Sutron TPE057ATQ User Manual

Slim line
Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual
Slim Line Outdoor Touch Panel
Part Number:
80860.768
Version:
1
Date:
2010-08-06
Valid for:
TPE057ATQ

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPE057ATQ and is the answer not in the manual?

Questions and answers

Related Manuals for Sutron TPE057ATQ

Summary of Contents for Sutron TPE057ATQ

  • Page 1 User Manual Slim Line Outdoor Touch Panel Part Number: 80860.768 Version: Date: 2010-08-06 Valid for: TPE057ATQ...
  • Page 2 Slim Line Touch Panel Version Date Modifications 06.08.2010 First Edition This manual, including all illustrations contained herein, is copyright protected. Use of this manual by any third party in departure from the copyright provision is forbidden. No part of this manual may be reproduced, trans- lated or electronically or photographically archived or altered without the express written consent from Sütron electronic GmbH.

  • Page 3: Table Of Contents

    Slim Line Touch Panel Overall Table of Contents Overall Table of Contents Important Notes ....................... 1-1 Symbols ....................1-1 Safety Notes ..................... 1-1 Intended Use..................... 1-2 Target Group..................... 1-2 Installation and Commissioning ................2-1 Unpacking the Device ................2-1 Mounting the Device ................. 2-1 2.2.1 Front Panel Dimensions ..............
  • Page 4 Overall Table of Contents Slim Line Touch Panel Generally....................6-1 TPE057ATQ....................6-3 Ordering Data......................7-1 Index ........................A-1...

  • Page 5: Important Notes

    Slim Line Touch Panel Important Notes 1 Important Notes Symbols The symbols in this manual are used to draw your attention on notes and dangers. This is the safety alert symbol. It is used to alert you to potential personal injury haz- ards.

  • Page 6: Intended Use

    Important Notes Slim Line Touch Panel Intended Use – The device is designed for use in the industry. – The device is state-of-the art and has been built to the latest standard safety re- quirements. However, dangerous situations or damage to the machine itself or other property can arise from the use of this device.

  • Page 7: Installation And Commissioning

    Slim Line Touch Panel TPE057ATQ Installation and Commissioning 2 Installation and Commissioning Unpacking the Device Unpack all parts carefully and check the contents for any visible damage in transit. Also check whether the shipment matches the specifications on your delivery note.

  • Page 8: Front Panel Dimensions

    Installation and Commissioning Slim Line Touch Panel TPE057ATQ 2.2.1 Front Panel Dimensions Figure 2-1 TPE057ATQ...

  • Page 9: Mounting Cutout

    Slim Line Touch Panel TPE057ATQ Installation and Commissioning 2.2.2 Mounting Cutout Figure 2-2 TPE057ATQ A Mounting Cutout B Front Panel...

  • Page 10: Side View, Mounting Depth

    Installation and Commissioning Slim Line Touch Panel TPE057ATQ 2.2.3 Side View, Mounting Depth Figure 2-3 TPE057ATQ Front Panel Circumferential Seal Press-in Threaded Bolt M4 x 16 mm (0.629") Mounting Surface Thickness 1 mm to 6 mm (0.039" to 0.236") Spring Lock Washer B4 DIN 127 Form B (not supplied)

  • Page 11: Connecting The Device

    Slim Line Touch Panel TPE057ATQ Installation and Commissioning Connecting the Device 2.3.1 Supply Voltage 24 V The supply voltage is supplied via connector X1. The device has reverse polarity protection. In case of wrong polarity, the device will not operate.
  • Page 12 Installation and Commissioning Slim Line Touch Panel TPE057ATQ 2. Fit the wires with wire end ferrules and connect the wires to the connector. Figure 2-5 Connecting the female connector strip 3. Plug the female connector strip onto connector X1. Figure 2-6 Female connector strip is plugged on 4.

  • Page 13: Switching On

    Slim Line Touch Panel TPE057ATQ Installation and Commissioning Switching On The Windows CE operating system is installed on the operating device. Running on the operating system is the visualization runtime. 2.4.1 Loading Procedure on Windows CE Operating Proce- dure The program allows you to use the buttons to make changes to the configuration.

  • Page 14: Launch Overview

    Installation and Commissioning Slim Line Touch Panel TPE057ATQ 2.4.1.1 Launch Overview Start Normal Admin Setup-Main Update Copy USB Stick Copy to Flash Copy to USB Import Settings Home Update Image Update Bootloader Home TouchScreen & Registry Save Registry Settings Change...

