User Manual
P Line Touch Panel
Part Number:
80860.761
Version:
7
Date:
2014-03-12
Valid for:
TP057ZTV
TP057GTV
TP070ZTW
TP070GTW
TP090ZTW
TP090GTW
TP105ZTS
TP105GTS
TP121ZTS
TP121GTS
TP121ZTM
TP121GTM
TP150ZTX
TP150GTX
TP154ZTM
TP154GTM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P Line and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sutron P Line

Summary of Contents for Sutron P Line

  • Page 1 User Manual P Line Touch Panel Part Number: 80860.761 Version: Date: 2014-03-12 Valid for: TP057ZTV TP057GTV TP070ZTW TP070GTW TP090ZTW TP090GTW TP105ZTS TP105GTS TP121ZTS TP121GTS TP121ZTM TP121GTM TP150ZTX TP150GTX TP154ZTM TP154GTM...
  • Page 2 P Line Touch Panel Version Date Modifications 2010-05-18 First Edition 2010-10-15 TP070ZTW, TP090ZTW, TP121ZTS added. 2011-09-13 TP057ZTV, TP121ZTM, TP151ZTX added. 2012-12-12 TP154ZTM, TP070GTW, TP090GTW, TP121GTM, TP154ZTM added. 2013-05-15 RS232 / RS485 COM ports updated. 2013-08-08 TP057ZTV, TP121GTS, TP150GTX added. 2014-03-12 TP105ZTS, TP105GTS added.

  • Page 3: Table Of Contents

    P Line Touch Panel Overall Table of Contents Overall Table of Contents Important Notes ......................7 Symbols ....................... 7 Safety Notes ....................7 Intended Use....................8 Target Group....................8 Installation and Commissioning .................. 9 Unpacking the Device .................. 9 Mounting the Device ..................9 2.2.1...
  • Page 4 Overall Table of Contents P Line Touch Panel 2.4.1.2.4 Network ......................... 38 2.4.1.2.5 Password ......................39 2.4.1.2.6 Display ........................39 2.4.1.2.7 Write Filter......................39 Identification ....................41 Control and Display Elements ................... 43 Touch Screen..................... 43 Display ....................... 43 Interfaces of the Device .................... 45 Ethernet......................
  • Page 5 P Line Touch Panel Overall Table of Contents Technical Data......................63 General ...................... 63 TP057ZTV....................65 TP057GTV ....................67 TP070ZTW....................69 TP070GTW ....................71 TP090ZTW....................73 TP090GTW ....................75 TP105ZTS....................77 TP105GTS ....................79 6.10 TP121ZTS....................81 6.11 TP121GTS ....................83 6.12...
  • Page 6 Overall Table of Contents P Line Touch Panel...

  • Page 7: Important Notes

    P Line Touch Panel Important Notes 1 Important Notes Symbols The symbols in this manual are used to draw your attention on notes and dangers. This is the safety alert symbol. It is used to alert you to potential personal injury hazards.

  • Page 8: Intended Use

    Important Notes P Line Touch Panel Intended Use – The device is designed for use in the industry. – The device is state-of-the art and has been built to the latest standard safety requirements. However, dangerous situations or damage to the machine itself or other property can arise from the use of this device.

  • Page 9: Installation And Commissioning

    P Line Touch Panel Installation and Commissioning 2 Installation and Commissioning Unpacking the Device Unpack all parts carefully and check the contents for any visible damage in transit. Also check whether the shipment matches the specifications on your delivery note.

  • Page 10: Front Panel Dimensions

    Installation and Commissioning P Line Touch Panel 2.2.1 Front Panel Dimensions 2.2.1.1 TP057ZTV / TP057GTV Figure 2-2 TP057ZTV / TP057GTV...

  • Page 11: Tp070Ztw / Tp070Gtw

    P Line Touch Panel Installation and Commissioning 2.2.1.2 TP070ZTW / TP070GTW Figure 2-3 TP070ZTW / TP070GTW...

  • Page 12: Tp090Ztw / Tp090Gtw

    Installation and Commissioning P Line Touch Panel 2.2.1.3 TP090ZTW / TP090GTW Figure 2-4 TP090ZTW / TP090GTW...

  • Page 13: Tp105Zts / Tp105Gts

    P Line Touch Panel Installation and Commissioning 2.2.1.4 TP105ZTS / TP105GTS Figure 2-5 TP105ZTS / TP105GTS...

