IQBoard ET & PS
User Manual
Copyright(C) 2003-2009 Returnstar Technology Co., Ltd.
Web: www.recoverystar.com;
www.iqboard.net
Tel: +86-591-83385086, 87274373
Fax: +86-591-87274383
E-mail:
master@recoverystar.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IQBoard ET and is the answer not in the manual?

Questions and answers

Related Manuals for Returnstar IQBoard ET

Summary of Contents for Returnstar IQBoard ET

  • Page 1 IQBoard ET & PS User Manual Copyright(C) 2003-2009 Returnstar Technology Co., Ltd. Web: www.recoverystar.com; www.iqboard.net Tel: +86-591-83385086, 87274373 Fax: +86-591-87274383 E-mail: master@recoverystar.com...
  • Page 2 Important Statements This manual is for IQBoard ET and IQBoard PS. The “Whiteboard” or “Interactive Whiteboard” in this manual all refer to IQBoard ET or IQBoard PS. The “Electronic Pen” is used for IQBoard ET. The “Colorless Writing Pen (Finger)” is used for IQBoard PS.

  • Page 3: Chapter 1 Product Introduction

    IQBoard ET and IQBoard PS are the latest interactive presentation boards. Connect IQBoard ET or PS with your computer and projector, then simply touch the projection area with electronic pen or your finger, you can transform the electronic pen or your finger to mouse and directly operate the computer on the projection area.

  • Page 4: Chapter 2 Specification

    Processing rate for writing or clicking: 240 dot/s. Provide 9 or 20 points precise orientation. Power consumption for electronic pen: ≤1 W. IQBoard ET provides sizes of 80 inches, 60 inches, 50 inches (4:3), 100 inches, 120 inches (16:9) and customized sizes.
  • Page 5 System Requirement Windows XP/2003/Vista operation system Pentium166 CPU (PentiumII or higher recommended) 64 MB RAM (128 MB recommended) 1G free hard disk space (for full installation) 1 free USB port 1 projector (short focus or ultra-short focus projector recommended)

  • Page 6: Chapter 3 Setup Hardware

    Chapter 3 Setup Hardware 3.1 Mount Whiteboard 3.1.1 For product with an “M” on its name In case your product having an “M” on its name, you can select wall mounting. Parts list: Picture Name Quantity Screw Wall Anchor Safety Bracket Anchor Bolt Wall Mounting Bar Wall Mounting Bracket...
  • Page 7 Note: When mounting the Wall Mounting Bar, mind its direction. Step 2. Align the 2 Wall Mounting Brackets on the backboard with the Wall Mounting Bar, and hang the whiteboard on the wall. Step 3. Fasten the 2 Safety Brackets on each side of whiteboard lower frame using 2 Screws.
  • Page 8 Picture Name Quantity Screw Wall Anchor Safety Bracket Anchor Bolt Height Adjust Bracket (already mounted on backboard) Installation Steps: Step 1. Drill 4 holes at the location where you want to place the 4 Anchor Bolts, insert the 4 Anchor Bolts in these holes, and leave 4mm clearance between bolt head and nut for hanging whiteboard.
  • Page 9 Prompt: The distance from floor to the 2 anchor bolts on top (Distance X) is 190cm. The vertical distance between 2 anchor bolts (Distance H) is 45cm for the 50" and 60" whiteboards, and 75cm for the 80", 100", 112", and 120" whiteboards. For the horizontal distance between 2 anchor bolts (Distance L), please measure horizontal distance of the 2 Height Adjust Brackets on the backboard.
  • Page 10 Part List Picture Name Quantity Leg Bar Column Supporting Caster Moveable Crossbeam (Each includes Beams and a U-Shaped Groove) Hexagon Bolt Hexagon Bolt B (M8 with 08/22 washer) Hexagon Bolt C (M8 50) Hexagon Bolt Set A (M8 Each set includes: 1 Hexagon Bolt, 1 Wind Nut, 1 M8 Nut, 1 Small Washer, 1 Big Washer...
  • Page 11 Hexagon Bolt Set B (M8 Each set includes: 1 Hexagon Bolt, 1 Wind Nut, 1 Small Washer, 1 Big Washer Anchor Bolt (M8 60) Wrench Installation Steps: Step 1. Install Column on each Leg Bar using Hexagon Bolt B. Step 2. Install one end of each Supporting Bar on each Leg Bar, using Hexagon Bolt Step 3.
  • Page 12 Step 4. Install 2 Casters on each Leg Bar. Step 5. Install 2 Beams on each Column, using Hexagon Bolt C Step 6. Laid down and connect the two leg assemblies with the U-Shaped Grooves.
  • Page 13 Step 7. Secure the U-Shaped Grooves with Hexagon Bolt Set B. In this stage, do not completely tighten the bolt in order to adjust the stand width later. Step 8. Install 2 Hexagon Bolt Sets A on each Column, leaving 4mm clearance between bolt head and nut for hanging whiteboard.
  • Page 14 Step 9. Align the Hexagon Bolt on the Column with the clip holes of Height Adjusting Bracket on backboard, and hang the one side of whiteboard on the stand. Then adjust the stand width to fit the whiteboard, and hang other side of the whiteboard on the stand.
  • Page 15 Prompt 1. You can use different clip holes of the Height Adjusting Bracket to adjust the whiteboard height. Generally the bottom of the whiteboard should be 70-80cm above the ground. 2. For 50 and 60 inch whiteboard, you can hang the whiteboard on the first and second bolts from top down on the Column.
  • Page 16 3.2.1 Install battery 1. Unscrew the end cap of signal pen turning it counterclockwise. 2. Remove the battery cover by pushing the cover back away from the pen tip. 3. Insert 1 AAA battery with the plus (+) side up. 4.
  • Page 17 Chapter 4 Connecting with Computer and Projector After fixing the whiteboard, find a connecting port on the backboard right bottom. Plug the quadrate side of USB cable into the connecting port, and plug the flat side into the available USB port of computer, as follows. External power source is not required.
  • Page 18 to make the projection quadrate. The blue areas are the maximum projection areas. For whiteboards without hotkey or with hard hotkeys, there should be 2cm margin between projection area and whiteboard inner frame. For whiteboards with soft hotkeys, the projection area should not exceed the hotkeys. Note: 1.
  • Page 19 2. No restriction on Windows user account (Administrator, Guest, and Limited User). 5.2 Uninstall Drivers Select “Start > Programs > IQBoard ET & PS Drivers >Uninstall” to uninstall. You also can open Control Panel, select “Add/Remove Programs”, and in the list of currently installed Programs, select “IQBoard ET &...
  • Page 20 Operation steps are as follows: Step 1. Select “Start > Programs > IQBoard ET & PS Drivers >Orient” to enter the Orient Precision Selection window, as follows. If your product model is without H, N and T, you also can press “...
  • Page 21 6.2 Hotkey Setting At the first time you use the whiteboard with soft hotkeys, you need to set these hotkeys. Step 1. Select “Start > Programs > IQBoard ET & PS Drivers >Hotkey setting” to enter the setting window, as follows...
  • Page 22 Step 2. Follow the indication on screen, click relevant hotkey in sequence. After the setting is completed, you can use these hotkeys. Prompt: 1. When setting the soft hotkeys, if some error occurs, you can press “ESC” key on the keyboard to exit the setting process, and then reset the hotkeys.

