Precautions…………………………………………………………………………………………. Safety Tips……………………………………………………………………………………………. • Please read this manual carefully before using the camera. • Avoid damage from stress, violent vibration or liquid intrusion during transportation, storage or installation. • Take care of the camera during installation to prevent damage to the camera case, ports, lens or PTZ mechanism.
Page 3
• IR Remote Controller (1) • User Manual (1) Rear Board Connectors………………………………………………………………………… High Definition Interface: USB 3.0 Control Signal Interface: Mini DIN-8 (VISCA IN, VISCA OUT/RS485) Control Signal Configuration: Dip-Switch Pin 7/TTL Signal; Baud Rate: 9600bps Power Supply Interface: DC 12V Socket Electrical……….…………………………………………………………………………………….
Rear Board & Function……………………………………………………………………….. 1. Front View………………………………………………………………………………….. 1. Lens 20x Optical Zoom. 2. IR Receiver To receive IR remote controller signal. 3. Power LED Blue LED blinks when unit is powered. 4. Stand by LED Orange LED blinks for Stand-By status, Blue LED for Working Status.
2. Rear View…………………………………………………………………………………………. 6. Power Switch Power On/Off button. 7. DC IN 12V Socket Only use the Power Adapter supplied with this camera. 8. IR Receiver To receive IR remote controller signals. 9. IR Selective Switch When using only one remote to control more than one camera, this switch will assign a unique ID to each camera.
Used for daisy chaining multiple cameras for RS-232 RS-485 control. 12. USB 3.0 Interface For connection to PC. 2. Bottom View…………………………………………………………………………………. 1. Tripod Will accept 1/4-20 bolt from 3 party tripod, wall or ceiling mount. 2. Dip-Switch Used for selecting baud rate and the remote signal output switch. Ver 1.1 6/26/14...
Page 7
4. Dip-Switch Settings………………………………………………………………………….. Dip-Switch 1 - (To set communication baud rate). Dip-Switch 2 - (To set control protocol). Dip-Switch 3 - (Set only for firmware upgrading). Dip Switch 4 & 5 - (To set camera’s RS232/RS485 ID number – for daisy chain wired control).
Page 8
Cable Connection Info………………………………………………………………………… VISCA RS-232C - IN Reference……………………………………………………………… VISCA RS-232C - Out Reference…………………………………………………………… Ver 1.1 6/26/14...
Page 9
OSD MENU…………………………………………………………………………………………….. On Screen Display Menu - Use the OSD menu to access and change the camera’s settings. Note: You cannot manually move the camera (pan/tilt) when the OSD menu is visible on the screen. The Dome OSD Menu is as follows: •...
The Lens OSD Menu is as follows: • Default Value: Off Wide Dynamic Range = On or Off • BACKLIGHT Default Value: OFF ON/OFF • NR (Noise Reduction) Default Value: 3 Adjustable Value: 0-5 • WB (White Balance) Default Value: Auto Auto/Manual/Outdoor/Indoor/One Push/ATW (Manual Settings): ◦...
Page 11
IR Remote Controller (Note: Some buttons do not operate for all camera models) Reset: Restarts the camera and restores it to Factory Default settings. (Note: Will delete all memory). Camera Selection Select Camera ID: 1, 2 or 3 Preset Positions 1-9: Preset Positions Set: Setting Preset Position Clear: Clear Preset Position...
Page 12
Pan/Tilt Function Zone L-Limit: Set left boundary limit scanning position Scan: Enable Boundary Scanning (Auto Panning) R-Limit: Set right boundary limit scanning position Home: Go to camera’s Home position Tour: Enable automatic patrol tour of presets Rev: Enable image flip for ceiling mounting Connection Instructions………………………………………………………………………...
Installation Instructions……………………………………………………………………… Desktop Installation……………………………………………………………………………… When using the HuddleCam on a desk, Make sure that it will stand level. If you want to use the camera on an incline, make sure the angle is less than 15 degrees to ensure that the camera’s pan and tilt mechanism operates normally. Tripod Installation…………………………………………………………………………………...
Page 14
Ceiling Mount………………………………………………………………………………………… Ver 1.1 6/26/14...
Troubleshooting………….………………………………………………………………………… Problem Cause Resolution There is no power to the Power adapter is Check the connections camera. disconnected from mains between the camera, or from camera. power adapter and mains. If anything is disconnected, reconnect Power switch is set to OFF. Set the power switch to Camera will not connect to USB cable is bad.
