HK Audio A.C.T.O.RDX 112ASAT Service Documents

Hide thumbs

Advertisement

Quick Links

Service Documents
Confidential, for authorized service technicians only!
Do not disclose this information to or share these documents
A.C.T.O.R
Note!
The components used in this product - particularly parts affecting
safety as well as speakers and transformers - were developed and
manufactured to certain specifications. Please use original spare
parts only to ensure the product remains fully functional and safe.
TECHNICAL SERVICE:
Stamer Musikanlagen GmbH • Magdeburger Str. 8 • 66606 St.Wendel • Germany
Music & Sales P.E. GmbH • Leipziger Str. 3 • 66606 St.Wendel • Germany
with third parties.
Vertraulich! Nur für autorisierte Servicetechniker!
Nicht zur Weitergabe an Dritte freigegeben!
DX 112A
SAT
Achtung!
Die in diesem Produkt verwendeten Komponenten, insbesondere
sicherheitsrelevante Teile, Lautsprecher und Transformatoren
wurden nach spezifischen Vorgaben entwickelt und gefertigt.
Bitte benutzen Sie ausschließlich Original-Ersatzteile – nur so ist
die volle Funktionalität und Sicherheit gewährleistet.
13.07.07

Advertisement

loading
Need help?

Need help?

Do you have a question about the A.C.T.O.RDX 112ASAT and is the answer not in the manual?

Questions and answers

Related Manuals for HK Audio A.C.T.O.RDX 112ASAT

Summary of Contents for HK Audio A.C.T.O.RDX 112ASAT

  • Page 1 13.07.07 Service Documents Confidential, for authorized service technicians only! Do not disclose this information to or share these documents with third parties. Vertraulich! Nur für autorisierte Servicetechniker! Nicht zur Weitergabe an Dritte freigegeben! A.C.T.O.R DX 112A Note! Achtung! The components used in this product - particularly parts affecting Die in diesem Produkt verwendeten Komponenten, insbesondere safety as well as speakers and transformers - were developed and sicherheitsrelevante Teile, Lautsprecher und Transformatoren...
  • Page 2 Directory features page: drawing-numbers-example page: standard for single wire confection page: HK1104-A.C.T.O.R DX SATELLITE 112A page: exploded drawings: complete /active Rev.: page: 16-17 complete /passive Rev.: page: 18-19 chassis /active Rev.: page: 20-22 chassis /passive Rev.: page: 23-24 front grille Rev.: page: cabling 100-240V...

  • Page 3: Table Of Contents

    All the best from the HK AUDIO team; enjoy your ACTOR DX system! Table of Contents 1 ACTOR DX System Components ... .6 2 Transport .
  • Page 4 – making the most of sonic energy – for less pre-gig stress The novel DuoTilt™ pole mount allows sound energy Like all HK AUDIO Active Systems, ACTOR DX to be utilized far more efficiently. DuoTilt™ offers was designed as a cohesive system consisting of 7.5°...

  • Page 5: Actor Dx System Components

    ADX 112 A Mid/High Unit two ACTOR ADX 112 A mid/high units, ADX 112 A These enclosures are loaded with one 12" HK AUDIO two ADX 115 Sub A subwoofers and Custom speaker and one 1. 4" compression driver two ADX 115 Sub B subwoofers.
  • Page 6 1= ground, 2= +, 3= - 3.5 Flying ACTOR ADX 112 A Mid/High Units Use the HK AUDIO rigging frame to fly ACTOR DX mid/high units. To attach the frame, remove the countersunk M10 hex head bolts from the side panels.

  • Page 7: Connections And Control Features

    ACTOR DX Manual 1.1 5 Input Sensitivity 4 Connections and Control This selector matches the preamp’s input sensitivity Features to the mixer’s output signal level. Engage this switch to select either -10 dB (for exam- 4.1 ACTOR ADX 112 A ple, for unbalanced 1/4”...
  • Page 8 11 Display 14 Subwoofer Level Read-out: The numeric display indicates the Operation: When the knob is set to the 12 o’clock currently selected system configuration. position, the subwoofer’s and the mid/high unit’s respective volumes are matched, ensuring bass and mid/high ranges are rendered in balanced musical 0 Mute proportion.