  • Page 14: Tp121Zts / Tp121Gts

    Installation and Commissioning P Line Touch Panel 2.2.1.5 TP121ZTS / TP121GTS Figure 2-6 TP121ZTS / TP121GTS...

  • Page 15: Tp121Ztm / Tp121Gtm

    P Line Touch Panel Installation and Commissioning 2.2.1.6 TP121ZTM / TP121GTM Figure 2-7 TP121ZTM / TP121GTM...

  • Page 16: Tp150Ztx / Tp150Gtx

    Installation and Commissioning P Line Touch Panel 2.2.1.7 TP150ZTX / TP150GTX Figure 2-8 TP150ZTX / TP150GTX...

  • Page 17: Tp154Ztm / Tp154Gtm

    P Line Touch Panel Installation and Commissioning 2.2.1.8 TP154ZTM / TP154GTM Figure 2-9 TP154ZTM / TP154GTM...

  • Page 18: Mounting Cutout

    Installation and Commissioning P Line Touch Panel 2.2.2 Mounting Cutout 2.2.2.1 TP057ZTV / TP057GTV Figure 2-10 TP057ZTV / TP057GTV A Mounting Cutout B Front Panel...

  • Page 19: Tp070Ztw / Tp070Gtw

    P Line Touch Panel Installation and Commissioning 2.2.2.2 TP070ZTW / TP070GTW Figure 2-11 TP070ZTW / TP070GTW A Mounting Cutout B Front Panel...

  • Page 20: Tp090Ztw / Tp090Gtw

    Installation and Commissioning P Line Touch Panel 2.2.2.3 TP090ZTW / TP090GTW Figure 2-12 TP090ZTW / TP090GTW A Mounting Cutout B Front Panel...

  • Page 21: Tp105Zts / Tp105Gts

    P Line Touch Panel Installation and Commissioning 2.2.2.4 TP105ZTS / TP105GTS Figure 2-13 TP105ZTS / TP105GTS A Mounting Cutout B Front Panel...

  • Page 22: Tp121Zts / Tp121Gts

    Installation and Commissioning P Line Touch Panel 2.2.2.5 TP121ZTS / TP121GTS Figure 2-14 TP121ZTS / TP121GTS A Mounting Cutout B Front Panel...

  • Page 23: Tp121Ztm / Tp121Gtm

    P Line Touch Panel Installation and Commissioning 2.2.2.6 TP121ZTM / TP121GTM Figure 2-15 TP121ZTM / TP121GTM A Mounting Cutout B Front Panel...

  • Page 24: Tp150Ztx / Tp150Gtx

    Installation and Commissioning P Line Touch Panel 2.2.2.7 TP150ZTX / TP150GTX Figure 2-16 TP150ZTX / TP150GTX A Mounting Cutout B Front Panel...

  • Page 25: Tp154Ztm / Tp154Gtm

    P Line Touch Panel Installation and Commissioning 2.2.2.8 TP154ZTM / TP154GTM Figure 2-17 TP154ZTM / TP154GTM A Mounting Cutout B Front Panel...

  • Page 26: Side View, Mounting Depth

    Installation and Commissioning P Line Touch Panel 2.2.3 Side View, Mounting Depth 2.2.3.1 TP057ZTV / TP057GTV Figure 2-18 TP057ZTV / TP057GTV Mounting Bracket Threaded Pin Mounting Surface Thickness 1 mm to 6 mm Circumferential Seal Front Panel...

  • Page 27: Tp070Ztw / Tp070Gtw

    P Line Touch Panel Installation and Commissioning 2.2.3.2 TP070ZTW / TP070GTW Figure 2-19 TP070ZTW / TP070GTW Mounting Bracket Threaded Pin Mounting Surface Thickness 1 mm to 6 mm Circumferential Seal Front Panel...

  • Page 28: Tp090Ztw / Tp090Gtw

    Installation and Commissioning P Line Touch Panel 2.2.3.3 TP090ZTW / TP090GTW Figure 2-20 TP090ZTW / TP090GTW Mounting Bracket Threaded Pin Mounting Surface Thickness 1 mm to 6 mm Circumferential Seal Front Panel...

  • Page 29: Tp105Zts / Tp105Gts

    P Line Touch Panel Installation and Commissioning 2.2.3.4 TP105ZTS / TP105GTS Figure 2-21 TP105ZTS / TP105GTS Mounting Bracket Threaded Pin Mounting Surface Thickness 1 mm to 6 mm Circumferential Seal Front Panel...

