Summary of Contents for Alphacom a200
-
Page 1: User Guide
® Alphacom a200 a RANGE tElEPHONE USER GUIDE Versatility & Value... -
Page 2: Table Of Contents
10.3 DIALLIng nuMbERS FROM MEMORy 10.4 pAuSE 10.5 TOnE buTTOn 10.6 HAnDSET MuTE buTTOn 10.7 LATCHAbLE bASE MuTE OpERATING pROCEDURE FOR pBx CONNECTION 11.1 pbx RECALL 11.2 gEnERAL uSE IN CASE OF DIFFICUlTY CARE OF YOUR a200 HEADSETpHONE wAll MOUNTING... -
Page 3: Guarantee
CONDITIONS OF USE your a200 Telephone is approved for use on business or private direct exchange lines and on compatible pbx extensions. When connected to a direct exchange line this must be a standard exclusive (not shared service) line. -
Page 4: Facilities And Features
Facilities and Features This apparatus has been approved for the use of the following facilities Simple telephone facility Loop Disconnect or DTMF Signalling (selectable) 32 digit Automatic Storage of last number dialled 20 Direct Memory locations of 24 digit capacity Ringer volume control Ringer pitch control Time break or Earth Loop Recall (selectable) -
Page 5: Locations Of Controls - Front View
Telephone - Front View a200 Telephone - Front View... -
Page 6: Locations Of Controls - Side View
Telephone - Side View... -
Page 7: Headset Hook Assembly (Optional)
Headset Hook Assembly (Optional) Hi Elevation Lo Elevation position the Headset Hook in the required elevation (Hi or Lo) then slide the cover on to secure in place. -
Page 8: Utilisation Of Controls
Utilisation of Controls The button functions are as follows: 0 - 9 Dialing digits. * - # Dialling codes for MF signalling Recall For use on pbx or for star services Last number redial function Tone Switches from Loop Disconnect to DTMF during dialling pause Insert a pause in the dial sequence Mute... -
Page 9: Installation
Installation your a200 Telephone is designed to be plugged into the new phone sockets adopted in the u.k. If you do not have a primary socket you can obtain this from your bT sales office, whose address is in the telephone directory. Additional sockets can be fitted by yourself using one of the extension kits commercially available. -
Page 10: The Recall Mode Selector Switch
THE RECAll MODE SElECTOR SwITCH If you are connected to a TOnE dialling exchange, set the switch to the TbR (Timed break Recall) position to enable you access certain network Services. If you are connected to a puLSE dialling exchange, set the switch to the ELR (Earth Loop) position as recall has no function on direct lines connected to such exchanges. -
Page 11: Operating Procedures
Operating Procedures 10.1 lAST NUMBER REDIAl To redial the last number manually dialled: Lift handset, listen for dial tone press redial button 10.2 MEMORY OpERATION up to 20 telephone numbers each consisting of a maximum of 24 digits (including pauses or change of dial mode instruction) may be stored in memory. numbers may also be stored when you are actually in the process of making a call and using the handset or headset. -
Page 12: Tone Button
Mute LED will light up. press the mute button again to deactivate the mute function. Operating Procedure For PBX Connection The a200 Telephone is suitable for connection to a pAbx which returns secondary proceed indication. 11.1 pBx RECAll When connected to a pbx, the telephone will send a Recall Signal to the exchange when the RECALL (R) button is pressed. -
Page 13: 12. In Case Of Difficulty
Care of your a200 Telephone you have invested in a quality product and simple care and cleaning will keep it in good condition.The plastic parts and cards should be wiped with a cloth dampened with clean... -
Page 14: Wall Mounting
Wall Mounting you may wish to mount the nR202 Memoryphone on a wall. To do this: Slide the plastic “wall mount” upwards to remove, turn it around and replace it in the slot. The Handset will then stay in the cradle when the telephone is on the wall. position two screws into the wall at a distance of 10cm apart. - Page 15 Distributed by: Alphacom ® Incom House, Waterside Trafford park Manchester, M17 1WD Tel: 0161 935 1000 Fax: 0161 935 1015 www.alphacomtelecoms.co.uk email: sales@alphacomtelecoms.co.uk All Alphacom telephones are manufactured to comply with CE standards...