  • Page 9: Tips And Tricks

    ACTOR DX Manual 1.1 Feel free to use a four-core cable if you wish, though 4.2 ACTOR ADX 115 Sub A pin 2+ and 2- remain unused, of course. 1 Power Switch Operation: This is the on/off switch for the active system.

  • Page 10: Actor Dx Accessories

    TV spigots and clamps. control panels. It is acceptable for these to flash yellow from time to time, but under no To learn more about original HK AUDIO accessories, circumstances may the yellow LEDs illuminate talk to your HK AUDIO dealer or visit continuously.

  • Page 11: Technical Specifications

    1.4" Directivity: 60° x 40° CD horn Crossover frequency: 950 Hz, 12 dB/octave Pole mount: HK AUDIO DuoTilt™, 36 mm, 7.5°, 15° Rigging points: 4 M10 threaded bushings for attaching an optional rigging bracket Accessories: ACTOR DX Tilt-Unit, 7.5°, 15°...
  • Page 12 +/- 10% Lothar Stamer Dipl.Ing. Ambient temperature range: -10° C to +35° C Managing Director Internal fuses: St.Wendel, 04/15/05 * Stamer Musikanlagen manufactures exclusively for HK AUDIO ® ACTOR ADX 115 Sub B Connections: 1x Speakon ® Input Nominal power handling:...
  • Page 13 KU = PLASTIC / KUNSTSTOFF LP = PCB / LEITERPLATTEN SO = MISCELLANEOUS / SONSTIGES SP = SCHEMATIC / SCHALTPLÄNE TR = TRANSFORMER / TRANSFORMATOR GK = WIRING DIAGRAM / GERÄTEVERKABELUNG PROJECT-NR.: HK = HK AUDIO HU = HUGHES&KETTNER MP = MINDPRINT...
  • Page 14 Stand 17. Jun 04 Standard for single wire confection. 485 W 1015 style 1015 according UL specifications I = completely insulated with black shrinktube or appropriate sleeve IT = partly insulated; only crimp connection insulated. no marking = without insulation Z = with additional junction no marking = without additional junction W = angled faston...
  • Page 15 Service Documents HK1104 A.C.T.O.R DX 112A Satellite Confidential, for authorized service technicians only! Do not disclose this information to or share these documents with third parties. TECHNICAL SERVICE: Stamer Musikanlagen GmbH • Magdeburger Str. 8 • 66606 St.Wendel • Germany Music &...
  • Page 16 E 994178 E 974381 E 974355 SCHWINGSPULE ALS ERSATZTEIL: E 976159 994191-B&M MD/DE 254 8OHM MEMBRANA E 972008 E 974227 E 974099 3 E 502180 (220-240V) E 502181 (100-120V) HK1104-EX-R03-1B E 994177 E 972047 E 976072 E 994217 E 1124 HK1104-EX-R04-1B 2 E 400263 HK1104-HZ-R01-1C...
  • Page 17 pos. no. part-no. 1 part-no. 2 description Beschreibung quantity 1124 front grille Actor DX sattelite Frontgitter Actor DX Top 400263 wooden cabinet, ACTOR DX Top Holzgeh. ACTOR DX Top 502180 502181 chassis Actor DX sattelite Chassis Actor DX Top (220-240V) (100-120V) 520118 crossover Actor DX sat...
  • Page 18 14 E 970638 E 970744 HK0502-BL-R04-1A HK1104-BL-R01-1D 19 E 974007 8 E 950060 E 970745 HK1104-BL-R04-1A 13 E 966046 12 E 966001 E 974110 E 970739 HK1104-SO-R01-1B E 943230 28 E 974444 E 600080 HK1104-SO-R06-1A E 974075 24 E 974157 E 600079 31 E 976141 E 950055...