  • Page 30: Tp121Zts / Tp121Gts

    Installation and Commissioning P Line Touch Panel 2.2.3.5 TP121ZTS / TP121GTS Figure 2-22 TP121ZTS / TP121GTS Mounting Bracket Threaded Pin Mounting Surface Thickness 1 mm to 6 mm Circumferential Seal Front Panel...

  • Page 31: Tp121Ztm / Tp121Gtm

    P Line Touch Panel Installation and Commissioning 2.2.3.6 TP121ZTM / TP121GTM Figure 2-23 TP121ZTM / TP121GTM Mounting Bracket Threaded Pin Mounting Surface Thickness 1 mm to 6 mm Circumferential Seal Front Panel...

  • Page 32: Tp150Ztx / Tp150Gtx

    Installation and Commissioning P Line Touch Panel 2.2.3.7 TP150ZTX / TP150GTX Figure 2-24 TP150ZTX / TP150GTX Mounting Bracket Threaded Pin Mounting Surface Thickness 1 mm to 6 mm Circumferential Seal Front Panel...

  • Page 33: Tp154Ztm / Tp154Gtm

    P Line Touch Panel Installation and Commissioning 2.2.3.8 TP154ZTM / TP154GTM Figure 2-25 TP154ZTM / TP154GTM Mounting Bracket Threaded Pin Mounting Surface Thickness 1 mm to 6 mm Circumferential Seal Front Panel...

  • Page 34: Connecting The Device

    Installation and Commissioning P Line Touch Panel Connecting the Device 2.3.1 Supply Voltage The supply voltage is supplied via pin strip X1. A suitable socket strip is supplied. Refer to the technical data for the permissible supply voltage of the operating de- vice.

  • Page 35: Grounding

    P Line Touch Panel Installation and Commissioning 2.3.2 Grounding The grounding is performed - depending on the type of device - with a slip-on sleeve (noiseless ground / functional earth ground) or a ring cable lug (protective ground). NOTICE: Damage A separate copper conductor must always be provided for the grounding.

  • Page 36: Switching On

    Installation and Commissioning P Line Touch Panel Switching On When switching on the operating system loads. The interface for SD/SDHC cards is available for applications and other data. 2.4.1 Cockpit The operating device allows you - by starting the cockpit during the startup phase - to make changes to the device configuration.

  • Page 37: Menu Structure

    P Line Touch Panel Installation and Commissioning 2.4.1.1 Menu Structure Start Normal Cockpit Language Selection English German Date and Time Administration Information Network IP Address WINS / DNS Device Name SNTP Password Display Brightness Orientation Calibrate Touch Write Filter FBWF HORM 2.4.1.2...

  • Page 38: Date And Time

    Installation and Commissioning P Line Touch Panel 2.4.1.2.2 Date and Time You set up date, time and time zone via the Date and Time menu item. 2.4.1.2.3 Administration The Administration menu shows device information. Information The following informations are displayed: –...

  • Page 39: Password

    P Line Touch Panel Installation and Commissioning 2.4.1.2.5 Password The menu item Password allows you to protect certain menu items in the cockpit with a password. Current password 1. Enter a password for the protected menu items. 2. Confirm your selection with the green check.
  • Page 40 Installation and Commissioning P Line Touch Panel Disable EWF 1. Press the Disable EWF button. 2. Confirm your selection with the green check. 3. Restart the operating device for the changes to take effect. FBWF The file based write filter (FBWF) protects your system from write access and in- stead writes the data to the main memory.

  • Page 41: Identification

    P Line Touch Panel Installation and Commissioning Identification The operating device can be identified using the nameplate on the rear of the de- vice. Figure 2-29 Nameplate (example) Device Type Software Version (Version on Delivery) MAC Addresses Voltage and Current...
  • Page 42 Installation and Commissioning P Line Touch Panel...

  • Page 43: Control And Display Elements

    P Line Touch Panel Control and Display Elements 3 Control and Display Elements Touch Screen The device is equipped with a resistive 4 wire touch screen. You operate the de- vice using this touch screen. NOTICE: Damage Pointed or sharp objects, such as pens or fingernails, can lead to irreparable damages of the touch screen.
  • Page 44 Control and Display Elements P Line Touch Panel...

