Summary of Contents for Alphacom Regency 605
-
Page 1: User Guide
Alphacom Regency605 REGENCY RANGE hEAdsEtPhONE USER GUIDE Versatility & Value... -
Page 3: Table Of Contents
REDIAL / pAuSE buTTON (REDIAL) 13.14 SAVE buTTON 13.15 REDIAL / pAuSE buTTON (pAuSE) OPERATING PROCEDURE FOR PBX CONNECTION 14.1 pbX RECALL 14.2 pAbX pAuSE fACILITy 14.3 MESSAgE WAITINg OpERATION 14.4 gENERAL uSE IN CASE OF DIFFICUlTy CARE OF yOUR REGENCy 605 HEADSETPHONE... -
Page 4: Guarantee
CONDITIONS OF USE your Regency 605 Headsetphone is approved for use on business or private direct exchange lines and on compatible pbX extensions. When connected to a direct exchange line this must be a standard exclusive (not shared service) line. -
Page 5: Feature List
Feature List Simple telephone facility Loop disconnect or DTMf signalling (selectable). 32 digits automatic storage last number dialed. 32 digits save function Earth loop and time break recall pAbX pause function 10 + 10 direct memory location of 24 digits capacity LCD date/time display and auto timer function base unit toggle mute with LED indication Handset push to mute facility... -
Page 6: Locations Of Controls
Regency 605 Headsetphone... -
Page 7: Utilisation Of Controls
Utilisation of Controls 0 - 9 Dialing digits. * - # Dialling codes for Mf signalling Recall for use on pbX or for star services Save used during conversation to store a memo number or last number LNR/pause Last number redial and pause function base Mute To prevent the other party from hearing you (i.e. -
Page 8: Installation
The numbers when added together must be 4 or less. Sometimes bT telephones are unmarked but they can generally be assumed to have a REN of 1.0. If in doubt, please check with your BT Sales Office. The REN value of your Regency 605 Headsetphone is 1.0. -
Page 9: The Recall Mode Selector Switch
To find out if you are on a digital exchange, or when it will be provided, contact your local BT office. your Regency 605 Headsetphone provides tone signalling when the Dial Mode selector switch is set to the (TONE) position and the Recall Mode selector switch is in the TbR position. -
Page 10: Connecting To Telephone Socket
Set the switch to the Hl, MED or LO position to adjust the pitch of the ringer. Wall Mounting you may wish to mount the Regency 605 Headsetphone on a wall. To do this: Slide the plastic, “wall mount” upwards to remove, turn it around and replace it in the slot. -
Page 11: Setting Up
Setting up 12.1 CONNECTING TElEPHONE The plug at the end of the telephone lead should be connected into a telephone modular socket. Warning – the calendar memory may be lost if the telephone is disconnected from the telephone line. 12.2 RINGER vOlUME OFF lO HI SWITCH Set the Ringer Volume switch on base unit to adjust the ringer the required volume... -
Page 12: Operation
Operation 13.1 USING THE TElEPHONE Having connected the telephone you can now make and receive telephone calls and store telephone numbers in memory. 13.2 TO MAKE A CAll Lift the Handset or press Hands-free/Headset button, await dial tone and dial required number. On the completion of the call, carefully replace the Handset in the cradle, or press the Hands-free/Headset button to clear down the line. -
Page 13: View Button
13.5 vIEW BUTTON you can check the last number dialed and the conversation time. Lift up the handset or press Hands-free press View button, the last dialed number will be shown on the display. If dialed number is longer than 16 digits, press View button again to display the rest of number. -
Page 14: Storing Telephone Numbers
13.8 STORING TElEPHONE NUMBERS “ONE TOUCH” lOCATIONS Ensure telephone is plugged into telephone socket. Lift handset or press Hands-free button. press the Store button. Dial the telephone number you wish to store. press one of the “One Touch” direct memory button.(The LCD will show the memory location E01~E10) Repeat steps 2 to 4 for remaining nine “One Touch”... -
Page 15: Redialling The Last Number
13.10 REDIAllING THE lAST NUMBER If the telephone number you have called is engaged or if you want to repeat the call to the number you previously dialed, lift the handset, await dial tone and press Redial button. The previously dialed number will be automatically redialed. -
Page 16: Operating Procedure For Pbx Connection
Operating Procedure for PBX Connection The Regency 605 Headsetphone is suitable for connection to a pAbX which returns secondary proceed indication. 14.1 PBX RECAll When connected to a pbX, the telephone will send a Recall Signal to the exchange when the RECALL button is pressed. This Regency 605 Headsetphone provides either TIMED LINE bREAK RECALL or EARTH RECALL. -
Page 17: 15. In Case Of Difficulty
Note: If bT engineers are called out unnecessarily and the line is not at fault, a charge will be made. If difficulties are still experienced, please contact your supplier. Care of your Regency 605 Headsetphone you have invested in a quality product and simple care and cleaning will keep it in good condition.The plastic parts and cards should be wiped with a cloth dampened with clean... - Page 18 Distributed by: Alphacom ® Incom House, Waterside Trafford park Manchester, M17 1WD Tel: 0161 935 1000 fax: 0161 935 1015 www.alphacomtelecoms.co.uk email: sales@alphacomtelecoms.co.uk All Alphacom telephones are manufactured to comply with CE standards...
