has two kinds of communication modes: RS232
and RS485. User can chose the communication mode by
setting up the jumper. AC-930P can connect with PC serial port,
and one serial port only connects with one AC-930P.
RS485 signal should be converted to RS232 signal before it
can communicate with PC. RS485 can connect with
multiple devices. After ASI-8930 is connected with PC, user
can detect AC-930P address by detecting serial port (please
refer to the user manual to setup the address). If
"connected" is displayed, the communication is ok. User
can get version and model number of AC-930P by inputting the
address and clicking Auto Detect.
Test the LCD
14:20
The LCD will display the Provisual and the time, after turn
on the power for
Test the time of AC-930P
Time adjustment is shown in the picture on the left. The time of
controller should be in consistent with PC. User can get
updated time for controller by press"Refresh". If controller
time is incorrect, card record may get lost, validity of card-
read is in doubt, and moreover, valid card may turn into be
invalid.
Home & Business Security Solution
AC-930P
.