  • Page 45: Interfaces Of The Device

    P Line Touch Panel Interfaces of the Device 4 Interfaces of the Device Figure 4-1 Rear view Slot for SD / SDHC Memory Card Ethernet X7, X6 (10/100/1000 MBit) Female Connector X2 - X5 (USB Host - Type A) Supply Voltage...

  • Page 46: Ethernet

    Interfaces of the Device P Line Touch Panel Ethernet 10/100/1000 Base-T Ethernet interfaces are available at the operating device. 4.1.1 Pin Assignment Connector in the operating device: RJ45 female connector. Table 4-1 Pin assignment of the Ethernet interface Designation Function...

  • Page 47: Diagnosis

    P Line Touch Panel Interfaces of the Device 4.1.3 Diagnosis Ethernet diagnostics LEDs are located at the ethernet interface of the operating device. Figure 4-2 Arrangement of the Ethernet diagnostics LEDs Table 4-2 Function of Ethernet diagnostics LEDs Color State...

  • Page 48: Serial Interfaces

    Interfaces of the Device P Line Touch Panel Serial Interfaces Figure 4-3 Rear view RS-422 / RS-485, RS-232 Slot for SD / SDHC Memory Card Ethernet X7, X6 (10/100/1000 MBit) Female Connector X2 - X5 (USB Host - Type A)

  • Page 49: Rs-485 (X14)

    P Line Touch Panel Interfaces of the Device 4.3.1 RS-422 / RS-485 (X14) The interface standard RS-422 / RS-485 is suitable for point-to-point and multi- point connections. The wires belonging together are marked with „A“ and „B“. Some descriptions re- fer to the pins with „-“...

  • Page 50: Termination

    Interfaces of the Device P Line Touch Panel 4.3.1.2 Termination Always turn on the termination in a 4-wire point-to-point connection (RS-422 / RS- 485). A sender termination for the quiescent level of the receiver must exist on the remote station.

  • Page 51: Transmitter Control

    P Line Touch Panel Interfaces of the Device 4.3.1.3 Transmitter Control Switching between half-duplex and full-duplex is carried out by the DTR signal. Full-duplex (DTR inactive / off): The transmitter is always active and is not turned off on intermissions.

  • Page 52: Rs232 (X15)

    Interfaces of the Device P Line Touch Panel 4.3.2 RS232 (X15) The serial RS-232 interface is suitable to establish a point-to-point connection. The interface is assigned to the port COM3. At an image version before 181 and operating system Windows CE 6.0 the port COM0 is assigned.

  • Page 53: Field Bus Interfaces

    P Line Touch Panel Interfaces of the Device Field Bus Interfaces 4.4.1 CAN (X12, X13) Figure 4-7 Rear view CAN Slot for SD / SDHC Memory Card Ethernet X7, X6 (10/100/1000 MBit) Female Connector X2 - X5 (USB Host - Type A)

  • Page 54: Pin Assignment

    Interfaces of the Device P Line Touch Panel 4.4.1.1 Pin Assignment Figure 4-8 5 pin M12 male connector Connector in the operating device: 5 pin M12 male connector. Table 4-9 Pin assignment CAN 1 Designation Function Shielding Reserved Reserved for DeviceNet...

  • Page 55: Termination

    P Line Touch Panel Interfaces of the Device 4.4.1.3 Termination Terminate the CAN bus at both ends by terminating resistors (120 Ohm). The switch positions for ON or OFF are printed onto the operating device. Only the specified switch positions are allowed.

  • Page 56: Memory Card

    Interfaces of the Device P Line Touch Panel Memory Card At the underside of the operating device you can plug in an SD card. NOTICE Using hardware not suitable for industrial use (e.g. keyboard, mouse, memory card) may decrease safety of operation. This includes hardware intended for home and office use.

  • Page 57: Shielding D-Sub Connectors

    P Line Touch Panel Interfaces of the Device Shielding D-SUB Connectors You must shield D-SUB connectors as follows: Figure 4-10 Shielding D-SUB connectors D-SUB connector Shield Cable clip Cable The shield must be folded back into a flat position over the cable sheath.
  • Page 58 Interfaces of the Device P Line Touch Panel...

  • Page 59: Maintenance And Servicing

    P Line Touch Panel Maintenance and Servicing 5 Maintenance and Servicing Maintenance Interval The following maintenance intervals are recommended for this operating device: Table 5-1 Maintenance interval Maintenance work Interval Changing the Battery 4 Years Front Panel Only use a damp cloth to remove any dirt from the front panel.