  • Page 15: Normal Mode

    Slim Line Touch Panel TPE057ATQ Installation and Commissioning 2.4.1.2 Normal Mode The program AppStarter.exe starts from the internal Flash memory. Admin Press For Setup Main Menu Figure 2-8 Display after startup Please, note that the device is accessible over the Ethernet only after assignment of an IP address to the Ethernet.
  • Page 16 Installation and Commissioning Slim Line Touch Panel TPE057ATQ Update, Copy USB-Stick, Copy to Flash: This function copies the data from the USB stick to the internal flash file system. Several projects can be managed in subdirectories below the directory TSvisRT. If more than one project is in different subdirectories, a choice dialog is displayed.
  • Page 17 Slim Line Touch Panel TPE057ATQ Installation and Commissioning LCD Saver switches the brightness to the lowest value, if no user operation occures for at least one hour. This entry is able to be password-protected. Touch Screen & Registry, Start Calibration: The touch calibration is started.
  • Page 18 Installation and Commissioning Slim Line Touch Panel TPE057ATQ Network Settings, TCP/IP Info: TCP/IP Info MAC: 0-7-93-FF-FF-CE IP: 192.168.100.82 Mask: 255.255.255.0 Device Name: MyName DHCP enabled Gate: 000.000.000.000 1. DNS: 000.000.000.000 2. DNS: 000.000.000.000 1. WINS: 000.000.000.000 2. WINS: 000.000.000.000 Figure 2-17 TCP/IP Info The following informations are displayed: –...
  • Page 19 Slim Line Touch Panel TPE057ATQ Installation and Commissioning Network Settings, Fix Settings, Gateway: Gateway Change Default Gateway 000.000.000.000 Cancel Figure 2-19 Gateway The system automatically deselects DHCP and optionally enters the settings from the IPSetting.ini file of the USB stick. This file must exist in the root directory of the USB stick.
  • Page 20 Installation and Commissioning Slim Line Touch Panel TPE057ATQ Network Settings, Fix Settings, WINS: WINS Primary WINS 000.000.000.000 Secondary WINS 000.000.000.000 Cancel Figure 2-21 WINS The system automatically deselects DHCP and optionally enters the settings from the IPSetting.ini file of the USB stick. This file must exist in the root directory of the USB stick.
  • Page 21 Slim Line Touch Panel TPE057ATQ Installation and Commissioning Network Settings, FTP Settings, Delete a user: Delete a user Enter User MyName Enter Password **** Confirm Password **** Cancel Figure 2-24 Delete a user You may enter the user name you like to delete.
  • Page 22 Installation and Commissioning Slim Line Touch Panel TPE057ATQ Settings, Contrast: Contrast Contrast Brightness Color Depth 8 bpp 16 bpp Apply Cancel Figure 2-27 Contrast The operating mode setup main is displayed with default values for contrast and brightness to ensure reading also at faulty values. If you change a value, you have to confirm this in a dialog.
  • Page 23 Slim Line Touch Panel TPE057ATQ Installation and Commissioning Settings, Password: Password Current Password Enable Password Change Cancel Figure 2-29 Password The password can be activated, deactivated or redefined. When the password is ac- tivated, all password-protected dialog boxes can only be accessed if the password has been entered successfully.
  • Page 24 Installation and Commissioning Slim Line Touch Panel TPE057ATQ Settings, Printer, Network Print, Network Server Login: Network Server Login User Name: Password: Domain: Cancel Figure 2-33 Network Server Login You may perform a network login. Enter a user name, password and domain.

  • Page 25: Administration Operating Mode

    Slim Line Touch Panel TPE057ATQ Installation and Commissioning 2.4.1.4 Administration Operating Mode If you press the Admin button during the startup phase, the Administration mode of operation starts. You can use the Admin.ini file to manage the device. This file must exist in the root directory of the USB stick.

  • Page 26: Important Files And Update

    Installation and Commissioning Slim Line Touch Panel TPE057ATQ Mode=Standard The Shell is restricted: No task bar and task switch available. Desktop contains the launch icon only. The change becomes effective on the next device reboot. DeviceName=MyName Defines the device name of the operating device ;DeviceName=MyName...

  • Page 27: Identification

    Slim Line Touch Panel TPE057ATQ Installation and Commissioning Identification The operating device can be identified using the nameplate on the rear of the device. Figure 2-35 Nameplate (example) Order number Version key (at time of delivery) MAC address Voltage and power specification Serial number 2.5.1...
  • Page 28 Installation and Commissioning Slim Line Touch Panel TPE057ATQ 2-22...