  • Page 19 pos. no. part-no. 1 description Beschreibung quantity pos. no. part-no. 1 description Beschreibung quantity 547053 Actor DX Top Mainboard Actor DX Top Mainboard 974075 cross recessed panhead screw, M3x5, Linsenschraube M3x5 vz zinc plated 547053 ADX112A Displayboard Assembly (part ADX112A, Bedienpanel Baugruppe (Teil of mainboard) von Mainboard) 974084...
  • Page 20 TITEL: ACTOR DX SATTELITE EXPLODED DRAWING CHASSIS 66606 St. Wendel / Germany ZEICHNUNGS-NR.: HK1104-EX-R03-1B VERSION: REVISION: BLATT: ERSTELLT VON: C. LORIS 20.06.07 ÄNDERUNG ZEICHNER INDEX GEPRÜFT/ BLÄTTER FREIGEGEBEN VON: 1B-200607 update for service manual C. Loris WERKSTOFF: OBERFLÄCHE: HK1104-EX-R03-1B-CHASSIS-TOP DATEINAME:...
  • Page 21 Streckgitter 972085 acoustic foam anthracite 15mm Akustikschaum Anthrazit 15mm 974158 snapon retaining ring (for logo) Schnellbefestiger f. Logo 980105 logo ´HK Audio´ 55x55 mm Logo ´HK Audio´ 55x55 mm 1 E 970335 HK1104-SO-R03-1C 3 E 974158 E 972085 HK1104-SO-R05-1C TITEL:...
  • Page 22      !∀ ##    4 5  6& 7 !8∗+9∗:       !∀ ## 2∗∗ ∋ ∗2!−!.    9;+ 8∗+!/−//           ...
  • Page 23          4 5  6#& 7 8∗+9∗:        2∗∗ ∋ ∗2−.    9;+ 8∗+/−//      !∀ ∀#  #      ...
  • Page 24 TITEL: HK1104 - A.C.T.O.R. DX Bestückungsplan Mainboard 66606 St. Wendel / Germany ZEICHNUNGS-NR.: VERSION: HK1104-LP-R01-1D REVISION: BLATT: ERSTELLT VON: Michael Bohlender 22.06.2005 ZEICHNER INDEX ÄNDERUNG GEPRÜFT/ Michael Bohlender 22.06.2005 BLÄTTER FREIGEGEBEN VON: WERKSTOFF: OBERFLÄCHE: FR4, zweiseitig, 1.6mm HAL, Lötstop zweiseitig HK1104-LP-R01-1D-Bestueckung DATEINAME:...
  • Page 25 TITEL: HK1104 - A.C.T.O.R. DX Bestückungsplan Mainboard 66606 St. Wendel / Germany ZEICHNUNGS-NR.: VERSION: REVISION: HK1104-LP-R01-1D BLATT: ERSTELLT VON: Michael Bohlender 22.06.2005 ZEICHNER INDEX ÄNDERUNG GEPRÜFT/ Michael Bohlender 22.06.2005 BLÄTTER FREIGEGEBEN VON: WERKSTOFF: OBERFLÄCHE: FR4, zweiseitig, 1.6mm HAL, Lötstop zweiseitig DATEINAME: HK1104-LP-R01-1D-Bestueckung...
  • Page 26 Date Modification Revision Name 24.02.2005 1st draft published to EPA M. Bohlender 07.03.2005 Signal LED's TOP/BASS assignment changed M. Bohlender R8 to -15V, R27=1k5, C42=33nK, R29=1k2 BR5, BR6 = NA, BR7 changed to R12a (10k) BR2, R10, R12, R7, R9, C36, C37, R82 = NA Analog_Interface Digital_Interface R75, R88, R83 = 22k, C39/C40 = 10u/63V Elko...
  • Page 27 +15V +15V REL2 -15V +15V 47p/100V-K 47p/100V-K 47p/100V-K JST-B03B-EH-A 1N4148 LINE IN INPUT BL01RN1A1F1J INPUT 10u/63V 240R MC33079P(MOT) XLR/F-NC3FBH2 -15V TQ2-12V BL01RN1A1F1J 10u/63V -15V -15V 47pF/100V-K REL1C TQ2-12V-1 47R/1W 47n/250V LINE THROUGH SUB OUT BL01RN1A1F1J XLR/M-NC3MBH BL01RN1A1F1J 47p/100V-K XLR/M-NC3MBH BL01RN1A1F1J System Input 47p/100V-K DDO Sub Output...
  • Page 28 Display and Control Board Digital Mainboard Section Mechanics / Ref-Points / Filtering BASS HO34 HO35 DK-R70-B32 DK-R70-B32 INPUT LEFT_INPUT +15V +15V R100 R101 R103 R104 RIGHT_INPUT +5VA SUB_OUTPUT DGND Sub_Out SUB_OUTPUT SUB_OUTPUT AGND AGND Top_Out TOP_OUTPUT LEFT_OUTPUT Top_Out TOP_OUTPUT RIGHT_OUTPUT -15V -15V RD0102-LP-R01...