  • Page 60: Changing The Battery

    Maintenance and Servicing P Line Touch Panel 5.4.1 Changing the Battery NOTICE: Damage Batteries must only be changed by authorized and trained experts! NOTICE: Damage Electrostatic discharge can damage electronic components. Observe the ESD protective measures! CAUTION: Explosive Do not throw lithium batteries into fire, do not heat to 100 °C or higher and do not recharge.

  • Page 61: Battery Disposal

    P Line Touch Panel Maintenance and Servicing 5.4.2 Battery Disposal The manufacturer is obliged to mark batteries with this symbol before first placing into market. The symbol is extended by the chemical symbols if the following lim- iting values are exceeded: More than 0.0005 mass percent mercury...
  • Page 62 Maintenance and Servicing P Line Touch Panel...

  • Page 63: Technical Data

    P Line Touch Panel Technical Data 6 Technical Data General Touch Screen Type Analog resistive, 4 wire technology Activation force 15 g (Standard) With R8 HS60 silicon rubber Durability No damages or malfunctions after 3 million keystrokes as the following:...
  • Page 64 Technical Data P Line Touch Panel Standards and Guidelines Interference immunity EN 61000-4-2 EN 61000-4-3 EN 61000-4-4 EN 61000-4-5 EN 61000-4-6 EN 61000-6-2 Emitted interference EN 61000-6-4 EN 50011 limit class value A EN 50022 limit class value A Equipment requirements...

  • Page 65: Tp057Ztv

    P Line Touch Panel Technical Data TP057ZTV Central Processing Unit Central processing unit Intel® Atom™ Clock frequency 1.6 GHz Display Size (diagonal) in cm 14.48 (5.7) (inch) Type TFT (color) Resolution (pixels) 640 x 480 Colors 262144 Reading angle (vertical / 107°...
  • Page 66 Technical Data P Line Touch Panel Front Panel and Enclosure Enclosure Steel sheet, galvanized Front panel material Aluminium, brushed, anodized natural finish Front panel (H x W x D) in 126 x 168 x 5 mm (Inch) (4.961 x 6.614 x 0.197)

  • Page 67: Tp057Gtv

    P Line Touch Panel Technical Data TP057GTV Central Processing Unit Central processing unit AMD embedded G-Series Clock frequency 1 GHz single / dual-core Display Size (diagonal) in cm 14.48 (5.7) (inch) Type TFT (color) Resolution (pixels) 640 x 480 Colors...
  • Page 68 Technical Data P Line Touch Panel Front Panel and Enclosure Enclosure Steel sheet, galvanized Front panel material Aluminium, brushed, anodized natural finish Front panel (H x W x D) in 126 x 168 x 5 mm (Inch) (4.961 x 6.614 x 0.197)

  • Page 69: Tp070Ztw

    P Line Touch Panel Technical Data TP070ZTW Central Processing Unit Central processing unit Intel® Atom™ Clock frequency 1.6 GHz Display Size (diagonal) in cm 17.78 (7) (inch) Type TFT (color) Resolution (pixels) 800 x 480 Colors 262144 Reading angle (vertical / 130°...
  • Page 70 Technical Data P Line Touch Panel Front Panel and Enclosure Enclosure Steel sheet, galvanized Front panel material Aluminium, brushed, anodized natural finish Front panel (H x W x D) in 147 x 203 x 5 mm (Inch) (5.787 x 7.992 x 0.197)

  • Page 71: Tp070Gtw

    P Line Touch Panel Technical Data TP070GTW Central Processing Unit Central processing unit AMD embedded G-Series Clock frequency 1 GHz single / dual-core Display Size (diagonal) in cm 17.78 (7) (inch) Type TFT (color) Resolution (pixels) 800 x 480 Colors...
  • Page 72 Technical Data P Line Touch Panel Front Panel and Enclosure Enclosure Steel sheet, galvanized Front panel material Aluminium, brushed, anodized natural finish Front panel (H x W x D) in 147 x 203 x 5 mm (Inch) (5.787 x 7.992 x 0.197)

