Toddler Quad
KT1138
OWNER'S MANUAL
The owner's manual contains assembly, use and maintenance
instructions. The vehicle must be assembled by an adult who
has read and understands the instructions in this manual.
Keep the packaging away from children and dispose of all
packaging before use. Keep instructions for future reference.
Styles and colors may vary.
Made in China
©Disney
Advertisement
Table of Contents
Related Manuals for KidTrax KT1138 Jake and the Neverland Pirates
Summary of Contents for KidTrax KT1138 Jake and the Neverland Pirates
- Page 1 Toddler Quad KT1138 OWNER’S MANUAL The owner’s manual contains assembly, use and maintenance instructions. The vehicle must be assembled by an adult who has read and understands the instructions in this manual. Keep the packaging away from children and dispose of all packaging before use.
- Page 2 Thank You For purchasing Jake and the Never Land Pirate toddler quad. Features include; Power Trax rubber traction strips on the tires, and a 6 volt battery with charger. We hope your child will have years of riding enjoyment with our products. We appreciate your business.
-
Page 3: Table Of Contents
Contents 1 Safety ..........4 5 Maintenance . -
Page 4: Safety
Safety WARNING! The following safety hazards may result in serious injury or • Using the vehicle in unsafe conditions such as snow, rain, death to the user of the vehicle: loose dirt, mud, sand or fine gravel may result in •... -
Page 5: Battery Warnings
15 minutes. If the chemical was • Using the KidTrax Toys 6V rechargeable battery and swallowed, immediately give the person water or charger for any other product may result in milk. -
Page 6: User Requirements And Warnings
USER REQUIREMENTS AND WARNINGS CARE WARNINGS WARNING! Age Range 18 months and up Weight Range No more than 45 lb (20 kg) • Park the vehicle indoors or cover it with a tarp to protect it from wet weather. Before using the vehicle the child should understand the vehicle •... -
Page 7: Parts
Parts Important! Check that you have all parts before assembly. Flag Roll bar Seat Handlebar assembly Treasure chest Battery charger Axle pad (1) Wheel (4) Note: all wheels are Vehicle body identical Includes 6 volt battery Hubcap (4) Small washer (4) Retainer nut (4) Wheel cover (4) Headlight... -
Page 8: Assembly
Assembly ATTACH THE HEADLIGHT ASSEMBLY ❶ Position the headlight assembly so the arms of the headlight assembly are aligned with the tubes of the front axle assembly. ❷ Slide the headlight assembly into the tubes until the tabs on the arms snap into the slots on the front axle assembly. Headlight assembly snapped... -
Page 9: Attach The Handlebar Assembly
ATTACH THE HANDLEBAR ASSEMBLY ❶ Position the handlebar assembly so the start button is facing the seat, and the steering rod is aligned with the hole in the front axle assembly. Figure 3.2 ❷ Insert the steering rod and wire connector through the opening located on the top of the quad body. -
Page 10: Attach The Rear Wheels
ATTACH THE REAR WHEELS Before you begin: Remove the axle nut and washer from the ❹ Slide the wheel all the way onto the axle until it meets the end of the rear axle. large washer. Note: All the wheels are identical and can be placed on any axle. -
Page 11: Attach The Front Wheels
ATTACH THE FRONT WHEELS Before you begin: Remove the axle nut and washer from the end of the front axle. ❶ Slide the large washer onto the end of the front axle until it meets the axle stop. Figure 3.5 ❷... -
Page 12: Attach The Roll Bar
ATTACH THE ROLL BAR ❶ Position the roll bar with the screws facing the rear of the quad. Align the bottom of the roll bar with the holes located on each side of the seat opening, and press down firmly on the roll bar until it snaps into place. -
Page 13: Charge The Battery
CHARGE THE BATTERY Important! Before using the quad for the first time the battery needs to be charged for at least 24 hours. Only an adult who has read and understands the safety warnings should handle, charge or recharge of the battery. First charge 24 hours. -
Page 14: Attach The Seat
ATTACH THE SEAT ❶ Insert the seat tab into the seat slot located at the back of Open the seat compartment. Figure 3.9 Close ❷ Lower the seat onto the quad body, and turn the locking screw clockwise until the seat lock is engaged. Figure 3.9... -
Page 15: Use
OPERATING THE QUAD Important! Before using the quad for the first time the battery needs to be charged for a full 24 hours. Note: Do not charge more than 30 hours. Only an adult who has read and understands the safety warnings should handle, charge or recharge of the battery. -
Page 16: Re-Charge Interval And Time
RE-CHARGE INTERVAL AND TIME BATTERY STORAGE Important! Do not leave the battery connected in the vehicle for long period of times while not being used. This may drain the battery • Damage to the battery may occur if it is allowed to drain completely and cause permanent damage. -
Page 17: Battery Replacement And Disposal
BATTERY REPLACEMENT AND DISPOSAL ❼ Reconnect the battery connectors. The Kids Trax Toys 6V 4AH battery will eventually lose the ability ❽ Replace the metal battery bracket. to hold a charge. Depending on the amount of use, and varying conditions, the battery should operate for one to three years. ❾... -
Page 18: Maintenance
Water will damage the motor, electrical system and battery. • KidTrax Toys recommends that you take the vehicle to an authorized service center for periodic maintenance and service. Call Kid... -
Page 19: Troubleshooting Guide
Troubleshooting Guide The following are examples of potential problems. Completely read through this manual and the troubleshooting guide table before calling Kid Trax Toys Consumer Relations. If you still need help resolving the problem please call 877-741-6154. Kid Trax Toys recommends that you take the vehicle to an authorized service center for periodic maintenance and service. Call the number listed above for the closest center to you. - Page 20 Problem Possible Cause Remedy Vehicle does not run very Battery is old Replace battery (see Battery: Replacement and long Disposal Vehicle runs sluggishly or Battery low on power Recharge battery (see Battery: Recharge Interval beeping occurs and Time) Battery is old Replace battery (see Battery: Replacement and Disposal Vehicle is overloaded...
- Page 21 Problem Possible Cause Remedy 6V Battery will not recharge Battery connector or adapter connector is loose Check that battery connectors are firmly plugged into each other Charger not plugged in Check that battery charger is plugged into a working wall outlet Charger is not working (lights not glowing) Call Consumer Relations at 877-741-6154 for an authorized service center...
-
Page 22: Services, Repairs And Parts
Services, Repairs and Parts Do not return this product to the place of purchase. If your vehicle needs service, repairs or replacement parts, call: KidTrax Toys Consumer Relations Hours: 8:00 am – 5:00 pm (CST) Monday - Friday Phone: 877-741-6154 Email: customerservice@kidtraxtoys.com... -
Page 23: Warranty
1-800-858- 2800, 24 hours a day; write to KidTrax Consumer Relations Department, KidTrax Toys, P.O. Box 344 Olney, IL 62450 or call 1-877-741- 6154 from 8 a.m. -
Page 24: Contact Information
Contact Information If you have any questions or comments please contact us at: In U.S.A. © 2013 Pacific-Cycle Inc. 4902 Hammersly Rd. Madison, WI 53711 Customer Service: 877-741-6154 customerservice@kidtraxtoys.com www.kidtraxtoys.com...