  • Page 29: Control And Display Elements

    Slim Line Touch Panel Control and Display Elements 3 Control and Display Elements Display DANGER: Toxic If the display is damaged, avoid touching, swallowing or breathing in the liquids or gases which may leak out! DANGER: Corrosive If the display is damaged, avoid touching, swallowing or breathing in the liquids or gases which may leak out! 3.1.1 Touch Screen...
  • Page 30 Control and Display Elements Slim Line Touch Panel...

  • Page 31: Interfaces Of The Device

    Slim Line Touch Panel Interfaces of the Device 4 Interfaces of the Device Figure 4-1 Rear view Female Connector X5 (Ethernet) Female Connector X9, X10 (USB Host - Type A) Female Connector X7 (RS422/RS485) - optional Termination Switch (X7) - optional Connector X1 (Supply Voltage) Threaded Bolt For Protective Grounding...

  • Page 32: Ethernet (X5)

    Interfaces of the Device Slim Line Touch Panel Ethernet (X5) A 10/100 Base-T Ethernet interface is located on the side of the operating device. 4.1.1 Pin Assignment Connector in the operating device: RJ45 female connector. Table 4-1 Assignment of the Ethernet interface Designation Function Transmitted Data, Positive Polarity...

  • Page 33: Diagnostics

    Slim Line Touch Panel Interfaces of the Device 4.1.3 Diagnostics Ethernet diagnostics LEDs are located at the side of the operating device. Figure 4-2 Position of the ethernet diagnostics LEDs Table 4-2 Function of the ethernet diagnostics LEDs Color State Designation Function Green...
  • Page 34 Interfaces of the Device Slim Line Touch Panel...

  • Page 35: Maintenance And Servicing

    Slim Line Touch Panel Maintenance and Servicing 5 Maintenance and Servicing Front Panel Only use a damp cloth to remove any dirt from the front panel. Fuse NOTICE: Damage The semiconductor fuse cannot be replaced! A semiconductor fuse is used to protect the device. Once the fuse has been tripped, the device must be disconnected from the supply voltage to allow the semiconductor fuse to regenerate.
  • Page 36 Maintenance and Servicing Slim Line Touch Panel...

  • Page 37: Technical Data

    Slim Line Touch Panel Technical Data 6 Technical Data Generally Touch Screen Type Low Reflective GFG (glass film glass), analog resistive, 4 wire technology Activation force Input area A (area within 20 mm, circulating): Minimum / maximum: 0,3 N / 1,5 N Average: 0,9 N Input area B (marginal area of 20 mm, circulating): Minimum / maximum: 0,5 N / 2,5 N...
  • Page 38 Technical Data Slim Line Touch Panel Environmental Conditions Temperature during oper- - 20 °C to + 70 °C (- 4 °F to + 158 °F) ation Temperature during stor- - 30 °C to + 80 °C (- 22 °F to + 176 °F) age, transport Relative air humidity for Front: 5 % to 95 %, no condensation...

  • Page 39: Tpe057Atq

    Slim Line Touch Panel Technical Data TPE057ATQ Display Type TFT (color) Resolution (pixels) 320 x 240 Colors 65536 Reading angle (vertical / 135° / 150° horizontal) Half-life backlighting 40,000 h Brightness in cd/m Display area (H x W) in 86.4 x 115.2 (3.402 x 4.535)
  • Page 40 Technical Data Slim Line Touch Panel...

  • Page 41: Ordering Data

    Slim Line Touch Panel Ordering Data 7 Ordering Data Table 7-1 Accessories Description Article No. USB 2.0 stick 1 GB 81152.100 USB 2.0 stick 2 GB 81152.200 USB 2.0 stick 8 GB 81152.800 Protective foil for touch screen 5,7" (Set with 10 protective foils, scraper and instructions) 81251.056...
  • Page 42 Ordering Data Slim Line Touch Panel...

  • Page 43: A Index

    Slim Line Touch Panel TPE057ATQ A Index Standards............6-2 Supply voltage 24 V .......... 2-5 Accessories............7-1 Switching on............2-7 Administration operating mode ....... 2-19 Target group............1-2 Cable Technical data........... 6-1 Ethernet ............ 4-2 TPE057ATQ..........6-3 USB ............4-3 Touch screen ............
  • Page 44 Slim Line Touch Panel TPE057ATQ...
  • Page 46 Sütron electronic GmbH Kurze Straße 29 D-70794 Filderstadt Phone: 0049 711 / 77098-0 Fax: 0049 711 / 77098-60 E-Mail: doku@suetron.de Internet: www.suetron.com...
