6. Menu Operation

Menu is accessed by pressing the left triangular button. Once in the Menu, turning the
rotary encoder cycles through the options while pressing the right triangular button (or
encoder which is equivalent) advances the selection. Pressing the left triangular button
again backs the selection one level until you exit the menu. All settings are preserved
when the unit is powered off. Default menu setting, also available after resetting the
defaults in the firmware menu item, are marked in bold. Default values are recommended,
please use other values only when required.

6.1 INPUT

USB 1.1 - Driver-less, plug-n-play computer input that is limited to 96kHz.
INPUT SYNC
•
USB 2.0 - Hi-speed computer input that is capable of 192kHz and 64x and 128xDSD
playback. Use of this input requires drivers installed on the computer. USB2.0 or the
Firewire inputs provide the highest quality playback.
INT SYNC
•
WORD CLOCK
•
FIREWIRE - Hi-speed computer input that is capable of 192kHz and 64x and 128xDSD
playback. Use of this input requires drivers installed on the computer. USB2.0 or the
Firewire inputs provide the highest quality playback.
INT SYNC
•
WORD CLOCK
•
S/PDIF - Coaxial S/PDIF input capable of receiving PCM data up to 192kHz and DSD
DOP (64xDSD only). This input can also be used to transmit digital data to computer via
FW connection.
INT 48.0kHz, 88.2kHz, 96.0kHz, 176.4kHz, 192.0kHz
•
INPUT SYNC
•
WORD CLOCK
•
TOSLINK - Optical S/PDIF input capable of receiving PCM data up to 192kHz and DSD
DOP (64xDSD only). This input can also be used to transmit digital data to computer via
FW connection.
INT 44.1kHZ, 48.0kHz, 88.2kHz, 96.0kHz, 176,4kHz, 192.0kHz
•
INPUT SYNC
•
WORD CLOCK
•
SDIF - Professional DSD input capable of receiving DSD64x to DSD256x formats.
SDIF RATE
•
