Installation and Operation Manual

DTE-16
DTMF Tone/Sequence Encoder
Firmware Version 1.05
Manual update 12/09/2004
Due to the dynamic nature of product design, the information contained in this
document is subject to change without notice. Broadcast Tools, Inc., assumes no
responsibility for errors and/or omissions contained in this document. Revisions
of this information or new editions may be issued to incorporate such changes.
Broadcast Tools® is a registered trademark of Broadcast Tools, Inc.
Copyright, 1989 - 2005 by Broadcast Tools, Inc. All rights reserved.
No part of this document may be reproduced or distributed without permission.
Visit www.broadcasttools.com for important product update information.

Advertisement

loading

Related Manuals for Broadcast DTE-16

Summary of Contents for Broadcast DTE-16

  • Page 1: Installation And Operation Manual

    Manual update 12/09/2004 Due to the dynamic nature of product design, the information contained in this document is subject to change without notice. Broadcast Tools, Inc., assumes no responsibility for errors and/or omissions contained in this document. Revisions of this information or new editions may be issued to incorporate such changes.

  • Page 2: Safety Information

    Thank you for your purchase of the tiny TOOLS™ DTMF Tone/Sequence Broadcast Tools® Encoder, which we will refer to throughout the manual as the DTE-16. We’re Products, as with any confident this product will give you many years of dependable service. This...

  • Page 3: Product Description

    “GD” Ground terminals. The station ground should be connected to the chassis ground screw located on the far right side of the DTE-16 as viewed from the rear. It is recommended that all cables connected to the DTE-16 be looped through ferrite cores to suppress RF.
  • Page 4 DTE-16 Installation and Operation Manual PROGRAMMING To program the DTE-16, you must connect a PC running a terminal program such as Windows HyperTerminal, Tera-Term, etc. Set the terminal program to 9600,8,N,1 flow control to none. Character Echo must be turned ON. There are two methods of entering program mode.

  • Page 5: Operation

    RS-232 string of @Lnnnn<cr>. The “@” is the start character, the “L” tells the DTE-16 to generate “Long” tones, nnn…nn is the string of tones to be sent and the carriage return will begin transmitting the buffered characters. For example, to send 5678, enter @L5678<cr>.
  • Page 6 If Broadcast Tools is notified, in writing, of a failure of any item manufactured by Broadcast Tools to conform to the foregoing Limited Warranty within one (1) year following the date of the Buyer’s acquisition of the item, and if the item is returned to Broadcast Tools in accordance with Broadcast Tools’...

  • Page 7: Functional Diagram

    DTE-16 Installation and Operation Manual APPENDIX A Functional Diagram Contact Closure, Trigger Inputs Female DB-9 Programming & Control RS-232 Port – Mix Input DTMF Tones Level Trimmer – DTMF & Mix Output Valid Tone Data 2.1mm Power Power APPENDIX e e - - m m a a i i l l : :...
