Summary of Contents for ProVisual AC-930P
- Page 1 CCTV & Security Distributor Integrated Access Controller Integrated Access Controller Installation Manual Installation Manual Quality Assurance Technical Innovation Sincere and Faithful Human-centered Design 3000 ProVisual, Inc.
-
Page 2: Product Manual
Product Manual Installation Manual Product Connection Function Debugging Product Maintenance Home & Business Security Solutions... - Page 3 CCTV & Security Distributor Product Series AC-930P Provisual Integrated Access Control Series: Features Anson Integrated Access Control is characterized by its elegant design and convenient application and installation, which is especially suitable for office buildings and shops. The device is equipped with built-in reader and can work both as controller and reader.
- Page 4 In case of any problem, please contact with our technical support instead of self- repairment. Please keep the original state of the products when sending back for repair. Please notify us if you have any special demand, and we will feedback within 48 hours. ProVisual, Inc. Technical Support Department support@securitycameradistributor.com Toll Free: 1(800)593-6955 Home &...
- Page 5 Product Manual CCTV & Security Distributor 1 5 0 m m 30mm Fixing Hole Fixing Hole Jumper 485 232 DAT0 DAT1 485+ 485- MenC1 BELL BELL Fixing Hole The Side The Back The Front 设 备 参 数 Product Parameters Working Voltage:DC9-15V Static Current:≤120mA Reading Distance: 5-10cm...
- Page 6 Installation Manual CCTV & Security Distributor 1. Remove the two keys first. 2. Unfasten the two screws. Push up the back cover to open First open the lower part of backcover for around 1cm. Please note that open too wide may lead to damage to the device.
- Page 7 Product Connection CCTV & Security Distributor AC-930P Interface Power Interface RS232 485 232 Interface DAT0 Reader Interface 485+ DAT1 RS485 Interface Exit Button 485- Interface Door Magnet 485 232 Alarm Output DAT0 DAT1 485+ Door Magnet MenC1 Interface 485- Interface...
- Page 8 Product Connection CCTV & Security Distributor AC-930P Interface AC-930P Interface For this type of connection, the COM1 Common end barrier switch is closed in normal status. When user presents Stop card or presses the exit button, Close the barrier will be opened, The...
- Page 9 Product Connection CCTV & Security Distributor AC-930P Interface Converter Computer Interface DB9-Hole For 485 communication, please follow the diagram for connection and no other connection mode should be used. 12345 12345 RS232 Connect with RS485 Connect with Rs232 PC or Router...
- Page 10 The status reversed when valid default input is normal close.The user can decide the type of default input setup in the software. AC-930P has two input interfaces: SW-GND is button input; MenCi-GND is door magnet input. Both of them can be changed in “channel setup”.
- Page 11 RS485. User can chose the communication mode by Rs485 Rs232 setting up the jumper. AC-930P can connect with PC serial port, and one serial port only connects with one AC-930P. RS485 signal should be converted to RS232 signal before it can communicate with PC.
- Page 12 8. When RS485 is applied, voltage between 485+ and 485- is around 5 voltages. 9. The LCD have no information to be displayed, after turn on the power for AC-930P. The starting program maybe damaged. The life of products is related to application environment and application method. Please carefully follow the product manual and installation manual.