  • Page 73: Tp090Ztw

    P Line Touch Panel Technical Data TP090ZTW Central Processing Unit Central processing unit Intel® Atom™ Clock frequency 1.6 GHz Display Size (diagonal) in cm 22.86 (9) (inch) Type TFT (color) Resolution (pixels) 800 x 480 Colors 16.77 million Reading angle (vertical / 170°...
  • Page 74 Technical Data P Line Touch Panel Front Panel and Enclosure Enclosure Steel sheet, galvanized Front panel material Aluminium, brushed, anodized natural finish Front panel (H x W x D) in 172 x 260 x 5 mm (Inch) (6.772 x 10.236 x 0.197)

  • Page 75: Tp090Gtw

    P Line Touch Panel Technical Data TP090GTW Central Processing Unit Central processing unit AMD embedded G-Series Clock frequency 1 GHz single / dual-core Display Size (diagonal) in cm 22.86 (9) (inch) Type TFT (color) Resolution (pixels) 800 x 480 Colors 16.77 million...
  • Page 76 Technical Data P Line Touch Panel Front Panel and Enclosure Enclosure Steel sheet, galvanized Front panel material Aluminium, brushed, anodized natural finish Front panel (H x W x D) in 172 x 260 x 5 mm (Inch) (6.772 x 10.236 x 0.197)

  • Page 77: Tp105Zts

    P Line Touch Panel Technical Data TP105ZTS Central Processing Unit Central processing unit Intel® Atom™ Clock frequency 1.6 GHz Display Size (diagonal) in cm 26.42 (10.4) (inch) Type TFT (color) Resolution (pixels) 800 x 600 Colors 262144 Reading angle (vertical / 110°...
  • Page 78 Technical Data P Line Touch Panel Front Panel and Enclosure Enclosure Steel sheet, galvanized Front panel material Aluminium, brushed, anodized natural finish Front panel (H x W x D) in 220 x 295 x 5 mm (Inch) (8.661 x 11.614 x 0.196)

  • Page 79: Tp105Gts

    P Line Touch Panel Technical Data TP105GTS Central Processing Unit Central processing unit AMD embedded G-Series Clock frequency 1 GHz single / dual-core Display Size (diagonal) in cm 26.42 (10.4) (inch) Type TFT (color) Resolution (pixels) 800 x 600 Colors...
  • Page 80 Technical Data P Line Touch Panel Front Panel and Enclosure Enclosure Steel sheet, galvanized Front panel material Aluminium, brushed, anodized natural finish Front panel (H x W x D) in 220 x 295 x 5 mm (Inch) (8.661 x 11.614 x 0.196)

  • Page 81: Tp121Zts

    P Line Touch Panel Technical Data 6.10 TP121ZTS Central Processing Unit Central processing unit Intel® Atom™ Clock frequency 1.6 GHz Display Size (diagonal) in cm 30.73 (12.1) (inch) Type TFT (color) Resolution (pixels) 800 x 600 Colors 262144 Reading angle (vertical / 140°...
  • Page 82 Technical Data P Line Touch Panel Front Panel and Enclosure Enclosure Steel sheet, galvanized Front panel material Aluminium, brushed, anodized natural finish Front panel (H x W x D) in 270 x 340 x 5 (10.63 x 13.386 x 0.197)

  • Page 83: Tp121Gts

    P Line Touch Panel Technical Data 6.11 TP121GTS Central Processing Unit Central processing unit AMD embedded G-Series Clock frequency 1 GHz single / dual-core Display Size (diagonal) in cm 30.73 (12.1) (inch) Type TFT (color) Resolution (pixels) 800 x 600...
  • Page 84 Technical Data P Line Touch Panel Front Panel and Enclosure Enclosure Steel sheet, galvanized Front panel material Aluminium, brushed, anodized natural finish Front panel (H x W x D) in 270 x 340 x 5 (10.63 x 13.386 x 0.197)

  • Page 85: Tp121Ztm

    P Line Touch Panel Technical Data 6.12 TP121ZTM Central Processing Unit Central processing unit Intel® Atom™ Clock frequency 1.6 GHz Display Size (diagonal) in cm 30.73 (12.1) (inch) Type TFT (color) Resolution (pixels) 1280 x 800 Colors 262144 Reading angle (vertical / 176°...
  • Page 86 Technical Data P Line Touch Panel Front Panel and Enclosure Enclosure Steel sheet, galvanized Front panel material Aluminium, brushed, anodized natural finish Front panel (H x W x D) in 225 x 330 x 5 mm (Inch) (8.858 x 12.992 x 0.197)