  • Page 23: Chapter 7 Operation

    Chapter 7 Operation 7.1 Skills of pressing and writing Single-click & Double-click: Do not raise the electronic pen or writing pen (finger) too much (about 1-2mm from the tip to the surface), keep the angle between pen and surface more than 50º, then press the surface at proper strength. The operation of double-click on board has the same definition as double-click mouse in Windows, please make sure you click at the same point.
  • Page 24 Following is the introduction of these hotkeys. : In Windows Mode, press this key to clear all annotations on screen. In Add Page Board Mode, Press this key to add a new page in current “cdf” file. : In Windows Mode, press this key to save all annotations on screen to a Save File page in current file.
  • Page 25 these keys, you can write on board in corresponding color. Press “Pen” twice to modify its properties. : Press key, you can erase the writing content on board. In Eraser “Windows” mode, press this key twice to popup the “Shut Down Windows” window. : Press key to popup a quick access bar including shortcut icons for Tools...

  • Page 26: Chapter 8 Faq

    5. IQBoard Software hasn’t been started, please start IQBoard Software first. 6.The driver version doesn’t match. Please uninstall the driver, restart computer, and re-install the driver. You can download the universal driver of IQBoard ET & PS Drivers (for V4.5/V5.0/V6.0) on our website. After the installation is completed, please reconnect the USB cable with computer.
  • Page 27 The operating or writing force is uneven. Sometimes the force is too light to be sensed. 6. When I operate and write on the IQBoard ET with electronic pen, the system doesn’t respond. 1. The electronic pen runs out of battery, please replace the battery.
  • Page 28 7. When using IQBoard ET, the cursor is out of gear or the whiteboard can’t be oriented. There is interference source nearby, such as high voltage cable or large generator set which can generate strong magnetic field. Background knowledge: IQBoard ET adopts working principle of electromagnetic induction.

  • Page 29: Chapter 9 Cautions And Maintenance

    Chapter 9 Cautions and Maintenance 9.1 Whiteboard For the interactive whiteboard that do not support normal marker (the product model is without “W”), please try not to use normal marker to write on the surface. Before cleaning, please shut down the computer and switch the projector into standby mode to make the dirt more obvious.
  • Page 30 6. To avoid harm from improper operation, please do not use chair or other tool to help short students use the whiteboard. If students can not use whiteboard because of the limitation of their height, please low down the whiteboard under the help of professional technician.