  • Page 87: Tp121Gtm

    P Line Touch Panel Technical Data 6.13 TP121GTM Central Processing Unit Central processing unit AMD embedded G-Series Clock frequency 1 GHz single / dual-core Display Size (diagonal) in cm 30.73 (12.1) (inch) Type TFT (color) Resolution (pixels) 1280 x 800...
  • Page 88 Technical Data P Line Touch Panel Front Panel and Enclosure Enclosure Steel sheet, galvanized Front panel material Aluminium, brushed, anodized natural finish Front panel (H x W x D) in 225 x 330 x 5 mm (Inch) (8.858 x 12.992 x 0.197)

  • Page 89: Tp150Ztx

    P Line Touch Panel Technical Data 6.14 TP150ZTX Central Processing Unit Central processing unit Intel® Atom™ Clock frequency 1.6 GHz Display Size (diagonal) in cm 38.1 (15) (inch) Type TFT (color) Resolution (pixels) 1024 x 768 Colors 262144 Reading angle (vertical / 140°...
  • Page 90 Technical Data P Line Touch Panel Front Panel and Enclosure Enclosure Steel sheet, galvanized Front panel material Aluminium, brushed, anodized natural finish Front panel (H x W x D) in 329 x 400 x 5 (12.953 x 15.748 x 0.197)

  • Page 91: Tp150Gtx

    P Line Touch Panel Technical Data 6.15 TP150GTX Central Processing Unit Central processing unit AMD embedded G-Series Clock frequency 1 GHz single / dual-core Display Size (diagonal) in cm 38.1 (15) (inch) Type TFT (color) Resolution (pixels) 1024 x 768...
  • Page 92 Technical Data P Line Touch Panel Front Panel and Enclosure Enclosure Steel sheet, galvanized Front panel material Aluminium, brushed, anodized natural finish Front panel (H x W x D) in 329 x 400 x 5 (12.953 x 15.748 x 0.197)

  • Page 93: Tp154Ztm

    P Line Touch Panel Technical Data 6.16 TP154ZTM Central Processing Unit Central processing unit Intel® Atom™ Clock frequency 1.6 GHz Display Size (diagonal) in cm 39.1 (15.4) (inch) Type TFT (color) Resolution (pixels) 1280 x 800 Colors 262144 Reading angle (vertical / 140°...
  • Page 94 Technical Data P Line Touch Panel Front Panel and Enclosure Enclosure Steel sheet, galvanized Front panel material Aluminium, brushed, anodized natural finish Front panel (H x W x D) in 297 x 420 x 5 (11.692 x 16.535 x 0.197)

  • Page 95: Tp154Gtm

    P Line Touch Panel Technical Data 6.17 TP154GTM Central Processing Unit Central processing unit AMD embedded G-Series Clock frequency 1 GHz single / dual-core Display Size (diagonal) in cm 39.1 (15.4) (inch) Type TFT (color) Resolution (pixels) 1280 x 800...
  • Page 96 Technical Data P Line Touch Panel Front Panel and Enclosure Enclosure Steel sheet, galvanized Front panel material Aluminium, brushed, anodized natural finish Front panel (H x W x D) in 297 x 420 x 5 (11.692 x 16.535 x 0.197)

  • Page 97: Ordering Data

    P Line Touch Panel Ordering Data 7 Ordering Data Tabelle 7-1 Accessories Description Part No. SD card 512 MB 81152.513 USB 2.0 stick 1 GB 81152.100 USB 2.0 stick 2 GB 81152.200 USB 2.0 stick 8 GB 81152.800 Battery, assembled with cable and connector (Type: CR2450) 66779.100...
  • Page 98 Ordering Data P Line Touch Panel...

  • Page 99: A Index

    A Index Accessories............97 Ordering data ............. 97 Administration .............38 Password ............39 Battery..............59 Pin assignment Battery disposal ..........61 CAN ............54 Ethernet ............. 46 RS-232............52 Cable RS-422............49 CAN ............54 RS-485............49 Ethernet ............46 USB ............47 Changing the battery...........60 Rear view Cockpit CAN ............
  • Page 102 SÜTRON electronic GmbH Kurze Straße 29 D-70794 Filderstadt Phone: 0049 711 / 77098-0 Fax: 0049 711 / 77098-305 E-Mail: doku@suetron.de Internet:www.suetron.com...
